Order no.: AQ-500 Set ECL

Chlorine Gas Leak Detector AQ-500 Set ECL

Question / Callback

Delivery time: 10 - 14 days

Description

Chlorine gas leak detector for measuring chlorine in the air / Many different sensors available / Sensor ECL / Exchangeable sensor head / Alarm function /
Data logger / Optional sensor for temperature and humidity

The chlorine gas leak detector is a highly accurate measuring device for measuring the chlorine concentration in our ambient air. Furthermore, sensor heads for other gases are also available for the chlorine measuring device, which are automatically recognized when they are plugged into the device. So you can use the chlorine meter in many different areas.

By using leading GSS Technology sensors, the Aeroqual gas leak detector has a high level of measurement accuracy and a very long service life for the sensor heads. The unique possibility of refreshing the sensors from the chlorine measuring device offers cost-effective maintenance of the devices compared to other sensor technologies. Depending on the model, the measured concentrations can be output via an analogue interface with a 0…5 V output signal, written to the internal memory of the chlorine measuring device or transferred to a PC via a USB interface.

A remote kit is also optionally available, which allows measurements to be taken with the chlorine meter in a safe room while the sensor is connected to the chlorine meter by cable. Due to the simplicity of the operation, the alarm thresholds for the optical or acoustic signaling can be changed in a very short time. In addition to the measured concentrations, which are displayed in ppm or mg/m³, the LCD display also shows the high and low alarms.

Highlights

- High accuracy and functionality
- Easy to operate and maintain
- Fast response time
- Interchangeable sensor heads
- LCD display
- Battery operation
- Alarm function
- Sensor calibration function
- Max. / Min. / Average function
- Analog output
- Digital output
- Data logger

Specification

Measurement units	ppm or mg/m³
Functions	Max, Min, Average, Average 15 min
Sensor head	removable / replaceable
Display status indication	battery, sensor, standby
Calibration function	zero calibration
Digital output	RS232 with USB converter
Data logger	8188 values
PC transmission	software and data cable incl.
Alarm function	"High", "Low", Mute
Alarm output	Transistor output, 150 mA max Low Alarm, High Alarm & Control
Analog output	0 ... 5 V
Location ID	Storage of the measuring location
Power supply	12 V DC
Battery	lithium polymer 12 V DC / 2700 mAh
Charger	12.6 V 2 A
Charging voltage	12.6 V
Charging time	2 ... 3 hours
Life cycle	> 500 charges
Housing	PC & ABS / IP20 & NEMA 1
Dimensions (incl. optionally available sensors)	195 x 122 x 54 mm / 7.7 x 4.8 x 2.1"
Weight	< 460 g / 16.2 oz (with battery)
Approvals	EN 50082-1: 1997, EN 50081-1: 1992, CE

Delivery Scope

1 x Chlorine Gas Leak Detector AQ-500 SET ECL
1 x Sensor head ECL (chlorine (Cl2) 0-10 ppm)
1 x 12 V DC 800 mA AC/DC plug-in power supply
1 x Battery pack 12 V
1 x Software and data cable (USB)
1 x Instruction manual

Downloads

Manual

Accessories

Gas Detector / Gas Detection Instrument

AQ-VOCH PID Sensor 0-2000 ppm

£ 1,818.00

Price excl. VAT &. delivery
2 year Warranty

AQ-VOCH PID Sensor (Photoionization Detector Sensor)

Measuring range: 0 … 2000 ppm
Minimum: 0.1 ppm
Measurement accuracy: <±0.2 ppm + 10% of measured value.
Resolution: 0.1 ppm
Temperature: 0 … 40 °C / 32 … 104 °F
Humidity: 10 … 95%

AQ-MT / methane (CH4)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Methane (CH4)MT/GSSsensor/semiconductorsensor

Measuring range:0… 10,000 ppm

Minimum:10ppm

Accuracy:<±15%
Resolution:1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-OZU / Ozone (O3)

£ 536.00

Price excl. VAT &. delivery
2 year Warranty

Ozone (O3)OZU/GSSsensor/semiconductorsensor

Measuring range:0… 0.15 ppm

Minimum:0.001ppm
- Accuracy:< ±0.005 %

Resolution: 0.001ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-OZL / Ozone (O3)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Ozone (O3)OZL/GSSsensor/semiconductorsensor

Measuring range:0…0.5 ppm

Minimum:0.001ppm
- Accuracy:< ±0.008 / 0 … 0.1 ppm

Resolution: 0.001ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-HA / hydrogen (H2)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Hydrogen (H2)HA/GSSsensor/semiconductorsensor

Measuring range:0…5000 ppm

Minimum:5ppm

Accuracy:<±10%
Resolution:1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-ENG / ammonia (NH3)

£ 810.00

Price excl. VAT &. delivery
2 year Warranty

Ammonia(NH3)ENG/GSEsensor(electrochemical sensor)

