Order no.: CWG 1

Anemometer CWG 1

£ 356.00
£ 427.20
CWG 1
price ex. (VAT / delivery)
Cup vane
Up to 50 m/s
No
Yes (mA output)
Delivery time: 1-2 working days

Description

Compact anemometer with 4 … 20 mA output

Compact anemometer CWG 1 for weather monitoring. Basic cup anemometer with 4 … 20 mA output.

Highlights

- Basic cup anemometer
- Easy assembly
- 12 m / 39 ft connection cable
- 4 ... 20 mA output

Specification

Output4 … 20 mA
Measurement range0 … 50 m/s
Accuracy± 0.5 m/s or 3 % or measuring range
Loadmax. 80 m/s short-term
Load 500 Ohm at 15 V operating voltage
Power supply9 … 30 V AC / DC max. 50 mA
Assembly on mast tube
Heatingmax. 24 V DC/AC, max. 20 W
Ambient temperature  -25 … +60 °C /  -13 ... 140 °F (in ice-free conditions)
Cable12 m / 39 ft; LiYY 6 x 0.25 mm²
Protection classIP54
Weightapprox. 500g / 17. 6 oz
ApprovalUL

Delivery Scope

1 x Anemometer CWG 1
1 x Data Sheet

Downloads

Accessories

Accessories

- Wind Sensor
Dual Mounting Arm PCE-CW-T2
£ 102.00

Price excl. VAT &. delivery
2 year Warranty

The Dual Mounting Arm PCE-CW-T2 is used to mount one wind direction sensor CWR1 and one wind speed sensor CWG1. The cross-arm can be mounted on a mast using hose clamps.

  • Length: 80 cm / 31.5"
  • For CWR1 and CWG1
