PCE Instruments

Material Thickness Meter

Order no.: PCE-TG 100

The PCE-TG 100 is a compact material thickness meter for homogeneous materials. This material thickness meter PCE-TG 100 works with an external ultrasonic probe; this probe conducts ultrasonic waves into the material to be tested. Different materials conduct ultrasound at different speeds, so you can choose different ultrasonic speeds on the PCE-TG 100 Material Thickness Meter.


- Measurement range: 0.8 mm ... 225 mm / 0.03 in ... 8.86 in (displays in mm only)
- Adjustable sound velocity
- Suitable for metals, glass, plastics
- 5 MHz probe
- External sensor
- Material thickness

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TG 110

The material thickness meter PCE-TG 110 is a thickness gauge with external high-temperature probe for ferrous and non-ferrous metals etc. The PCE-TG 110 is an ideal material thickness meter for water pipes, steam pipes and pipes for chemicals.


- Measurement range: 2.5 mm ... 200 mm / 0.10 in ... 7.87 in (displays in mm only)
- Suitable for homogeneous materials such as metals, glass, ...
- Including special coated 5 MHz probe (usable up to 400°C / 752°F)
- External sensor

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TG 120

The material thickness meter PCE-TG120 is a very easy-to-use wall thickness gauge for all materials. This material thickness meter works to accurately measure the material thickness / wall thickness with ultrasound.

- Measurement range: 1 mm ... 30 mm / 0.04 in ... 1.18 in  (displays in mm only)
- Resolution: 0.1 mm / 3.94 mil
- Accuracy: ± 0.1 mm
- Integrated test block

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TG 250

PCE-TG 250 is a portable Material Thickness Meter with an easy-to-read 4-digit display. This ultrasound-based Material Thickness Meter uses a contact transducer (included) to measure the thickness of coated and uncoated ferrous and non-ferrous metal, glass, plastic, and other homogeneous materials including aluminum, brass, copper, iron, lead, nickel, steel, gold, titanium, pyrex and quartz glass, nylon, polyethylene, and silicone rubber.


- Measurement range: 1 mm ... 250 mm / 0.04 in ... 9.84 in (uncoated steel), 2.5 mm ... 20 mm / 0.1 in ... 0.79 in (coated surfaces)
- Accuracy: ±0.5% of measured value + 0.02 mm / 0.0008 in
- Resolution: 0.01 mm / 0.0004 in (Less than 100 mm / 3.9 inch); 0.1 mm / 0.004 in (over 100 mm / 3.9 inch)
- Sound velocity: 1000 m/s ... 9999 m/s / 3280 ft/s ... 32805 ft/s



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TG 300
The PCE-TG 300 is a material thickness meter with special sensors for various applications. In general, the wall thicknesses of all homogeneous materials can be measured with the material thickness meter. For damping or scattering materials such as plastic or cast a special sensor is available.

Measuring range:
PE: pulse-echo mode 0.65 ... 600 mm (steel)
EE: echo-echo mode 2.50 ... 60 mm
Accuracy:
± 0.04 mm H [mm] (<10 mm); ± 0.4% H [mm] (> 10 mm)
H refers to the material thickness of the workpiece
Resolution: 0.1 mm / 0.01 mm / 0.001 mm (adjustable)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TG 50

PCE-TG 50 is a compact ultrasonic material thickness meter or gauge used to measure the thickness of metal, glass, plastic and other homogeneous materials. This portable handheld material thickness gauge operates with an external ultrasonic contact transducer sensor probe and requires the use of coupling gel or paste.



- Measurement range: 1.2 ... 200 mm / 0.05 ... 7.87 in (steel)
- Accuracy: ± 0.5% of rdg. ± 0.1 mm / ± 0.0039 in
- Resolution: 0.1 mm / 0.001 in
- Ultrasound velocity (adjustable): 800 ... 9950 m/s / 2624 ... 32644 ft/s
- External sensor
- RS-232 interface
- Incl. calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 10
The material thickness gauge is used for quick and easy measurement of ink layer thicknesses on metallic surfaces. Due to the measuring range and the possibility of measuring on ferrous and non-ferrous metals, the material thickness gauge covers a large part of measuring tasks.

- Measuring range: 0 ... 2.20 mm
- Resolution: 0.01 mm
- Digital LCD display
- Automatic self-shutdown
- Adjustment with supplied standard possible
- For quick orientation measurement
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 65

PCE-CT 65 is a material coating thickness meter that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000H

PCE-CT 5000H is a material coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The material coating thickness meter or gauge automatically detects the type of metal to be measured.


- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 65-ICA

PCE-CT 65 is a material coating thickness meter that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness meter is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 100

PCE-CT 100 is a material coating thickness measuring instrument used to quickly and easily determine coating thicknesses on ferrous (Fe) and non-ferrous (nFe) metals. This compact handheld coating thickness gauge uses magnetic induction (ISO 2178) and eddy current (ISO 2360) coating thickness measurement methods to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum.


- Measuring range: Depends on choice of sensor probe - sold separately
- Resolution: 0.1 μm or < 0.2% of measured value
- Saves up to 100,000 measurements to memory
- Interfaces: USB 2.0, Bluetooth 4.0
- Displays measuring units in μm, mm or mils
- Includes factory calibration certificate according to ISO 9001

Manufacturer: PCE Instruments
Test Instruments manufacturer