Measuring range:0…100 ppm

Minimum:0.2ppm

Accuracy:<±10%
Resolution: 0.1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-EHT / hydrogen sulphide (H2S)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Hydrogen sulphide (H2S)EHT/GSEsensor(electrochemical sensor)

Measuring range:0…100 ppm

Minimum:0.2ppm
- Accuracy:< ±0.5 / 0 … 5 ppm

Resolution:0.1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-EHS / hydrogen sulphide (H2S)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Hydrogen sulphide (H2S)EHS/GSEsensor(electrochemical sensor)

Measuring range:0…10 ppm

Minimum:0.01ppm
- Accuracy:< ±0.05 / 0 …0.5 ppm

Resolution:0.01ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-EF / formaldehyde (CH2O)

£ 810.00

Price excl. VAT &. delivery
2 year Warranty

Formaldehyde(CH2O)EF/GSEsensor(electrochemical sensor)

Measuring range:0… 10 ppm

Minimum:0.01ppm
- Accuracy:< ±0.05 / 0 … 0.5 ppm

Resolution:0.01ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-ECN / carbon monoxide (CO)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Carbon monoxide(CO)ECN /GSEsensor(electrochemical sensor)

Measuring range:0…100 ppm

Minimum: 0.1ppm
- Accuracy:< ±1 / 0… 10 ppm

Resolution:0.1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-ECM / carbon monoxide (CO)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Carbon monoxide(CO)ECM /GSEsensor(electrochemical sensor)

Measuring range:0…25 ppm

Minimum:0.02ppm
- Accuracy:< ±0.5 / 0 … 5 ppm

Resolution:0.01ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-ECL / chlorine (CL2)

£ 810.00

Price excl. VAT &. delivery
2 year Warranty

Chlorine(CL2)ECL/GSEsensor/semiconductorsensor

Measuring range:0…10 ppm

Minimum:0.1ppm

Accuracy:<±10%
Resolution:0.01ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ ESP / sulfur dioxide (SO2)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Sulphur dioxide (SO2)ESP/GSEsensor(electrochemical sensor)

Measuring range:0…100 ppm

Minimum:0.2ppm
- Accuracy:< ±0.05 / 0 … 0.5 ppm

Resolution:0.1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-ESO / sulfur dioxide (SO2)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Sulphur dioxide (SO2)ESO/GSEsensor(electrochemical sensor)

Measuring range:0…10 ppm

Minimum:0.01ppm
- Accuracy:< ±0.05 / 0 … 0.5 ppm

Resolution:0.01ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ EOZ / ozone (O3)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Ozone (O3)EOZ/GSSsensor/semiconductorsensor

Measuring range:0…10 ppm

Minimum:0.01ppm
- Accuracy:< ±0.1 / 0…1 ppm

Resolution: 0.01ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-CE / carbon dioxide (CO2)

£ 932.00

Price excl. VAT &. delivery
2 year Warranty

Carbon dioxide (CO2)CE/NDIR sensor(infrared sensor)

Measuring range:0… 5000 ppm

Minimum:5ppm

Accuracy:<±5%/(the display)
Resolution:1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-PE / perchlorethylene (C2CL4)

£ 536.00

Price excl. VAT &. delivery
2 year Warranty

Perchloroethylene(C2CL4)PE/GSSsensor/semiconductorsensor

Measuring range:0…200 ppm

Minimum:1ppm
- Accuracy:< ±5 / 0 … 50 ppm

Resolution:1ppm
Temperature:0 … +40 °C
Humidity:10…90%

Gas Detector / Gas Detection Instrument

AQ-VOC PID Sensor 0-30 ppm

£ 1,818.00

Price excl. VAT &. delivery
2 year Warranty

AQ-VOC PID Sensor (Photoionization Detector Sensor)

Measuring range: 0 … 30 ppm
Minimum: 0.01 ppm
Measurement accuracy: <±0.02 ppm + 10% of measured value.
Resolution: 0.01 ppm
Temperature: 0 … 40 °C / 32 … 104 °F
Humidity: 0 … 95%

Gas Detector / Gas Detection Instrument

Fixed Gas Detector Base AQ-FM S900

£ 332.00

Price excl. VAT &. delivery
2 year Warranty

The fixed gas detector base AQ-FM S900 for AQ-sensor heads can communicate with a variety of hardware systems. The transmitter can also be used as switching relays with user-set values, as 4-20 mA gas transmitter and it can communicate with a network via the RS485 interface. Changing sensor heads is quick and easy, no configuration changes required. Calibration certificate included. Wall mounting kit.

Analog Output: 4-20 mA (optional isolated), 10… 30V
External control signal: Min Max. Alarm, control and diagnostics
Power supply: 12V DC 1A power supply is required but not supplied
Interface: RS485

Attention! No AQ sensor head is included in the delivery, it must be ordered separately as an accessory!

