US$ 237.00
Legal for Trade Scale up to 6,000 kg / Resolution from 0.1 kg
/
Bidirectional RS-232 interface / Tare weight storable / Piece counting function
/
Optional: analog output 4-20 mA, 0-10 V, OC switch contacts, etc.
|
||||||||||||||
* The minimum load is the load from which the calibration authority checks the accuracy. The verifiable floor scale also indicates smaller weights, but these may not be used in legal traffic. | ||||||||||||||
Calibration | calibratable according to class M III (calibrated) | |||||||||||||
Tare range | multiple tare over the full range | |||||||||||||
Settling time | <4 s | |||||||||||||
Display | LED with 20 mm digit height (on the 3 m cable) | |||||||||||||
Weighing units | kg / piece / lb | |||||||||||||
Interface | bidirectional RS-232 optional USB, LAN, 4-20 mA, 0-10V, OC |
|||||||||||||
Ramp | optional, see accessories | |||||||||||||
Operating temperature | -10 °C ... +40 °C | |||||||||||||
Power supply | ~230V 50Hz 8VA (safety plug) | |||||||||||||
Protection | IP68 cells / IP65 display |
