Price excl. VAT &. delivery
2 year Warranty
- Special pH electrode for higher temperatures up to 100°C / 212°F
- With BNC connection
Measured variable pH | |
Measuring range | 0 ... 14 pH |
Resolution | 0.01 pH |
Accuracy | ± (0.02 pH + 2 digits) |
Measured variable temperature | |
Measuring range | 0 ... 65°C / 32 ... 149°F |
Resolution | 0.1°C / 0.18°F |
Accuracy | ± 0.8°C / 1.44°F |
pH input impedance | 1012 ohms |
Temperature compensation | Manual: -30 ... 100°C / -22 ... 212°F |
Automatic: 0 ... 65°C / 32 ... 149°F | |
3-point calibration | pH 7, pH4, pH10 |
Connection pH electrode | BNC |
Ampling rate | About 1 second |
Display | 4 digit LED display |
14 mm digit height | |
NO relay | 250V AC / 0.5A |
24V DC / 0.5A | |
Spannungsausang | 12V / 0.05A DC |
Interface | Serial RS232 |
Operating conditions | 0 ... 50°C / 32 ... 122°F, max. 80% rh |
Power supply | 90 ... 260V AC / 50/60 Hz |
Input | Approx. 4.7 VA at 110V AC |
Approx. 5.3 VA at 220V AC | |
Weight | About 275 g / 9.7 oz meter only |
Dimensions | 96 x 48 x 107 mm / 3.8 x 1.9 x 4.2 in |
Front panel | 92 x 46 mm / 3.6 x 1.8 in |
