| Layer thickness | |
| Measurement range up to | 2 ... 100 µm |
| Resolution | 0.1 µm |
| Accuracy | ±1 µm |
| Layer thickness | |
| Measurement range up to | 100 ... 1000 µm |
| Resolution | 1 µm |
| Accuracy | ±1% |
| Layer thickness | |
| Measurement range up to | 1000 ... 2000 µm |
| Resolution | 10 µm |
| Accuracy | ±3% |
| Layer thickness | |
| Measurement range up to | 2000 ... 5000 µm |
| Resolution | 10 µm |
| Accuracy | ±5% |
| Sensor | |
| Designation | DX5-F |
| Measurable materials | Measurement of paint, varnish, plastic and galvanized coatings on steel |
| Min. measuring surface | Ø 4 mm |
| Min. radius of curvature convex | 4 mm |
| Min. radius of curvature concave | 38 mm |
| Additional description | Standard FE probe with sliding sleeve and prism, swivelling |
| General technical data | |
| Measuring functions | Quantity, MAX, MIN, Average value, Standard deviation |
| Units | µm, mils |
| Display type | LCD touchscreen |
| Display resolution | 320x480 pixels |
| Storage medium | Internal memory |
| Storage capacity | 10000 Measurements |
| Interface | USB, SCPI |
| Standard(s) | ISO 2178, ISO 2360, BS 5411, ASTM |
| Operating time | 25 h |
| Operating time additional information | Unlimited with external power source |
| Automatic power-off from...to | 5 ... 30 min. |
| Automatic power-off can be deactivated | Yes |
| Menu language | German, English (GB), English, Italian, French, Spanish |
| Protection class (device) | IP64 |
| Power supply | 3x 1.5V AA battery or 5V via USB |
| (Rechargeable) battery | 3 x 1.5V AA battery , Alkali-manganese |
| Capacity | 3000 mAh |
| Operating conditions | 0 ... 50°C / 32 … 122°F, 10 ... 90% RH |
| Storage conditions | 0 ... 50°C / 32 … 122°F, 10 ... 90% RH |
| Dimensions ( L x W x H ) | 150 x 85 x 35 mm / 5.9 × 3.3 × 1.4 in |
| Weight | 251 g / 0.55 lb |
| Layer thickness | |
| Measurement range up to | 2 ... 100 µm |
| Resolution | 0,1 µm |
| Accuracy | ±1 µm |
| Layer thickness | |
| Measurement range up to | 100 ... 1000 µm |
| Resolution | 1 µm |
| Accuracy | ±1% |
| Layer thickness | |
| Measurement range up to | 1000 ... 2000 µm |
| Resolution | 10 µm |
| Accuracy | ±3% |
| Layer thickness | |
| Measurement range up to | 2000 ... 5000 µm |
| Resolution | 10 µm |
| Accuracy | ±5% |
| Sensor | |
| Designation | DX5-F |
| Measurable materials | Measurement of paint, varnish, plastic and galvanised coatings on steel |
| Min. measuring surface | Ø 4 mm |
| Min. radius of curvature convex | 4 mm |
| Min. radius of curvature concave | 38 mm |
| Additional description | Standard FE probe with sliding sleeve and prism, swivelling |
| General technical data | |
| Measuring functions | Quantity, MAX, MIN, Average value, Standard deviation |
| Units | µm, mils |
| Display type | LCD touchscreen |
| Display resolution | 320x480 pixels |
| Storage medium | Internal memory |
| Storage capacity | 10000 Measurements |
| Interface | USB, SCPI |
| Standard(s) | ISO 2178, ISO 2360, BS 5411, ASTM |
| Operating time | 25 h |
| Operating time additional information | Unlimited with external power source |
| Automatic power-off from...to | 5 ... 30 min. |
| Automatic power-off can be deactivated | Yes |
| Menu language | German, English (GB), English, Italian, French, Spanish |
| Protection class (device) | IP64 |
| Power supply | 3x 1.5V AA battery or 5V via USB |
| (Rechargeable) battery | 3 x 1,5 V AA battery , Alkali-manganese |
| Capacity | 3000 mAh |
| Operating conditions | 0 ... 50 °C , 10 ... 90 % RH |
| Storage conditions | 0 ... 50 °C , 10 ... 90 % RH |
| Dimensions ( L x W x H ) | 150 x 85 x 35 mm |
| Weight | 251 g |
