The compact Radiation Detector offers a precise and long-term stable solution for monitoring indoor radon concentrations. It is ideal for use in various environments such as living spaces, offices and laboratories. With a measuring range of 3.3 Bq/m³ ... 37 kBq/m³ and an accuracy of ±15%, the Radiation Detector enables reliable measurement of the radon concentration. The integrated semiconductor radon sensor ensures high measurement accuracy. The measuring interval is 60 minutes and the data is saved every 6 hours, which enables long-term data storage of up to 504 days.
The Radiation Detector displays minimum, maximum and AVG values as well as cumulative average values and the values for 12, 24, 48 and 96 hours. It also offers an acoustic and visual alarm function, which can be set in the range from 100 ... 800 Bq/m³. The first measured values are displayed after 6 hours and a new data record is saved every 6 hours, whereby a maximum of 10 data records can be saved. The 2-inch LC colour display can be switched to standby mode to maximise the operating time of the Li-ion battery, which lasts up to 45 days when the display is switched off.
The Radiation Detector is used for continuous monitoring of indoor radon concentrations, for example in workplaces or public buildings. It is used for the early detection of increased radon levels in order to assess health risks and initiate suitable measures.
Radiation | |
Measurement range up to | 3,3 Bq/m³ ... 37 kBq/m³ |
Resolution | 1 kBq/m³ |
Accuracy | ±15 % |
General technical data | |
Measuring functions | Cumulative average, 12h value, 24h value, 48h value, 96h value |
Units | pCi/L, kBq/m³ |
Display type | LC colour display |
Display size | 2 Inch |
Storage medium | Internal memory |
Memory information | The first measured values are displayed after 6 hours. A new data record is saved every 6 hours, whereby a maximum of 10 data records can be saved. Historical data can be viewed for up to 504 days. |
Interface | USB-C |
Operating time | 45 Day(s) |
Operating time additional information | with the screen switched off |
Alarm | optical, Acoustic |
Sensors | Semiconductor detector |
Alarm settings | 100 ... 800 Bq/m³ |
Measuring interval | 60 min |
Menu language | English, English (GB), Chinese |
Protection class (device) | IP20 |
(Rechargeable) battery | 1 x 3,7 V internal , lithium |
Capacity | 2000 mAh |
Operating conditions | -10 ... 45 °C , 0 ... 90 % RH |
Storage conditions | 0 ... 50 °C , 0 ... 90 % RH |
Dimensions ( L x W x H ) | 80 x 80 x 38 mm |
Weight | 122 g |
