£ 18.00
| Measuring range | to 60 microns thickness | |
| Number of teeth | 6 or 11 (depending on the version) | |
| Average distance | 1 ... 3 mm (depending on the version) | |
| Choosing the right cross-cut method | ||
| - Method A (X-cut) for testing to ASTM D 3359 with layer thickness> 125 µm | ||
| - Method B (crosshatch Cross) for testing to ISO 2409 with thickness 0 ... 250 µm and ASTM D 3359 with thickness <125 µm | ||
| Choosing the right cut distance (Method B) | ||
| To EN DIN ISO 2409 | ||
| Layer thickness | Substratum | Average distance |
| 0...60 µm | Hard | 1 mm |
| 0...60 µm | Soft | 2 mm |
| Approx. 60...120 µm | Hard or soft | 2 mm |
| Approx. 120...250 µm | Hard or soft | 3 mm |
| To ASTM D 3359 | ||
| Layer thickness | Average distance | |
| 0 ... 50 µm | 1 mm | |
| 50 ... 125 µm | 2 mm | |
