PCE Instruments

Clamp on Tester

Order no.: PCE-GPA 62

Clamp on Tester with network Analyzer / Clamp on Tester with data logger. The Clamp on Tester (Graphic Power Quality Analyzer) PCE-GPA 62 is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50? of the harmonic waveform. As all test instruments, the Clamp on Tester is delivered manufacturer calibrated (ISO certification is available optional).


- Real-time test, register and measurement of voltage and current (real and effective)
- Measures power factor and phase angle, frequency, energy, active, reactive and apparent power
  (single-phase or three-phase in symmetrical networks).
- Max. conductor diameter: 55 mm / 2.2 in
- Records up to 50,000 records


Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GPA 62-ICA

This clamp on tester is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50º of the harmonic waveform. The clamp on tester is equipped with data logger. The test instrument is delivered manufacturer calibrated (ISO or certification as an option).


- Real-time test, register and measurement of voltage and current (real and effective)
- Measures power factor and phase angle, frequency, energy, active, reactive and apparent power
  (single-phase or three-phase in symmetrical networks).
- Max. conductor diameter: 55 mm / 2.2 in
- Datalogger for 50,000 readings / software/ USB interface
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-360-ICA

The PCE-360 is a clamp-on tester with data logger functionality. This versatile clamp-on tester can take single-phase and three-phase power measurements both in real time and over an extended time period.


- Voltage range: 50.0 V ... 600.0 V True RMS value
- Current range: 3.0 A ... 999.9 A True RMS value
- Includes clamps, clips, leads, PC software and data cable
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CM 3
The PCE-CM 3 clamp on tester is used for quick and easy AC measurements. For current measurement, the PCE-CM 3 clamp on tester is plugged over the live conductor. The clamp on tester PCE-CM 3 is particularly suitable for the measurement of alternating current in distributions and wherever circuits must not be interrupted.

- Digital Multimeters up to 200 A
- Compact dimensions
- Robust plastic housing
- Multimeter functions
- Safety conditions: IEC1010-1 (2001)
                             CAT II 1000V
                             CAT III 600V
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC1

Clamp on Tester for measuring AC current, AC voltage, DC current and frequency. The reduced dimensions of this device allow for measurements to be taken in places with limited access. The backlight display ensures that it is easy to read, even in places with limited light available, such as electrical cabinets or in cabling ducts. The Clamp on Tester (as all the test instruments) comes manufacturer calibrated - ISO certification is available as an option.


- AC current (50/60 Hz): 200 A / 0.1 A or 100-mA / ±3.0% + 8 digits
- DC current: 200 A / 100-mA / ±2.8% + 8 digits
- AC test voltage (without contact):100 VAC to 600 VAC at 50 /
  60 Hz
- Frequency (3 ranges): 40 to 50 Hz / 51 to 510 Hz / 0.51 to 1 kHz



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC2

Digital Clamp Meter for measuring AC/DC current, AC voltage and resistance. This clamp meter is designed to indirectly detect AC/DC current and ohms. The clamp has white LEDs which illuminate the point of measurement and test the voltage without contact. Small dimensions of this device allow to take measurements in places with limited access. The clamp meter comes manufacturer calibrated and can optionally be certified according to ISO or standards.


- AC / DC current, voltage and resistance measurement
- 3 2/3-digit LCD display
- Power supply: 2 x 1.5V AAA battery
- Dimensions: 164 x 65 x 32 mm / 6.4 x 2.5 x 1.2 in



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC3

Clamp on Tester to determine indirectly, the AC/DC currents with high accuracy.


- AC current (50 / 60 Hz): 2 A  / 1-mA / ± 2.8% + 10 dgt
- DC current: 2 A / 1-mA / ± 3.0% + 10 dgt
- AC overload protection: 100V AC up to 600V AC 50 / 60 Hz

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PCM 1

PCE-PCM 1 is a multipurpose clamp-on tester or power analyzer used to measure alternating current (AC), voltage (TRMS) and frequency to determine active (kW), apparent (kVA) and reactive (kVAR) power as well as active energy (kWh) consumption. Both the phase angle and the power factor (cos φ) are shown on the handheld power meter's large and easy-to-read backlit display.

- Voltage (50 ... 200 Hz): 100 / 400 / 750V, ± (1.2% + 5 digits)
- Internal memory: Stores up to 99 measurement values
- Includes USB cable and PC software
- Three-phase power measurement
- True RMS

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-LCT 1

Clamp on Tester PCE-LCT 1 to test leakage / RMS measurement / continuity and resistance test. The Clamp on Tester can measure leakage currents which appear when current flows through electrical conductors which are not designed for conduction current. The Clamp on Tester, as all test instruments, is delivered manufacturer calibrated, but can additionally be certified to ISO.


- Measures current up to 100 A
- Measures voltage up to 600 V
- Measures resistance up to 400 O
- Test cables are included



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC 41

The clamp on tester PCE-DC 41 can measure voltages up to 600 V, currents up to 600 A and electrical resistance up to 1000 Ω. To perform a measurement, you can either use the measuring leads, which are included in the package of the clamp on tester, or you can use the integrated clamp mechanism. By using the clamp of the clamp on tester, you are able to measure the electrical parameters of an electrical conductor contact-free and without disconnecting it.


