PCE Instruments

Inspection Camera

Order no.: PCE-HDM 20
The inspection camera PCE-HDM 20 is a universal measuring instrument. The inspection camera PCE-HDM 20 allows a variety of measurement projects. This makes it easy to investigate current, voltage, capacitance, frequency and resistances.

- Thermal imager function
- DC voltage
- AC voltage (TRMS)
- DC and AC voltage (TRMS)
- Direct current
- Alternating current (TRMS)
- Coil current
- Diode test
- Resistance and continuity test
- Frequency
- Duty cycle
- Temperature (Thermoelement Type K)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-HDM 20-ICA
The Inspection Camera PCE-HDM 20-ICA is a universal measuring instrument. The inspection camera PCE-HDM 20-ICA allows a variety of measurement projects. This makes it easy to investigate current, voltage, capacitance, frequency and resistances.

- Thermal imager function
- DC voltage
- AC voltage (TRMS)
- DC and AC voltage (TRMS)
- Direct current
- Alternating current (TRMS)
- Coil current
- Diode test
- Resistance and continuity test
- Frequency
- Duty cycle
- Temperature (Thermoelement Type K)
- Incl. ISO calibration certificate (for multimeter function only)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 180

PCE-VE 180 is a rechargeable handheld pistol-grip borescope inspection camera with video recording and image capture functionality. Equipped with built-in LED lighting on the waterproof camera tip, the PCE-VE 180 inspection camera features a detachable remote control with integrated 3.5" LCD for easy viewing and navigation. The remote control communicates using radio transmission at 2.4 GHz.

- Semi-flexible gooseneck cable
- 1 m / 3.28 ft cable length
- 3.9 mm / .16 in cable diameter
- Includes detachable 4.5 mm / .18 in mirror, hook and magnet

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200

PCE-VE 200 is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.


- 4.5 mm / 0.18 in diameter, semi-rigid
- 1 m / 3.28 ft cable length
- 180° image rotation



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200-S

PCE-VE 200-S is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.


- 3.7 mm / 0.14 in diameter
- 1 m / 3.28 ft cable length
- 180° image rotation


Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200-S3

PCE-VE 200-S3 is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.


- 3.7 mm / 0.14 in diameter
- 3 m / 9.8 ft cable length
- 1600 x 1200 pixels JPEG image / 640 x 480 pixels AVI video



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-IVE 320

PCE-IVE 320 is a borescope, inspection camera, videoscope or industrial endoscope that comes with a rigid telescoping pole that extends up to 2.3 m (7.6 ft) in length (3 m / 9.8 ft long total with camera connection). Plus, the borescope has a 0.3 megapixel camera with a 23 mm (0.91 in) diameter flexible head with microphone and 12 white LEDs offering adjustable brightness. Includes wheel attachment for under vehicle inspection.


- Telescopic pole extends up to 2.3 m / 7.6 ft
   (3 m /9.8 ft long total with camera connection)

- 12.7 cm / 5" LCD monitor with 800 x 480 pixel resolution
- Video recording capability
- Accommodates SD memory cards from 2 ... 32 GB
- Spare battery to allow all day operation



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 390N

PCE-VE 390N is the ideal inspection camera snake for the analysis of buildings (walls, supports, eaves, gutters, attics, crawl spaces), plumbing (pipes, drains, sewers, wells) and heating, ventilation, air conditioning and refrigeration (HVACR) systems (ducts, furnaces, chimneys, boiler and condenser tubes). The IP68-rated cable of this inspection camera is waterproof and heavy duty, making the PCE-VE 390N well suited for use in tough environments like construction sites and industrial installations.


- Camera head diameter: 28 mm / 1.1"
- Camera cable length: 10 m / 32 ft 9"
- Interface: Mini-USB 1.1 and AV out
- Memory: 8 GB SD memory card (incl.)
- Especially suitable for chimneys, downpipes, ventilation ducts etc.

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 1000

PCE-VE 1000 is an industrial endoscope, borescope, videoscope or inspection camera display featuring an exceptionally large 7" high-resolution LCD screen for impressive on-screen viewing capabilities.


- Stores photos and saves videos with sound to the included 8 GB SD memory
  card (max. compatibility 32 GB) for quick and easy transfer to a computer
- 360° image rotation (in 90° steps)
- Digital zoom


Display only. Camera cables (from diam. 5.5 mm / 0.22 in, 2-way, 4-way articulation) are sold separately. See accessories to customize.



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 380N

PCE-VE 380N is a waterproof inspection camera, videoscope, endoscope or borescope with a handheld monitor that allows you to gain valuable visual insight into the inner workings of machines and other small spaces such as ventilation ducts, drainpipes and downpipes, sewer pipes, chimneys and more. This semi-flexible / semi-rigid waterproof inspection camera is ideal for a variety of industrial and trade applications. Images and videos can be stored directly on the device or on the included SD memory card.


