PCE Instruments

Condition Monitoring

Order no.: PCE-VM 31-HA

The PCE-VM 31-HA Condition Monitoring Human Vibration Meter is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.


- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support
- Includes hand-arm sensor only - whole-body sensor sold separately (see
  accessories)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 31-WB

The PCE-VM 31-WB Condition Monitoring Human Vibration Meter or Analyzer is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.


- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support
- Includes whole-body sensor only - hand-arm sensor sold separately (see
  accessories)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 31-HAWB

The PCE-VM 31-HAWB Condition Monitoring Human Vibration Meter is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631. Each sensor consists of a triaxial Vibration Meter that captures acceleration, velocity, and displacement measurements.


- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VMS 504

The wireless PCE-VMS 504 Vibration Monitor detects vibration within an acceleration range of up to 30 g and a frequency range between 5 and 10 KHz. The wireless vibration monitor therefore features external vibration sensors, which measures vibrations at machines to transfer those wireless to a receiving unit.


- Acceleration range: up to 300 m/s2
- Wireless communication via ZigBee
- Frequency range between 5 Hz and 10 kHz
- Wireless transferring Piezo sensors
- Data memory (receiving base) 128 MB



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-LES 300
The Condition Monitoring Tachometer PCE-LES 300 is equipped with 9 high-power LEDs that generate a light intensity of 5100 lux at 6000 FPM at a distance of 20 cm / 7.9 in. This allows the PCE-LES 300 condition monitoring tachometer / stroboscope to provide a large and bright area of illumination.

- Flash frequency up to 120000 FPM
- Accuracy: ± 0.01%
- Adjustable deceleration time
- 9 high-power LEDs
- Phase shift
- Includes factory calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 800

PCE-VE 800 is a handheld articulating condition monitoring borescope inspection camera with video recording and image capture functionality. Equipped with adjustable built-in LED lighting on the waterproof camera tip, the PCE-VE 800 condition monitoring  inspection camera features a high interpolated resolution of 200,000 pixels and a large integrated 4.3" LCD for easy viewing and navigation.



- Semi-flexible cable with 4-way articulating tip
- 1.5 m / 4.9 ft cable length
- 2.8 mm / 0.11 in cable diameter

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T237

The condition monitoring tachometer can be used contactless or with mechanical contact. The PCE-T237 condition monitoring tachometer is particularly suitable for recording rotational speeds and speeds on rotating machines and systems (on conveyor belts, motors, belt drives, etc.).


- Contact measurement of rpm via cone adapter
- Contact measurement of m / min via surface wheel
- Robust ABS plastic housing
- Meter count: 0.1 ... 199,999 m



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T 260
The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope function, the condition monitoring tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 2700

PCE-VT 2700 is a factory-calibrated (certificate included) handheld portable digital battery-powered condition monitoring vibration meter used to measure the radial and axial vibration of industrial machines, equipment and parts such as bearings and gearboxes.


- Frequency range: 9 Hz ... 1 kHz (in 1 kHz mode) / 9 Hz ... 10 kHz
  (in 10 kHz mode) acceleration; 10 Hz ... 1 kHz velocity /
  displacement
- Resolution: 0.1 m/s2 / 0.1 yd/s2; 0.1 mm/s / 0.003 in/s ; 1 µm /
  3.3814e-14 oz ; 1 rpm
- Accuracy: ± 5% of reading + 2 digits
- Factory calibration certificate included

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 2700S

PCE-VT 2700S is a factory-calibrated (certificate included) portable digital battery-powered handheld condition monitoring vibration meter used to measure the radial and axial vibration of industrial machines, equipment and parts such as bearings and gearboxes. The PCE-VT 2700S comes with a special attachment to adapt the probe for handheld use.


- Frequency range: 9 Hz ... 1 kHz (in 1 kHz mode) / 9 Hz ... 10 kHz
  (in 10 kHz mode) acceleration; 10 Hz ... 1 kHz velocity /
  displacement
- Resolution: 0.1 m/s? / 0.1 yd/s?; 0.1 mm/s / 0.003 in/s ; 1 µm /
  3.3814e-14 oz ; 1 rpm
- Accuracy: ± 5% of reading + 2 digits
- ISO calibration certificate included



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 63

PCE-DT 63 is a condition monitoring digital handheld optical tachometer, or rotation meter, that can take noncontact measurements of rotational speed. This handheld condition monitoring tachometer features an integrated laser and is ideal for measuring rotational speeds of machines, motors, conveyor belts and other moving parts.


- Measuring range / Resolution: 50 ... 99.99 rpm / 0.01 rpm, 100 ... 9999.9 rpm
  / 0.1 rpm, 10000 ... 99999 rpm / 1 rpm

- Accuracy: ± 0.03% ± 2 digits
- Measuring distance: 50 ... 250 mm / 1.97 ... 9.84 in



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TH 5

The Condition Monitoring Thermo Hygrometer PCE-TH 5 is a universal temperature / humidity gauge which allows the measurement of both the ambient temperature and the ambient humidity, as well as the determination of the dew point and wet bulb temperature.


