Industrial Measurement Products and Solutions

Metal Hardness Tester

Order no.: PCE-2600N

The Material Hardness Tester for Metal PCE-2600N is used wherever a fast hardness test has to be carried out. It is possible to use the material tester PCE-2600N to determine the surface hardness of many metals. The material tester PCE-2600N is especially suitable for quality or product inspection.

- Measurement ranges: 170 ... 960 HLD, 17.9 ... 69.5 HRC, 19 ... 683 HB,
   80 ... 1042 HV, 30.6 ... 102.6 HS, 59.1 ... 88 HRA, 3.5 ... 101.7 HRB
- Measurement method: According to Leeb
- Measurement units: HLD, HRC, HB, HV, HS, HRA, HRB
- Impactor: DL
- Display: 128 x 64 OLED

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-2600N-ICA

The Material Hardness Tester for Metal PCE-2600N-ICA is used wherever a fast hardness test has to be carried out. It is possible to use the material tester PCE-2600N-ICA to determine the surface hardness of many metals. The material tester PCE-2600N-ICA is especially suitable for quality or product inspection.

- Measurement ranges: 170 ... 960 HLD, 17.9 ... 69.5 HRC, 19 ... 683 HB,
   80 ... 1042 HV, 30.6 ... 102.6 HS, 59.1 ... 88 HRA, 3.5 ... 101.7 HRB

- Measurement method: According to Leeb
- Measurement units: HLD, HRC, HB, HV, HS, HRA, HRB
- Impactor: DL
- Display: 128 x 64 OLED
- Includes ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-2900
The hardness tester PCE-2900 has been developed for hardness measurements on metallic materials. The hardness tester PCE-2900 measures the material hardness in Vickers, Brinell, Rockwell, Leeb and Shore. The hardness tester PCE-2900 measures the hardness according to the Leeb rebound principle.


- Measuring range: 170 ... 960 HLD
- Reproducibility: ± 6 HLD
- Impactor: Type D
- Hardness scales (HRC, HRB, HV, HB, HS)
- USB and WiFi for data transmission
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-2900-ICA
The hardness tester PCE-2900 has been developed for hardness measurements on metallic materials. The hardness tester PCE-2900 measures the material hardness in Vickers, Brinell, Rockwell, Leeb and Shore. The hardness tester PCE-2900 measures the hardness according to the Leeb rebound principle.

- Measuring range: 170 ... 960 HLD
- Reproducibility: ± 6 HLD
- Impactor: Type D
- Hardness scales (HRC, HRB, HV, HB, HS)
- USB and WiFi for data transmission
- Incl. ISO Calibration Certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-2500N

PCE-2500N is a portable handheld pen-sized digital material hardness tester, rebound hammer or durometer for use with metals. This high-accuracy hardness tester quickly and accurately measures the surface hardness of 10 common metal materials including steel, cast steel, alloy tool steel, stainless steel, cast iron, ductile iron, cast aluminum alloy, brass, bronze and copper.


- Displays measurements in Rockwell A, B or C (HRA, HRB or HRC), Brinell (HB),
  Vickers (HV), Shore (HS) or Leeb (HLD)
- Measurement ranges: 170 ... 960 HLD, 17.9 ... 69.5 HRC, 3.5 ... 101.7 HRB, HB 19 ... 683 HB,
   80 ... 1042 HV, 30.6 ... 102.6 HS, 59.1 ... 88 HRA

- Accuracy: ± 0.5 HLD
- Type D impact device
- Measuring principle: Rebound method

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-900

The Leeb Material Hardness Tester PCE-900 measures the hardness of nine different metals using the Leeb rebound method. This means that with the material hardness tester a firing pin bounces on a metallic surface and the intensity of the rebound is used as an indicator of the material hardness. The Material Hardness Tester PCE-900 measures the metal hardness in 6 different hardness scales.



- Measurement according to Leeb method
- Testing of HRC, HRB, HV, HB, HSD
- Vertical measuring direction
- LCD
- Incl. type D Leeb probe
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-2500N-ICA

PCE-2500N-ICA is a portable handheld pen-sized digital material hardness tester, rebound hammer or durometer for use with metals. This high-accuracy hardness tester quickly and accurately measures the surface hardness of 10 common metal materials including steel, cast steel, alloy tool steel, stainless steel, cast iron, ductile iron, cast aluminum alloy, brass, bronze and copper.