- Diameter camera head: 28 mm / 1.1"
- Camera head waterproof
- Camera cable length: 30 m / 98 ft 5"
- SD memory card
- Bright LED lighting

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 370HR

PCE-VE 370HR is a four-way articulating inspection camera, industrial endoscope, borescope or videoscope for the non-destructive inspection (NDI) of hard-to-reach places. The waterproof camera head features 6 LED lights (4 front, 2 side) for optimal illumination. In addition, digital image magnification or zoom of up to 2 times is available, plus boost functionality for improved image quality in the dark.


- With boost function: better images in dark surroundings
- 2 additional side LEDs for better lighting
- Diameter: Ø 6 mm / 0.24"
- 4-way camera
- Memory: 8 GB SD memory card (incl.)
- Cable length: 1 m / 3ft 3"

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 50
The inspection camera PCE-VE 50 is a compact video endoscope for the visual inspection of difficult to access areas. The camera head of the inspection camera PCE-VE 50 on the semi-rigid cable transmits images directly to the LC display.

- Camera diameter: 8 mm
- Cable length: 770 mm
- Image sensor: 1/9 ", CMOS
- Effective pixels: 640 x 480 pixels
- Interface: Video connection via 3.5 mm jack
- Protection class: IP67 (camera hose only)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DHM 30
The Inspection Camera PCE-DHM 30 is a versatile, small and handy, table microscope. With the inspection camera, you do not need any accessories, as this has a direct LCD display, which shows the enlarged image live in high resolution.

- File formats: JPG/BMP/AVI
- Optical lenses dimension: 1 / 6.5 "
- Image resolution: VGA 1.3 M, 2 M, 3 M
- Video resolution: 720p
- Software for Windows and MacOS
- Memory: Micro SD card
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TC 24
The Inspection Camera PCE-TC 24 is a picture-in-picture thermal camera. This inspection camera measures the temperature between -20 and 380 °C without contact. The inspection camera is suitable for fast and simple temperature measurements in the house, switch cabinets etc.

- Measuring range: -20 ... 380 °C
- Field of view: 32 x 32 °
- Frame rate: 9 Hz
- Picture-in-Picture function
- Micro-SD card memory
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 250
The Inspection Camera PCE-VE 250 is a diagnostic tool with integrated cleaning function. This makes the Inspection Camera PCE-VE 250 ideal for use on machine components. The cleaning can be done either with compressed air or compressed air in conjunction with water and or detergents.


- Videoscope with cleaning function
- Diameter camera head: 8.5 mm / 0.33 in
- Cable length: ca. 90 cm / 2ft 11 in
- 3.5" TFT LC-Display
- 4x optical zoom
- Viewing angle 60°
- 6 white, dimmable LEDs on the camera head
- Memory option on Micro SD card
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TC 25
The PCE-TC 25 inspection camera with built-in digital camera helps detect thermal problems in electrical installations, detect mechanical faults, perform preventive maintenance and save energy.

- Measuring range: -20 ... 380 °C
- Measures e.g. dew point & humidity
- Field of view: 32 x 32 °
- Frame rate: 9 Hz
- Picture-in-picture function
- Micro-SD card memory
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200SV1

The PCE-VE 200SV1 inspection camera is a nondestructive inspection camera. Thus, the PCE-VE 200SV1 inspection camera is the ideal instrument for diagnosing hard-to-reach areas. Thus, the areas of mechanical engineering, sanitary and heating construction, and the entire construction and construction industry are among the main applications of the inspection camera PCE-VE 200SV1.

- Camera head diameter 9 mm / 0.4 in
- Cable length: 1 m / 3.3 ft
- Interface: Micro USB 2.0
- Memory: Micro SD card
- Front and side view camera

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200SV3

The inspection camera PCE-VE 200SV3 is a nondestructive inspection camera. Thus, the inspection camera PCE-VE 200SV3 is the ideal instrument for diagnosis in hard-to-reach places. For example, the areas of mechanical engineering, sanitary and heating engineering, and the entire construction and construction industry are among the main areas of application of the inspection camera PCE-VE 200SV3.

- Camera head diameter 9 mm / 0.4 in
- Cable length: 3 m / 9.9 ft
- Interface: Micro USB 2.0
- Memory: Micro SD card
- Front and side view camera

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 300-H

The inspection camera PCE-VE 300-H is the optimum for experts and development engineers. Choose between many different cables for the inspection camera. This inspection camera not only gives you an optical insight into the inner workings of machines and systems without first disassembling them, it also allows images and video sequences of the components to be inspected to be stored directly in the device. The optimal tool for inspection of industrial machinery and equipment.


- Various videoscope cables selectable
- Interfaces: mini-USB 1.1 and AV out
- Memory: 8 GB SD memory card (incl.)

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-RS 40

Rigid Inspection Camera for visual inspection in small and narrow holes and cavities. With a diameter of 4 mm and a length of 175 or 432 mm / 6.9 or 17 in this rigid Inspection Camera is very versatile. The integrated LED lamp allows for a very good illumination of cavities to be inspected.


- Diameter only 4 mm / 0.16 in
- Useful length 175 or 432 mm / 6.9 or 17 in
- LED lighting
- Battery operation



Manufacturer: PCE Instruments
Test Instruments manufacturer