- Temperature measuring range: -20 ... 50°C / -4 ... 122°F
- Humidity measuring range: 0 ... 99.9% r.H.
- Resolution: 0.1°C / 0.18°F, 0.1% relative humidity
- Measurement accuracy: ±3% r.H. / ±0.6°C / 1.08°F
- Calculation of dew point and wet bulb temperature



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PI1

This Condition Monitoring Phase Rotation Meter PCE-PI1 has a robust housing with a large LCD display so you can easily and conveniently determine the phase and motor rotation direction. Furthermore, any problems in individual phases, are displayed on the phase rotation meter. The condition monitoring phase rotation meter meets the safety standard CAT III 600 V, IEC 61010.


- Easy operation
- No batteries required
- Robust alligator clips for easy connection
- 3-phase measurements of 40 ... 690 V AC
- Protection class IP 40



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 66

PCE-DT 66 is a condition monitoring portable, digital, handheld tachometer, or rotation meter, that can take measurements of rotational speed. This condition monitoring handheld tachometer features mechanical attachments and is ideal for measuring rotational speeds of machines, motors, conveyor belts and other moving parts.


- For taking measurements in contact with moving parts
- Measuring range: 50 ... 19999 RPM
- Accuracy: ± 0.03% / ± 2 digits



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-IR 100

PCE-IR 100 is both a infrared non-contact thermometer for measuring surface temperature and a contact thermometer with probe for measuring core temperature of food. This food-grade condition monitoring thermometer allows for quick and easy testing of food surface temperatures without contamination using the infrared sensor, while also offering the possibility of testing food internal temperatures using the food-quality sensor probe.


- Infrared temperature range: -33 ... 220ºC / -27 ... 428ºF
- Probe temperature range: -55 ... 330ºC / -67 ... 626ºF
- Resolution: 0.2ºC / 0.36ºF
- IP 65 ingress protection rating allows hygienic cleaning



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-428-KIT

PCE-428-KIT is a class 2 data-logging condition monitoring noise meter kit that meets IEC 60651:1979, IEC 60804:2000, IEC 61672-1:2013, ANSI S1.4-1983 and ANSI S1.43-1997 requirements. This portable high-accuracy sound level meter has a large easy-to-read illuminated LCD screen that displays the sound pressure level (SPL) numerically and graphically in real time.

- Measuring range: 25 ... 136 db(A)
- A, B, C and Z frequency weightings
- Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
- Adjustable data-recording interval from 1 s ... 24 h
- 1/1 octave band filter (optional 1/3 octave band filter upgrade)
- Kit includes factory calibration certificates (per ISO 9001) and a type 2 / class 2 acoustic calibrator (PCE-SC 42)

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-S 41

The PCE-S 41 Condition Monitoring Stethoscope is battery powered and easy to use. This Condition Monitoring Stethoscope can be used for detecting noise in machine components, such as gears, valves, vents, and pumps.


- Frequency range: 100 Hz to 10 kHz
- Headphones, 70 mm long sensor, 290 mm long sensor
- Weight: 240 g, with battery
- Dimensions: 206 x 50 x 32 mm



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T236

PCE-T236 is a digital handheld tachometer or rotation meter for both contact and non-contact measurement. This condition monitoring tachometer measures rotation speed as well as linear or surface speed, displaying units in rpm, m/min or ft/min. A unique feature of this tachometer is that the orientation of the 5-digit LCD screen automatically rotates 180° to accommodate either contact or non-contact measurement.


- Optical laser measurement range: 5 ... 99999 rpm
- Contact measurement range: 0.05 ... 19999 rpm
- Accuracy: Less than 60000 rpm = ±0.05% fs , Greater than 60000 rpm = ±0.15%
  fs



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-779N

The Condition Monitoring Thermometer PCE-779N measures temperatures quickly and without contact. The PCE-779N can be used for almost all surfaces. The emissivity of the infrared thermometer is adjustable over the range of 0.1 ... 1.0. The infrared thermometer has various measurement functions such as max, min and average measurement.


- OLED-Display
- Measuring range: -60 ... 760°C / -76 ... 1400°F
- Additional thermocouple measurement -64 ... 1400°C / -83.2 ... 2552°F
- Dual Laser
- Resolution: 0.1°C / 0.18°F at -83.2 ... 999.9°C (-117.8 ... 1831.8°F), otherwise 1°C / 1.8°F



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VD 3

The PCE-VD 3 Vibration Meter is a miniaturized universal Vibration Meter with an included built-in three-axes acceleration sensor (X, Y, Z axis). The internal sensor of the PCE-VD 3 Vibration Meter measures acceleration force along the X, Y, and Z axes with a measurement range of ±18 g per axis. Especially made for use in machine condition monitoring.


- 3-axis vibration data logging
- Software included -USB port
- Light weight
- Stand included
- Storage capacity: 4 Mbit (85764 records)
- Magnetic wall mount



Manufacturer: PCE Instruments
Test Instruments manufacturer
