Condition Monitoring

The PCE-VT 1100S condition monitoring vibration meter is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this condition monitoring vibration meter is used for rapid measurement of imbalance and for checking bearing and gear conditions.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Portable and battery operated
- Needle probe: 45mm / 1.77"

The PCE-VM 31-HA Condition Monitoring Human Vibration Meter is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.

- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support
- Includes hand-arm sensor only - whole-body sensor sold separately (see
  accessories)



The PCE-VM 31-WB Condition Monitoring Human Vibration Meter or Analyzer is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.

- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support
- Includes whole-body sensor only - hand-arm sensor sold separately (see
  accessories)



The PCE-VM 31-HAWB Condition Monitoring Human Vibration Meter is designed for measuring human vibration at the workplace. The Condition Monitoring Vibration Meter can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631. Each sensor consists of a triaxial Vibration Meter that captures acceleration, velocity, and displacement measurements.

- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support



The wireless PCE-VMS 501 Vibration Sensor detects vibration within an acceleration range of up to 30 g and a frequency range between 5 and 10 KHz. The wireless vibration sensors, which measures vibrations at machines to transfer those wireless vibrations to a receiving unit.

- Acceleration range: up to 300 m/s²
- Wireless communication via ZigBee
- Frequency range between 5 Hz and 10 kHz
- Wireless transferring Piezo sensors
- Transmission rate of 1 minute per sensor



The wireless PCE-VMS 504 Vibration Monitor detects vibration within an acceleration range of up to 30 g and a frequency range between 5 and 10 KHz. The wireless vibration monitor therefore features external vibration sensors, which measures vibrations at machines to transfer those wireless to a receiving unit.

- Acceleration range: up to 300 m/s²
- Wireless communication via ZigBee
- Frequency range between 5 Hz and 10 kHz
- Wireless transferring Piezo sensors
- Data memory (receiving base) 128 MB



The PCE-428-KIT-ICA class 2 data-logging condition monitoring noise meter kit is commonly used by professionals to ensure compliance with environmental noise regulations and workplace noise permissible exposure limits. The condition monitoring noise meter kit also functions as a data logger, recording measurements at an adjustable interval from 1 s ... 24 h and storing the recorded measurement data to a micro SD card memory. Alternatively, the sound level meter can be connected directly to a PC via USB.

- Class 2
- Measuring range: 25 ... 136 db(A)
- LXY (SPL), Leq (LXeq), LXYSD, LXSEL, LXE, LXYmax, LXYmin, LXPeak, LXN
- Frequency weighting: A, B, C and Z
- Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
- adjustable data-recording interval from 1 s ... 24 h
- 1/1 octave band filter (optional 1/3 octave band filter upgrade)
- Kit includes type 2 / class 2 acoustic calibrator (PCE-SC 42)
- incl. ISO Calibration Certificate for PCE-428 and ISO Calibration Certificate for PCE-SC 42

The condition monitoring tachometer can be used contactless or with mechanical contact. The PCE-T237 condition monitoring tachometer is particularly suitable for recording rotational speeds and speeds on rotating machines and systems (on conveyor belts, motors, belt drives, etc.).

- Contact measurement of rpm via cone adapter
- Contact measurement of m / min via surface wheel
- Robust ABS plastic housing
- Meter count: 0.1 ... 199,999 m



The condition monitoring tachometer can be used contactless or with mechanical contact. The PCE-T237 condition monitoring tachometer is particularly suitable for recording rotational speeds and speeds on rotating machines and systems (on conveyor belts, motors, belt drives, etc.).

- Contact measurement of rpm via cone adapter
- Contact measurement of m / min via surface wheel
- Robust ABS plastic housing
- Meter count: 0.1 ... 199,999 m
- Incl. ISO calibration certificate

The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope function, the condition monitoring tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared

The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope function, the condition monitoring tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared
- LED Flash frequency: 100 ... 99990 FPM
- Temperature measurement: Type K, PT 1000
- Infrared
- Incl. ISO calibration certificate (only for the tachometer function)

The Condition Monitoring Thermo Hygrometer PCE-TH 5 is a universal temperature / humidity gauge which allows the measurement of both the ambient temperature and the ambient humidity, as well as the determination of the dew point and wet bulb temperature.

- Temperature measuring range: -20 ... 50°C / -4 ... 122°F
- Humidity measuring range: 0 ... 99.9% r.H.
- Resolution: 0.1°C / 0.18°F, 0.1% relative humidity
- Measurement accuracy: ±3% r.H. / ±0.6°C / 1.08°F
- Calculation of dew point and wet bulb temperature



This Condition Monitoring Phase Rotation Meter PCE-PI1 has a robust housing with a large LCD display so you can easily and conveniently determine the phase and motor rotation direction. Furthermore, any problems in individual phases, are displayed on the phase rotation meter. The condition monitoring phase rotation meter meets the safety standard CAT III 600 V, IEC 61010.

- Easy operation
- No batteries required
- Robust alligator clips for easy connection
- 3-phase measurements of 40 ... 690 V AC
- Protection class IP 40



PCE-DT 66 is a condition monitoring portable, digital, handheld tachometer, or rotation meter, that can take measurements of rotational speed. This condition monitoring handheld tachometer features mechanical attachments and is ideal for measuring rotational speeds of machines, motors, conveyor belts and other moving parts.

- For taking measurements in contact with moving parts
- Measuring range: 50 ... 19999 RPM
- Accuracy: ± 0.03% / ± 2 digits



PCE-DT 66 is a condition monitoring portable, digital, handheld tachometer, or rotation meter, that can take measurements of rotational speed. This condition monitoring handheld tachometer features mechanical attachments and is ideal for measuring rotational speeds of machines, motors, conveyor belts and other moving parts.

- For taking measurements in contact with moving parts
- Measuring range: 50 ... 19999 RPM
- Accuracy: ± 0.03% / ± 2 digits
- Incl. ISO calibration certificate

PCE-IR 100 is both a infrared non-contact thermometer for measuring surface temperature and a contact thermometer with probe for measuring core temperature of food. This food-grade condition monitoring thermometer allows for quick and easy testing of food surface temperatures without contamination using the infrared sensor, while also offering the possibility of testing food internal temperatures using the food-quality sensor probe.

- Infrared temperature range: -33 ... 220ºC / -27 ... 428ºF
- Probe temperature range: -55 ... 330ºC / -67 ... 626ºF
- Resolution: 0.2ºC / 0.36ºF
- IP 65 ingress protection rating allows hygienic cleaning

PCE-IR 100-ICA incl. ISO calibration certificate is both a infrared non-contact thermometer for measuring surface temperature and a contact thermometer with probe for measuring core temperature of food. This food-grade condition monitoring thermometer allows for quick and easy testing of food surface temperatures without contamination using the infrared sensor, while also offering the possibility of testing food internal temperatures using the food-quality sensor probe.

- Infrared temperature range: -33 ... 220ºC / -27 ... 428ºF
- Probe temperature range: -55 ... 330ºC / -67 ... 626ºF
- Resolution: 0.2ºC / 0.36ºF
- IP 65 ingress protection rating allows hygienic cleaning