- Displays measurements in Rockwell A, B or C (HRA, HRB or HRC), Brinell (HB),
  Vickers (HV), Shore (HS) or Leeb (HLD)
- Measurement ranges: 170 ... 960 HLD, 17.9 ... 69.5 HRC, 3.5 ... 101.7 HRB, HB 19 ... 683 HB,
   80 ... 1042 HV, 30.6 ... 102.6 HS, 59.1 ... 88 HRA

- Accuracy: ± 0.5 HLD
- Type D impact device
- Measuring principle: Rebound method
- Includes ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-1000N

PCE-1000N is a portable handheld Barcol hardness tester used to measure the hardness of pure aluminum, soft aluminum, thick aluminum alloy and aluminum sheets, strips, rods, castings and forgings. The hardness of fiber-reinforced (FRP) plastics, glass-reinforced (GRP) plastics, hard plastics and soft metals (such as copper or lead) also can be tested using this battery-powered digital Barcol impressor hardness meter.


- Measurement parameters: Barcol (HBA), Brinell (HB), Vickers (HV), Webster
  (HW)
  Rockwell (HRB / HRE / HRF / HRH)
- Measuring range: 0 ... 100 HBA / 25 ... 150 HB
- Accuracy: 81 ... 88 HBA: ± 1 HBA / 42 ... 48 HBA: ± 2 HBA
- Repeatability: 81 ... 88 HBA: ± 1.5 HBA / 42 ... 48 HBA: ± 2.5 HBA
- Resolution: 0.1 HBA



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-950

PCE-950 is a handheld material hardness tester used to determine the hardness of 10 different types of metal (i.e., cast steel, hammered steel, cold-rolled steel, stainless steel, cast iron, ductile iron, aluminum alloy, brass, bronze and forged copper alloy) according to the Leeb rebound method. In addition to Leeb hardness units, the metal hardness tester displays hardness measurements in Rockwell C, Rockwell B, Rockwell A, Brinell, Vickers and Shore hardness units.

- Measurement ranges: 19.8 ... 68.5 HRC, 13.5 ... 101.7 HRB, 59.1 ... 85.8 HRA,
   19 ... 655 HB, 80 ... 976 HV, 32.2 ... 115 HS
- Hardness units: HL, HRC, HRB, HRA, HB, HV, HS
- Accuracy: ±6 HL at HL = 790
- Impact device: Type D (integrated)
- Maximum hardness: 976 HV
- For use with hammered steel, cold-rolled steel, stainless steel, cast iron, ductile iron, aluminum alloy, brass, bronze and forged copper alloy metals

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-950-ICA

PCE-950-ICA is a handheld material hardness tester used to determine the hardness of 10 different types of metal (i.e., cast steel, hammered steel, cold-rolled steel, stainless steel, cast iron, ductile iron, aluminum alloy, brass, bronze and forged copper alloy) according to the Leeb rebound method. In addition to Leeb hardness units, the metal hardness tester displays hardness measurements in Rockwell C, Rockwell B, Rockwell A, Brinell, Vickers and Shore hardness units.

- Measurement ranges: 19.8 ... 68.5 HRC, 13.5 ... 101.7 HRB, 59.1 ... 85.8 HRA,
   19 ... 655 HB, 80 ... 976 HV, 32.2 ... 115 HS
- Hardness units: HL, HRC, HRB, HRA, HB, HV, HS
- Accuracy: ±6 HL at HL = 790
- Impact device: Type D (integrated)
- Maximum hardness: 976 HV
- For use with hammered steel, cold-rolled steel, stainless steel, cast iron, ductile iron, aluminum alloy, brass, bronze and forged copper alloy metals
- Includes ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-5000

PCE-5000 is a portable material hardness tester that uses the ASTM A1038 ultrasonic contact impedance (UCI) method to measure the hardness of metals and alloys with a minimum thickness of 2 mm / .08 in. Non-destructive testing produces microscopic indentation.


- Displays measurements in Rockwell A (HRA), Rockwell B (HRB), Rockwell C
  (HRC), Brinell (HB), Vickers (HV) and MPa (N/mm²) SI units
- Measurement ranges:
  61 … 85.6 HRA, 41 … 100 HRB, 20.3 … 68 HRC, 85 … 650 HB, 50 … 999 HV,
  255 … 2180 MPa (N/mm²)

- Accuracy: ± 1.5 HR, ± 3% HB, ± 3% HV
- Memory size: 1,000 groups for measurement data and 20 groups for
  calibration data
- Different probe types (also automatic motorized probes) available



Manufacturer: PCE Instruments
Test Instruments manufacturer
