Pressure Meter PCE-P30-ICA Incl. ISO Calibration Certificate

Order no.: PCE-P30-ICA
ISO Calibration

£ 325.00
£ 390.00
price ex. (VAT / delivery)
Delivery time: 10 - 14 days

PCE-P30 Pressure Meter incl. ISO calibration certificate
Handheld dual-port digital manometer measures gauge pressure and true differential pressure from 0 to 30 psi

PCE-P30 is a pressure meter used to measure gauge pressure and true differential pressure in pneumatic, hydraulic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. 11 pressure units are selectable for Imperial and Metric measurement, including bar, mmHg, ozin², kgcm², psi, inH2, kPa, ftH2O|, inHg, cmH2O and mbar.

Gauge pressure is measured relative to the ambient atmospheric pressure. Thus, changes in the atmospheric pressure due to weather conditions or altitude directly influence the output of a gauge pressure sensor. A gauge pressure higher than the ambient pressure is referred to as positive pressure. If the measured pressure is below the atmospheric pressure, it is called negative or vacuum gauge pressure.

Although most gauge pressure sensors technically are differential pressure sensors — measuring the difference between the media and atmospheric pressure — true differential pressure sensors are used to identify the difference between two separate physical areas. PCE-P30 features two pressure ports and a differential pressure function for measuring true differential pressure.

- 0 to 30 psi pressure measuring range
- 11 pressure units: bar, mmHg, ozin², kgcm², psi, inH2, kPa, ftH2O|, inHg, cmH2O, mbar
- Maximum / minimum, average, differential pressure and data hold functions
- Auto power off (can be disabled)
- Large LCD screen with backlight
- ABS plastic housing
- Connects to PC via RS-232 interface (cable and software not included - see accessories)
- Incl. ISO calibration certificate
Pressure measuring range: 0 to 30 psi
Pressure units of measure: bar, mmHg, ozin², kgcm², psi, inH2, kPa, ftH2O|, inHg, cmH2O, mbar
Resolution: 0.02 psi
Accuracy: ± 0.3% of full scale at 25°C / 77°F
Response time: 0.5 seconds
Power supply: 1 x 9V battery
Approx. Dimensions: 72 x 182 x 30 mm / 2.84 x 7.17 x 1.18 in
Approx. Weight: 220 g / < 1 lb (with battery)

See user manual for complete technical specifications.
1 x PCE-P30 pressure meter
2 x Silicon tubes
1 x Battery
1 x User manual
1 x Carrying case
1 x ISO calibration certificate
