PCE Instruments

Data Logger / Data Logging Instrument

Order no.: PCE-VDL 16I
The data logger PCE-VDL 16I from PCE Instruments measures and stores the relevant measured variables: temperature, relative humidity, air pressure, light as well as acceleration in three axes by means of a vibration sensor. Therefore, this data logger is ideal for monitoring vibrations on machines while simultaneously measuring and recording the relevant environmental conditions of the system.

- 3-Axis acceleration up to 800 Hz
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Temperature, Humidity, Air pressure, Vibration, and Light

£ 222.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-PDFL 10
The data logger has a measuring range of -30 ... 60°C and can be used in cold environments. In addition to temperature and humidity measurement, the data logger can also measure the absolute air pressure in the ambient atmosphere in a measuring range between 700 ... 1100 hpa.

- Measuring range temperature: -30 ... 60°C / -22 ... 140°F
- Measuring range relative humidity: 0 ... 100% r. h.
- Measuring range absolute air pressure: 700 ... 1100 hpa
- Data export: .pdf, .csv
- Interface: USB-A
- Memory capacity: 13340 measuring points
£ 78.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HT 70
The humidity / temperature data logger records the air temperature and humidity and stores them internally. The compact  humidity / temperature data logger with a large memory (up to a maximum of 16,000 values) is primarily used for long-term registration, for example in the food sector (e.g. refrigerated counters in supermarkets, refrigerated transport, warehouses) or in the industrial sector (heating and cooling processes, machine temperatures, product warehouses...)

- Measuring range temperature: -40 ... 85 °C
- Measuring range rel. humidity: 0 ... 100%
- Max. 16,000 data records can be saved
- Export to software possible
- 450 day running time
- Adjustable storage rate from 1 second
£ 52.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HT 70-ICA
The humidity / temperature data logger records the air temperature and humidity and stores them internally. The compact humidity / temperature data logger with a large memory (up to a maximum of 16,000 values) is primarily used for long-term registration, for example in the food sector (e.g. refrigerated counters in supermarkets, refrigerated transport, warehouses) or in the industrial sector (heating and cooling processes, machine temperatures, product warehouses...)

- Measuring range temperature: -40 ... 85 °C / -40 ... 185 °F
- Measuring range rel. humidity: 0 ... 100%
- Max. 16,000 data records can be saved
- Export to software possible
- 450 day running time
- Adjustable storage rate from 1 second
- incl. ISO Calibration Certificate
£ 174.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HT 71N

The PCE-HT 71N Data Logger detects air temperature and humidity and stores readings in its internal memory. The Data Logger has a compact format and a wide memory capacity (up to 32,000 values / 16,000 values for each parameter) and it is mainly used as a data logger in fields such as supermarket refrigeration units, refrigerated transport, warehouses, and other temperature controlled environments. The logging instruments are sent out manufacturer calibrated and can be equipped with an ISO calibration certificate optionally.


- Measurement range: 0 ... 100% RH / -35 ... 70°C / -31 ... 176°F
- Accuracy: ± 3% RH (20 ... 80%) and  ± 5% / ± 1°C (1.8°F)
- Resolution: 0.5% RH / 0.1°C (0.18°F)
- Memory: Max. 32,000 measurement data (16,000 for each parameter (humidity / temperature))

£ 72.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HT 71N-ICA

The PCE-HT 71N Data Logger detects air temperature and humidity and stores readings in its internal memory. The Data Logger has a compact format and a wide memory capacity (up to 32,000 values / 16,000 values for each parameter) and it is mainly used in fields such as supermarket refrigeration units, refrigerated transport, warehouses, and other temperature controlled environments.


- Measurement range: 0 ... 100% RH / -35 ... 70°C / -31 ... 176°F
- Accuracy: ± 3% RH (20 ... 80%) and  ± 5% / ± 1°C (1.8°F)
- Resolution: 0.5% RH / 0.1°C (0.18°F)
- Memory: Max. 32,000 measurement data (16,000 for each parameter (humidity / temperature))
- Incl. ISO calibration certificate

£ 195.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HT 72
The temperature / humidity pdf data logger is a data logger has a memory of 20,010 sets of measurements and allows the pdf data logger to be used up to several months. The temperature / humidity pdf data logger is particularly suitable for measuring tasks where it is not possible for the user to install a software for reading the measured values.

- Measuring range Temp.: -30 ... 60°C / -22 ... 140°F
- Measuring range rel. Humidity: 0 ... 100% rh
- Measurement protocol as PDF
- Data export possible as CSV
- Readable without software
- 20,010 sets of measured values can be stored
£ 67.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HT 72-ICA
The temperature / humidity pdf data logger is a data logger has a memory of 20,010 sets of measurements and allows use of up to several months. The temperature / humidity pdf data logger is particularly suitable for measuring tasks where it is not possible for the user to install software for reading the measured values.

- Measuring range temp.: -30 ... 60 °C / -22 ... 140 °F
- Measuring range rel. humidity: 0 ... 100% RH
- Measurement protocol as PDF
- Data export possible as CSV
- Readable without software
- 20,010 sets of measured values can be stored
- incl. ISO Calibration Certificate
£ 190.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T390

The PCE-T390 multi channel temperature data logger is a digital device with four input channels for type K and type J temperature sensors and two input channels for PT100 temperature sensors. The PCE-T390 multi channel data logger has a SD card slot (from 1 ... 16 GB) for storing the measured data. The data is stored in xls format on the SD card of the data logger so that no additional software is needed for further analysis. This temperature logging test instrument comes manufacturer calibrated. An ISO calibration certificate can be purchased as an optional accessory.


