2 year Warranty
- Cable length: 2000 mm, 6.56 ft
- Cable diameter: 2.8 mm, 0.11"
- 0° viewing angle
- Camera resolution / image sensor: 400 x 400 Px
- Cable type: flexible
- Video output: HDMI
- LED light
PCE-VE 180 is a rechargeable handheld pistol-grip industrial borescope inspection camera with video recording and image capture functionality. Equipped with built-in LED lighting on the waterproof camera tip, the PCE-VE 180 industrial borescope features a detachable remote control with integrated 3.5" LCD for easy viewing and navigation. The remote control communicates using radio transmission at 2.4 GHz.
- Semi-flexible gooseneck cable
- 1 m / 3.28 ft cable length
- 3.9 mm / .16 in cable diameter
- Includes detachable 4.5 mm / .18 in mirror, hook and magnet
PCE-VE 200 is an industrial borescope, inspection camera or endoscope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
- 4.5 mm / 0.18 in diameter, semi-rigid
- 1 m / 3.28 ft cable length
- 180° image rotation
The PCE-VE 200SV1 industrial borescope is a nondestructive inspection camera. Thus, the PCE-VE 200SV1 industrial borescope is the ideal instrument for diagnosing hard-to-reach areas. Thus, the areas of mechanical engineering, sanitary and heating construction, and the entire construction and construction industry are among the main applications of the industrial borescope PCE-VE 200SV1.
- Camera head diameter 9 mm / 0.4 in
- Cable length: 1 m / 3.3 ft
- Interface: Micro USB 2.0
- Memory: Micro SD card
- Front and side view camera
The PCE-VE 200-S is an industrial inspection borescope camera or engine borescope for the non-destructive evaluation (NDE) of engines, machines and constructions. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head of this borescope camera features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
- 3.7 mm / 0.14 in diameter
- 1 m / 3.28 ft cable length
- 180° image rotation
A rigid industrial borescope for visual inspection in small and narrow holes and cavities for example in aviation industry. With a diameter of only 4 mm and a length of 175 or 432 mm / 6.9 or 17 in this rigid industrial borescope is very versatile. The integrated LED lamp allows for a very good illumination of cavities to be inspected. The robust and compact design of this type of industrial borescope is very good for use in routine inspections in various industries as in the automotive industry.
- Diameter only 4 mm / 0.16 in
- Useful length 175 or 432 mm / 6.9 or 17 in
- LED lighting
- Battery operation
The PCE-VE 200-S3 is an industrial inspection device, a borescope camera or engine borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head of this kind of borescope features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
- 3.7 mm / 0.14 in diameter
- 3 m / 9.8 ft cable length
- 1600 x 1200 pixels JPEG image / 640 x 480 pixels AVI video
The PCE-VE 200 is an industrial borescope or borescope camera for nondestructive evaluation (NDE) and machine diagnostics. This borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing hard-to-reach places, the scope can be rotated 180 ° and offers 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
Borescope
- 3.5 in LCD display
- 3.28 ft cable length
- 0.18 in cable diameter
- 1/8 in camera head / CMOS chip image sensor
- 640 x 480 pixels AVI video resolution
- Micro SD card memory
- Micro USB 2.0 and TV outputs
Air Flow Meter
The air flow meter PCE-VA 20-set is a measuring instrument for various wind related parameters. It has got an impeller diameter of ten centimeters. Moreover, if required, it is possible to order a set of flow hoods which provide a fast and reliable method which helps to use the 100 mm large impeller head optimally.
- incl. Flow hood
- 10 cm diameter impeller
- Backlight
- Automatic power off
- Extreme value measurement
- HOLD function
- Low battery indicator
The PCE-VE 200 is an industrial borescope camera for nondestructive evaluation (NDE) and machine diagnostics. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing hard-to-reach places, the scope can be rotated 180 ° and offers 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
Borescope
- 3.5 in LCD display
- 3.28 ft cable length
- 0.18 in cable diameter
- 1/8 in camera head / CMOS chip image sensor
- 640 x 480 pixels AVI video resolution
- Micro SD card memory
- Micro USB 2.0 and TV outputs
Clamp Meter
This Clamp Meter has been developed to determine indirectly, the the AC/DC currents with high accuracy. A non-contact clamp meter and a torch to illuminate the area being measured, have been integrated into this device. The small size of this Clamp Meter, makes it possible to use in small spaces with limited access.
- 4 digit LCD display with backlighting
- save function
- DCA zero rest function
- current tester, non-contact
- integrated light to illuminate measured area
- automatic range selection
- automatic disconnect
- clamp diameter: 18 mm
The PCE-VE 320N is an industrial borescope, inspection camera or industrial endoscope for the non-destructive inspection (NDI) of engines, machines and more. This industrial borescope is an ideal tool for diagnosing issues in hard-to-reach places. The waterproof camera head features 4 LED lights with automatic illumination. In addition, digital image magnification or zoom of up to 2 times is available.
- Diameter camera head: Ø 5.5 mm / 0.22"
- Cable length: 1 m / 3ft 3"
- Interface: mini-USB 1.1 and AV out
- Memory: 8 GB SD memory card (incl.)
The PCE-VE 330N is an industrial borescope, inspection camera or industrial endoscope for the non-destructive inspection (NDI) of engines, machines and more. This industrial borescope is an ideal tool for diagnosing issues in hard-to-reach places. The waterproof camera head features 4 LED lights with automatic illumination. In addition, digital image magnification or zoom of up to 2 times is available.
- Diameter camera head: Ø 5.5mm / 0.22"
- Interface: Mini-USB 1.1 and AV out
- Memory: 8 GB SD memory card (incl.)
- Cable length: 2 m / 6ft 6"
