The pH Meter / pH Tester PCE-228SF is used to measure the pH on surfaces such as paper, cardboard, leather, textiles, and skin. The pH and temperature can be stored directly on the SD card. The special pH electrode of the pH meter PCE-228SF is particularly flat and made of epoxy, which makes the pH electrode particularly resistant to impact. Temperature compensation is either manual or automatic via the supplied temperature sensor.
In addition to the measurement of the pH value of surfaces, the pH meter can also be used to measure very small sample volumes from 0.1 ml upwards. For this, the pH Meter / pH Tester is supplied with a special measuring cuvette. This cuvette can be plugged directly onto the electrode of the pH meter.
| pH | |
| Measuring range | 0 ... 14 pH |
| Resolution | 0,01 pH |
| Accuracy | ±(0.02 pH +2 digits) |
| Redox | |
| Measuring range | -1999 ... +1999 mV |
| Resolution | 1 mV |
| Accuracy | ±(0.5 % +2 digits) |
| Temperature | |
| Measuring range | 0 ... 65 °C |
| Resolution | 0,1 °C |
| Accuracy | ±0.5 °C |
| Electrode | |
| Designation | EPX-3 |
| Measuring range | 2 ... 12 pH |
| Temperature range | 5 ... 60 °C |
| Application | for damp surfaces: paper, fabrics, leather |
| Reference electrolyte | 3.3 M KCl Gel, Ag/AgCl |
| Shank material | Glass |
| Shank length | 110 mm |
| Shank diameter | 12 mm |
| Min. immersion depth | 1 mm |
| Cable length | 1 m |
| Connection | BNC-50 |
| General technical data | |
| Measuring functions | MIN, MAX, HOLD |
| Temperature compensation | - automatic 0 ... 65 °C - manual 0 ... 100 °C with temperature sensor removed |
| Display type | LCD with backlight |
| Display size | 2,6 Inch |
| Storage medium | SD card |
| Storage capacity | 4 GB |
| Memory capacity (additional information) | up to 16 GB SD card possible |
| Storage interval from | 1 s |
| Storage interval to | 9 min. |
| Interface | RS232 |
| Number of calibration points | 3 |
| Calibration | automatic |
| Menu language | English |
| Protection class (device) | IP20 |
| Power supply | 9 V DC |
| (Rechargeable) battery | 6 x 1,5 V AA battery , Alkali-manganese |
| Capacity | 3000 mAh |
| Operating conditions | 0 ... 50 °C , 0 ... 85 % RH |
| Storage conditions | 0 ... 50 °C , 0 ... 85 % RH |
| Dimensions ( L x W x H ) | 190 x 68 x 45 mm |
| Weight | 261 g |
