Order no.: PCE-AS1

PCE-AS1 is an air sampling meter used to assess microbiological pollution and monitor hygiene. Designed for use in hospitals, clean rooms, food, beverage, cosmetics, and pharmaceutical production facilities. The PCE-AS1 air sampler meets the latest requirements for devices used for airborne microbial analysis of bacterial and fungal counts. Rate is 100 lpm or 3.53 cfm with 300 micropores. **Optional ISO lab calibration listed under accessories**


- Accommodates manual adjustment of air volumes from 10 to 6000 liters
- Offers data storage for up to 99 parameters / 2000 measurement records
- Aids in compliance with HACCP, FDA FMSA, USP 797 and ISO 14698-1
- Runs off a rechargeable battery or AC power
- Supports standard Petri dishes of 90 mm / 3.5 in



Manufacturer: PCE Instruments
US$ 3,696.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-125/2
Ford flow cup meters are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 25 ... 120 mm²/s
- Ø nozzle: 2 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
US$ 198.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-125/3
Ford flow cup meters are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 49 ... 220 mm²/s
- Ø nozzle: 3 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
US$ 198.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-125/4
Ford flow cup meters are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 70 ... 370 mm²/s
- Ø nozzle: 4 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
US$ 198.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-CT 65

PCE-CT 65 is a thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory

Manufacturer: PCE Instruments
US$ 195.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-CT 65-ICA

PCE-CT 65 is a thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
US$ 335.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-CT 5000H-ICA

PCE-CT 5000H is a thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The thickness gauge automatically detects the type of metal to be measured.


- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
US$ 495.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-TG 300-ICA
The PCE-TG 300-ICA is a thickness gauge with special sensors for various applications. In general, the wall thicknesses of all homogeneous materials can be measured with the thickness gauge. For damping or scattering materials such as plastic or cast a special sensor is available.

Measuring range:
PE: pulse-echo mode 0.65 ... 600 mm (steel)
EE: echo-echo mode 2.50 ... 60 mm
Accuracy:
± 0.04 mm H [mm] (<10 mm); ± 0.4% H [mm] (> 10 mm)
H refers to the material thickness of the workpiece
Resolution: 0.1 mm / 0.01 mm / 0.001 mm (adjustable)
Incl. ISO Calibration Certificate
Manufacturer: PCE Instruments
US$ 1,711.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-125/5
Ford flow cup meters are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 214 ... 1413 mm²/s
- Ø nozzle: 5 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
US$ 198.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-MSR 50
The mini magnetic stirrer PCE-MSR 50 is suitable for applications in small laboratories. The mini magnetic stirrer can safely mix stirring quantities of 100 ... 1000 ml.

- Drive of the stirring points: Motorised
- Max. stirring quantity: 100 ... 1000 ml
- Adjustable speed: 0 ... 1600 rpm
- Stirring surface: Ø 88 mm
Manufacturer: PCE Instruments
US$ 46.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-CRC 10
The Adhesion Tester PCE-CRC 10 is designed to determine the quality of the adhesion of coatings. The Adhesion Tester is suitable for thin, thick or tough coatings on all surfaces. Since the adherence of paintings and other coatings is a crucial product and quality characteristic for their protective effect, adhesion testers are used in a wide range of industries.



- Evaluation of adhesion
- For thin, thick or tough coatings
- Large, non-slip grip
- Various blades selectable



Manufacturer: PCE Instruments
US$ 107.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-MSR 100

PCE-MSR 100 is a magnetic stirrer or magnetic stir plate commonly used in laboratories to ensure liquid samples are homogeneous in consistency and temperature. Proper mixing also boosts sensor response time, allowing measuring instruments to achieve stable readings more quickly.


- Maximum stirring volume: 2 Liters (L) ≈ 0.52 gallon
- Adjustable stirring speeds: 0 ... 1250 rpm
- Includes one magnetic stirrer bar



Manufacturer: PCE Instruments
US$ 125.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-CT 25FN

The Coating Thickness Gauge is used for the quick and precise detection of layer thicknesses on metals. In comparison to many other paint thickness gauges, this paint thickness gauge does not have to differentiate between ferrous and non-ferrous metal.

