PCE Instruments

Adhesion Tester

Order no.: PCE-CRC 10
The Adhesion Tester PCE-CRC 10 is designed to determine the quality of the adhesion of coatings. The Adhesion Tester is suitable for thin, thick or tough coatings on all surfaces. Since the adherence of paintings and other coatings is a crucial product and quality characteristic for their protective effect, adhesion testers are used in a wide range of industries.



- Evaluation of adhesion
- For thin, thick or tough coatings
- Large, non-slip grip
- Various blades selectable



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TAT 10

The simple design and an absolutely straightforward operation make it possible for the practitioner to use the adhesion tester as an instrument for daily adhesion tests. Using adhesive with rapid curing, the tests can be performed by the user in the shortest possible time.


- Breakout force: 200 kg
- Diameter of base dolly, mm: 15.1 (№ 1) and 19.5 (№ 2)
- Specific breakout force, MPa: Dolly №1 up to 10 MPa (100) Dolly
  №2 up to 6 MPa (60)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PST 1

PCE-PST 1 adhesion tester is designed to check the adhesive force of edges and edge bands on support materials. With the adhesion tester, checks can be made with respect to the quality of workmanship. Feed speed, travel distance, tension, and traction angle are fixed. Ball transfer units on the guide surface of the Test Stand reduce the coefficient of friction. Likewise the self-locking jaws and smooth guide rollers always guarantee reproducible and comparable results.


- Measuring range: 500 N / 50 kg / 110 lbs
- Measurable edge thickness: 0.4 mm ... 3.5 mm
- Measurable thicknesses: 10 mm ... 64 mm
- Velocity: 0.3 m / min



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PST 1

PCE-PST 1 adhesion tester is designed to check the adhesive force of edges and edge bands on support materials. With the adhesion tester, checks can be made with respect to the quality of workmanship. Feed speed, travel distance, tension, and traction angle are fixed. Ball transfer units on the guide surface of the Test Stand reduce the coefficient of friction. Likewise the self-locking jaws and smooth guide rollers always guarantee reproducible and comparable results.


- Measuring range: 500 N / 50 kg / 110 lbs
- Measurable edge thickness: 0.4 mm ... 3.5 mm
- Measurable thicknesses: 10 mm ... 64 mm
- Velocity: 0.3 m/min



Manufacturer: PCE Instruments
Test Instruments manufacturer