- 4 input channels for type-K, J temperature sensors
- 2 input channels for Pt100 temperature sensors
2 x type-K TF-500 temperature sensors are included in the package
- Sampling rate of 1 sec.
- SD card memory (1 ... 16 GB)



£ 230.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T390-ICA
The multi channel temperature data logger is a digital device with four input channels for type K and type J temperature sensors and two input channels for PT100 temperature sensors. The temperature data logger has a SD card slot (from 1 to 16 GB) for storing the measured data.

- 4 input channels for type-K, J temperature sensors
- 2 input channels for Pt100 temperature sensors
- 2 x type-K TF-500 temperature sensors are included in the package
- Sampling rate: 1/ sec.
- SD card memory (1 ... 16 GB)
- Incl. ISO calibration certificate
£ 281.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 420
The 4-channel temperature data logger allows for the display and archiving of multiple temperature sensors simultaneously. It can be connected to up to 8 different types of thermocouples.

- Measurement range from -200 ... +1800 °C
- High resolution of 0.1 °C
- Connectable with 8 types of thermocouples
- Thermocouple types: K, J, S, R, E, T, N, B
- Storage for 10 million measurement values
- Data interface: USB-C
- Equipped with 4 channels
£ 343.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 420-ICA
The 4-channel temperature data logger allows for the display and archiving of multiple temperature sensors simultaneously. It can be connected to up to 8 different types of thermocouples.

- Measurement range from -200 ... +1800 °C
- High resolution of 0.1 °C
- Connectable with 8 types of thermocouples
- Thermocouple types: K, J, S, R, E, T, N, B
- Storage for 10 million measurement values
- Data interface: USB-C
- Equipped with 4 channels
- incl. ISO-Calibration Certificate
£ 396.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HTD 125
The temperature data logger is an independent measuring device for determining temperatures between -40 ... 125 °C. The temperature data logger is therefore particularly suitable for monitoring particularly hot environments.

- Measuring range: -40 ... 125 °C / -40 ... 257 °F
- Measurement accuracy: ± 0.2 °C (0 ... +65 °C / 32 ... 149 °F)
- Resolution: 0.1 °C
- USB data logger
- Data export directly as PDF
£ 191.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HTD 125-ICA
The temperature data logger is an independent measuring device for determining temperatures between -40 ... 125 °C. The temperature data logger is therefore particularly suitable for monitoring particularly hot environments.

- Measuring range: -40 ... 125 °C / -40 ... 257 °F
- Measurement accuracy: ± 0.2 °C (0 ... +65 °C / 32 ... 149 °F)
- Resolution: 0.1 °C
- USB data logger
- Data export directly as PDF
incl. ISO-Calibration Certifikate
£ 311.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-LTD 100
The temperature data logger has a measuring range of -80 … +70 °C. The temperature data logger is therefore suitable for monitoring particularly cold environments.

- Measuring range: -80 ... +70 °C / -112 ... +158 °F
- Measurement accuracy: ± 0.5 °C (-30 ... +70 °C / -22 ... +158 °F)
- Resolution: 0.1 °C
- USB data logger for dry ice
- Data export directly as PDF
£ 191.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 1200

PCE-T 1200 is a 12-channel temperature data logger that accommodates SD cards up to 16 GB in size. The optional software allows the temperature data logger to connect to a PC via USB for direct data transfer and analysis via Microsoft Excel.

- 12-channel data logger for temperature (°C / °F)
- Works with type K, J, T, E, R and S thermocouple sensors
- Adjustable datalogging interval from 1 ... 3600 seconds per channel
Includes 2 Type K sensors 1-meter in length

£ 889.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 1200-ICA

PCE-T 1200 is a 12-channel temperature data logger that accommodates SD cards up to 16 GB in size. The optional software allows the temperature data logger to connect to a PC via USB for direct data transfer and analysis via Microsoft Excel.

- 12-channel data logger for temperature (°C / °F)
- Works with type K, J, T, E, R and S thermocouple sensors
- Adjustable datalogging interval from 1 ... 3600 seconds per channel

Includes 2 Type K sensors 1-meter in length
- incl. ISO Calibration Certificate

£ 1,477.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-JR 911

The PCE-JR-911 Data Logger with logging function is a versatile tool in that it can measure the temperature of objects without contact and readings can be stored in memory and transferred to a computer by way of its RS-232 interface and software. This Data Logger comes complete, allowing the user to program specific time intervals for taking measurements, such as over an entire week. These temperature logging test instruments are calibrated by the manufacturer. An ISO calibration certificate is available as an option.


- Temperature range: -40 to 500°C / -40 ... 932°F
- Resolution: 0.1°C / 0.18°F
- Accuracy: ±2% of reading or ±2°C / 3.6°F
- Optical resolution: 8:1
- Emissivity: 0.3 to 1.0 (adjustable)
- Interface: RS-232
- Display: LCD



£ 329.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-JR 911-ICA

The infrared temperature data logger is a versatile tool in that it can measure the temperature of objects without contact and readings can be stored in memory and transferred to a computer by way of its RS-232 interface and software. This infrared temperature data logger allows the user to program specific time intervals for taking measurements, such as over an entire week.

- Non-Contact temperature measurement (infrared)
- Sampling rate: 1/ sec.
- Memory size: 12,000 values
- Adjustable date and time
- Printer, memory, data Logger integrated
- Incl. ISO calibration certificate

£ 422.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HPT 1

The Data Logger with microprocessor is a high precision 1-channel temperature gauge. The Data Logger with microprocessor is ideal for use with various Pt100 sensors. These temperature logging test instruments are calibrated by the manufacturer. An ISO calibration certificate is available as an option.


- 1 channel temperature recorder
- Automatic shutdown
- High accuracy of ± 2% r.H.
- Sampling rate of 2 / sec
- Memory size: 5,000 values

£ 378.00

Price excl. VAT &. delivery
2 year Warranty