- Voltage: 600 V AC/DC
- Current: 600 A AC/DC
- Electrical Resistance: 1000 Ω
- Clamp mechanism



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CM 3-ICA
The PCE-CM 3 clamp on tester is used for quick and easy AC measurements. For current measurement, the PCE-CM 3 clamp on tester is plugged over the live conductor. The clamp on tester PCE-CM 3 is particularly suitable for the measurement of alternating current in distributions and wherever circuits must not be interrupted.

- Digital Multimeters up to 200 A
- Compact dimensions
- Robust plastic housing
- Multimeter functions
- Safety conditions: IEC1010-1 (2001)
                             CAT II 1000V
                             CAT III 600V
- Incl. ISO Calibration Certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC1-ICA
This clamp on tester was developed for the indirect acquisition of AC / DC currents as well as the frequency. A non-contact voltage tester function and a flashlight for illuminating the measuring point were also integrated in this clamp on tester.

- AC / DC current, AC voltage and frequency measurement
- Integrated measuring point illumination
- Non-contact voltage tester
- Automatic range selection
- Forceps opening: 18 mm
- Automatic switch-off
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC2-ICA

Clamp on tester for measuring AC/DC current, AC voltage and resistance. This clamp on tester is designed to indirectly detect AC/DC current and ohms. The clamp on tester has white LEDs which illuminate the point of measurement and test the voltage without contact. Small dimensions of this device allow to take measurements in places with limited access. The clamp on tester comes manufacturer calibrated and can optionally be certified according to ISO or standards.


- AC / DC current, voltage and resistance measurement
- 3 2/3-digit LCD display
- Power supply: 2 x 1.5V AAA battery
- Dimensions: 164 x 65 x 32 mm / 6.4 x 2.5 x 1.2 in
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC3-ICA

Clamp on tester to determine indirectly, the AC/DC currents with high accuracy.


- AC current (50 / 60 Hz): 2 A  / 1-mA / ± 2.8% + 10 dgt
- DC current: 2 A / 1-mA / ± 3.0% + 10 dgt
- AC overload protection: 100V AC up to 600V AC 50 / 60 Hz
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-OCM 10
The clamp on tester PCE-OCM 10 is characterized by the OLED display. The OLED display on this clamp on tester allows the display itself to be read in the dark, as it is self-luminous.

- Measurable up to 600 A
- Clamp with multimeter functions
- OLED display
- NCV function
- TRMS AC A
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-LCT 1-ICA
With the PCE-LCT 1-ICA clamp on tester, it is possible to measure leakage currents in the range of up to 100A. Leakage occurs when a current flows through an electrical conductor that is not normally designed to conduct electricity. The PCE-LCT 1-ICA clamp on tester captures these currents and displays them on the display.

- Measurable electrical parameters: AC V, AC A, resistance
- Clamp diameter: 30 mm
- Operating temperature: -10 ... 50°C / 50 ... 122°F
- Current consumption: 10-mA
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DC 41-ICA

The clamp on tester PCE-DC 41 can measure voltages up to 600 V, currents up to 600 A and electrical resistance up to 1000 Ω. To perform a measurement, you can either use the measuring leads, which are included in the package of the clamp on tester, or you can use the integrated clamp mechanism. By using the clamp of the clamp on tester, you are able to measure the electrical parameters of an electrical conductor contact-free and without disconnecting it.


- Voltage: 600 V AC/DC
- Current: 600 A AC/DC
- Electrical Resistance: 1000 Ω
- Clamp mechanism
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PA 8000

With the PCE-PA 8000 Clamp on Tester you will be able to perform prolonged measurements of electrical properties. The measurement data is saved in xls format on the included SD card to be easily transferred to a computer or laptop for review. The Clamp on Tester comes manufacturer calibrated and can be certified to ISO or UTIL standards as an option.

- Display: 3.7 in / 94 mm LCD (320 x 240 pixels) with LED backlight
- Electrical properties: AC V, AC A, active power, apparent power, power factor, phase angle, power frequency
- Voltage ranges: 10 V ... 600 V AC, automatic range selection
- Measures current up to 1200 A
- Security / Standards: IEC1010CAT III 600V

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-360

The PCE-360 is a Clamp-On Tester with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.


- Voltage range: 50.0 V ... 600.0 V True RMS value
- Current range: 3.0 A ... 999.9 A True RMS value
- Includes clamps, clips, leads, PC software and data cable

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-830-1

The PCE-830 Clamp on Tester is used for measuring one to three phases of electrical quantities for alternating current (AC). This Clamp on Tester also measures parameters such as voltage, current, frequency, harmonics, and power as well as indicating, according to standard EN50160, harmonic values, interharmonics, and asymmetrics. Interference, such as interruptions, leaks, overloads, or transience (from 16 µs) are detected with their corresponding values. The power logging instrument is delivered manufacturer calibrated. An ISO calibration certificate may be ordered optionally.


- PCE-830 + PCE-6801 amp clamp (100 A)
- Electrical conductor pick-up: 30 mm / 1.1 in diameter
- Range selection: manual (1 A, 10 A, 100 A)
- Clamp dimensions: 210 mm x 62 mm x 36 mm / 8.2 in x 2.4 in x 1.4 in
- Sampling rate: 2 sec.
- Memory size: 512 kB (max. 52,000 values (single phase)

Manufacturer: PCE Instruments
Test Instruments manufacturer