- Measuring range:  0 ... 1500 µm
-  Minimum thickness: Fe: 0.3 mm, NFe: 0.05 mm
- Measuring accuracy: ± (3% + 1 µm)
- Resolution: 0.1 µm in the measuring range 0 ... 100 µm
                      1 µm in the measuring range> 100 µm
Manufacturer: PCE Instruments
US$ 140.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-EMF 823

PCE-EMF 823 is a portable handheld single-axis magnetometer or electromagnetic radiation detector for measuring electromagnetic fields (EMFs). This user-friendly EMF meter is ideal for assessing risks associated with exposure to electromagnetic radiation emitted from electric power lines, home appliances and industrial devices.


- EMF measuring ranges: 20 micro Tesla (µT) / 200 µT / 2000 µT and 200 milli-Gauss (mG) / 2000 mG / 20000 mG
- EMF bandwidth: 30 Hz to 300 Hz
- Sampling time: Approx. 1 second

Manufacturer: PCE Instruments
US$ 165.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-CT 26FN
The PCE-CT 26FN thickness gauge can measure non-destructive coatings (paints, plastics ...) on steel / iron and non-ferrous metals. The PCE-CT 26FN thickness gauge is ideally suited to immediately detect, for example, accident damage to the vehicle.

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
Manufacturer: PCE Instruments
US$ 165.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-127/4
DIN flow cup meters are viscosity meters to determine the viscosity of liquids. The flow cup meters are often used in industry and research laboratories.

- Capacity: 100 ml
- Ø nozzle: 4 mm (± 0.02 mm)
- Material: anodized aluminum
- Standard: DIN 53211
Manufacturer: PCE Instruments
US$ 185.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-RCM 8
The Dust Monitor PCE-RCM 8 performs many measuring tasks. For example, the Dust Monitor can measure mass concentration, formaldehyde and TVOC. This Dust Monitor is specially designed for indoor measurement.

- Formaldehyde in mg / m³
- Measurement of TVOC
- Temperature measurement
- Alarm function
- Mass concentration
Manufacturer: PCE Instruments
US$ 191.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-RCM 10

PCE-RCM 10 is a portable handheld Dust Monitor used to monitor particulate matter (PM) concentrations in the air. Designed to aid in indoor air quality (IAQ) assessments, this Dust Monitor also measures air temperature and relative humidity (RH).


- PM channels: PM 2.5, PM 10
- Particle sizes (in micrometers): 2.5 µm, 10 µm
- Temp. measuring range: -20 ... +70 °C / -4 ... +158 °F
- Humidity measuring range: 0 ... 100 % RH
- 2.4" full-color LCD with user-friendly graphics
- For indicative measurements

Manufacturer: PCE Instruments
US$ 218.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-MSR 150
The magnetic stirrer PCE-MSR 150 is suitable for volumes up to 10 liters. The magnetic stirrer has an adjustable speed range of 200 ... 2200 rpm. The speed can be changed step by step in 10 rpm. You can buy the magnetic stirrer PCE-MSR 150 here in our online shop.

- Drive of the stirring points: Motor
- Max. Stirring quantity: 10 l
- Adjustable speed: 200 ... 2200 rpm
- Accuracy Speed: ± 20 rpm
- Recommended length of the stirring rod: 25 ... 60 mm / 1 x 2.4 in
Manufacturer: PCE Instruments
US$ 224.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-MSR 110
The inductive magnetic stirrer PCE-MSR-110, is a flat, space-saving laboratory magnetic stirrer. Due to the induction-based operation, a quiet operation and a flat design of the stirrer are made possible.

- Maximum stirring volume: 800 ml / 0.21 gallon based on water
- Flat construction
- Silent and wear-free drive
- Timer
- Agitator in stainless steel IP 65
- 1 stirring position Ø 94 mm / 3.7"
- Variably adjustable 15 - 1500 rpm
Manufacturer: PCE Instruments
US$ 244.00