AQ-NH / ammonia (NH3)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Ammonia (NH3) NH / GSS sensor / semiconductor sensor

Measuring range: 0 … 1000 ppm
Minimum: 2 ppm
Accuracy: <± 15%
Resolution: 1 ppm
Temperature: 0 … +40 ° C
Humidity: 10 … 90%

AQ-EOZH / ozone (O3)

£ 810.00

Price excl. VAT &. delivery
2 year Warranty

Ozone (O3) GSE sensor (electrochemical sensor)

Measuring range: 0 … 30 ppm
Lower detection limit: 0.01 ppm
Measurement accuracy: <± 0.05 ± 10%
Resolution: 0.01 ppm
Response time: 60 s
Temperature: 0 … 40 °C
Rel. humidity: 15 … 90% RH

AQ-END / nitrogen dioxide (NO2)

£ 810.00

Price excl. VAT &. delivery
2 year Warranty

Nitrogen dioxide (NO3) GSE sensor (electrochemical sensor)

Measuring range: 0 … 1 ppm
Lower detection limit: 0.005 ppm
Measurement accuracy: <± 0.02 ppm 0-0.2 ppm; <± 10% 0.2-1 ppm
Resolution: 0.001 ppm
Response time: 30 s
Temperature: 0 … 40 °C
Rel. humidity: 15 … 90% RH

AQ-CO / carbon monoxide (CO)

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

Carbon monoxide (CO) CO / GSS sensor (semiconductor sensor)

Measuring range: 0 … 1000 ppm
Minimum: 1 ppm
Accuracy: < ±10%
Resolution: 1 ppm
Temperature: 0 … +40 °C
Humidity: 10 … 90%

AQ-VP / VOC

£ 536.00

Price excl. VAT &. delivery
2 year Warranty

(VOC)VP/GSSsensor/semiconductorsensor

Measuring range:0…500 ppm

Minimum:1ppm
- Accuracy:±10 %

Resolution:1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-VN / NMHC

£ 496.00

Price excl. VAT &. delivery
2 year Warranty

AQ-VN/GSSsensor/semiconductorsensor/NMHC

Measuring range:0…25 ppm

Minimum:0.1ppm
- Accuracy:< ±10 % / 0.1 … 25 ppm

Resolution: 0.1ppm
Temperature:0 … +40 °C
Humidity:10…90%

AQ-VM / VOC

£ 536.00

Price excl. VAT &. delivery
2 year Warranty

(VOC)VM/GSSsensor/semiconductorsensor

Measuring range:0…25 ppm

Minimum:0.1ppm

Accuracy:<± 10%
Resolution:0.1ppm
Temperature:0 … +40 °C
Humidity:10…90%

Temperature and humidity sensor AQ-TRH for the Ozone Tester

£ 182.00

Price excl. VAT &. delivery
2 year Warranty

Optional sensorwhich, in additionto anothersensor, can beplugged in to the device assimpleplug and play.

Temperature range:-40 ° C …124° C
Humidity measuring range:0 … 100%RH
Data logger500Series:2706values

Carrying case for the ozone tester

£ 152.00

Price excl. VAT &. delivery
2 year Warranty

This carrying case is ideal for protecting your Aeroqual 200/300/500 device during transport. Furthermore, there are recesses for a power supply incl. cable.

AQ-R36 replacement battery for the Ozone Tester

£ 139.00

Price excl. VAT &. delivery
2 year Warranty

Replacement battery for the Ozone Tester

Wall mount for the Ozone Tester

£ 65.00

Price excl. VAT &. delivery
2 year Warranty

A bracket to mount the Ozone Tester AQ Series 200/300/500 on a wall.

Cigarette lighter adapter for ozone tester

£ 74.00

Price excl. VAT &. delivery
2 year Warranty

Adapter for the AQ Series 200/300/500 device to a 12V power source in a vehicle.

Remote Kit housing AQ-R13

£ 604.00

Price excl. VAT &. delivery
2 year Warranty

Remote KithousingAQ-R13(IP41andNEMA2)

Sensor Remote Kit for ozone tester

£ 310.00

Price excl. VAT &. delivery
2 year Warranty

TheAQ-R10Remote Kit(compatible withSeries 200/300/500)is usedto measuregasup to 14meters away in the environment.TheR13Remote Kitalso providesa housing protectedtoIP41andNEMA2standards.Furthermore, it isdesigned withasimpleplug and playsolutionso that the unit is as user friendly aspossible.

AQ-CD / carbon dioxide (CO2)

£ 932.00

Price excl. VAT &. delivery
2 year Warranty

Carbon dioxide (CO2)CD/NDIR sensor(infrared sensor)

Measuring range:0…2000 ppm

Minimum:2ppm

Accuracy:<±5%/(the display)
Resolution:1ppm
Temperature:0 … +40 °C
Humidity:10…90%
