Isolation Meter

At PCE Instruments you will find an isolation meter for a variety of ranges between 50 mega ohms and 2000 mega ohms. The portable manual isolation meter is used fordetermining insulation resistance, continuous current, alternating current and testing. With an isolation meter, measurements can be taken for different voltages, beginning with 100V up to 10,000V. Measurements meet the DIN VDE 0413 part 1 standard. The isolation meter comes with a test mechanism, clips, batteries and a carrying case. The isolation meter can be equipped for test laboratories if an optional DIN EN ISO is acquired.

Measurement of insulation in cables and motor coils is vitally important for the prevention of accidents and damage to installations and is obligatory according to most codes of conduct.

If you have any questions, please contact us at or +44 ( 0 ) 161 464902 0.

Isolation Meter PCE-IT 200

£ 162.00

Price excl. VAT &. delivery

Our compact isolation meter is perfect for measuring the insulation resistance of electrical devices and household appliances. With its ability to measure insulation resistance, AC voltage, low resistance, PI (polarization index) and DAR (dielectric absorption), the isolation meter is a versatile and reliable measuring tool for many application scenarios.

Insulation resistance up to 5.5 GΩ
Accuracy ±5% of Mw. ±3 digits (over100 kΩ)
Direct and alternating voltages 30 …600 V
Resistance 0 … 999 Ω
PI (polarization index)
DAR (dielectric absorption)
Power supply via battery or mains adapter

Isolation Meter PCE-IT55

£ 200.00

Price excl. VAT &. delivery

Isolation Meter for insulation resistance up to 2000 MΩ.

Measuring ranges AC voltage: 0 … 750V
Resolution AC voltage: 1V
Accuracy AC voltage: ± 1.2% ± 10 dgts
Complies with IEC1010-1, CAT III 1000V
Large display with backlight
Individual measurement and duration measurement

Isolation Meter PCE-IT100

£ 246.00

Price excl. VAT &. delivery

The Isolation Meter PCE-IT100 detects with auxiliary voltages of 125V, 250V, 500V and 1000V insulation resistors up to max. 4000 MΩ. Furthermore, the measurement of low-resistance resistors up to 400 Ω and a measurement function for alternating and also DC voltages is offered by this Isolation Meter.

AC voltage (40 … 400 Hz): 750V
DC voltage: 1000V
Resistance: 40 Ω / 400 Ω
Insulation resistance: 4 MΩ / 40 MΩ / 400 MΩ / 4000 MΩ
4 different test voltages up to 1 kV
Auto power-off function
Safety: EN 61010-1, CAT III 1000V

Isolation Meter PCE-IT 200-ICA incl. ISO calibration certificate

£ 335.00

Price excl. VAT &. delivery

Insulation resistance up to 5.5 GΩ
Accuracy ±5% of Mw. ±3 digits (over100 kΩ)
Direct and alternating voltages 30 …600 V
Resistance 0 … 999 Ω
PI (polarization index)
DAR (dielectric absorption)

Power supply via battery or mains adapter
incl. ISO calibration certificate

Isolation Meter PCE-ITM 20

£ 343.00

Price excl. VAT &. delivery

This isolation meter PCE-ITM 20 combines a versatile multimeter with an insulation tester. In addition to the usual measured quantities such as voltage, current and resistance, this isolation meter PCE-ITM 20 is also equipped with a frequency and capacitance measurement.

Automatic range selection
Capacitance measurement
Integrated isolation tester
Internal memory
To IEC 1010, CAT III 1000 V, CAT IV 600 V
Frequency measurement

Isolation Meter PCE-IT 120

£ 578.00

Price excl. VAT &. delivery

The Isolation Meter detects insulation resistance up to max. 8 GΩ (with auxiliary voltages of 250, 500 and 1000V). In addition, this Isolation Meter offers a measuring function for DC and AC voltages up to max. 950V DC and 700V AC as well as resistors up to max. 2 kΩ.

DC test voltage: 250/500 / 1000V
OLED display
Automatic polarity display
Automatic range selection
PI and DAR test
Degree of protection / standardization: IEC 1010-1, 700V CAT III

Isolation Meter PCE-IT413

£ 831.00

Price excl. VAT &. delivery

The Isolation Meter belongs to a series of highly accurate resistance devices that have a 6 digit display. These Isolation Meters have been developed specifically for technical service and for difficult measurement conditions.

For professionals
6 digit LCD
Measurements according to VDE 0413 part 1
Test tension up to 5,000V

Isolation Meter PCE-IT414

£ 984.00

Price excl. VAT &. delivery

The Isolation Meter belong to a series of highly accurate resistance devices that have a 6 digit display. These Isolation Meters have been developed specifically for technical service and for difficult measurement conditions.

For professionals
6 digit LCD
Measurements according to VDE 0413 part 1
Test tension up to 10,000V

Isolation Meter PCE-IT 150

£ 1,652.00

Price excl. VAT &. delivery

The isolation meter is for insulation measurements with a test voltage of up to 15 kV. The measuring range of 0 … 30 TΩ and other measuring functions make the tester versatile. With 4 quick selection buttons for common test voltages and the option of setting the voltage in 500 V steps. Pre-configured diagnostic tests, including (PI), dielectric absorption ratio (DAR) and a memory function for 200 measurements are integrated into the isolation meter.

Insulation resistance: 0 … 30 TΩ
Accuracy: ± (5% of Mw.+5 digits)
Test voltage: 500 V … 15 kV
Direct alternating voltage: 30 … 600 V
Accuracy: ± (2.0% v.Mw. +3 digits)
Polarisation index PI
Dielectric absorption ratio DAR
Memory and software
