Sound Level Meter / Noise Level Meter

A sound level meter is a measuring instrument used to assess noise or sound levels by measuring sound pressure. Sound Level Meter Often referred to as a sound pressure level (SPL) meter, decibel (dB) meter, noise meter or noise dosimeter, a sound level meter uses a microphone to capture sound. The sound is then evaluated within the device and acoustic measurement values are displayed. The most common unit of acoustic measurement for sound is the decibel (dB); however, some sound level meter devices also determine the equivalent continuous sound level (Leq) and other acoustic parameters. With a portable sound level meter, industrial hygiene and workplace safety professionals can measure sound levels in multiple locations to ensure environmental conditions fall within recommended exposure limits (RELs). Some sound level meter devices can be permanently installed for continuous monitoring of sound levels at a work or job site.

Sound Level Meter PCE-SDL 1 detects noise levels of 30 ... 130 dBSound Level Meter with data-logging functionalityCombination environmental meter and auto-ranging sound level meter



An important attribute to consider when searching for a suitable sound level meter is its type or class. The type or class of a sound level meter defines the device's accuracy as per American National Standards Institute (ANSI) or International Electrotechnical Commission (IEC) guidelines. Typically, "type" is the grade according to the ANSI S1.4 standard, whereas "class" is the grade according to the IEC 61672 standard. There are two types or classes assigned to sound level meters: type 1 / class 1 or type 2 / class 2. For assessing noise in basic industrial, commercial, educational, recreational or residential applications, a type 2 / class 2 sound level meter usually will suffice. For precision-grade assessments often made in a laboratory, a type 1 / class 1 sound level meter primarily is used.

Video: Wolfgang Rudolph shows us all about a sound level meter.


Watch sound level meter video!


PCE-branded sound level meter products are lightweight, easy-to-use and manufactured in accordance with the highest industrial standards. Should you require assistance determining which sound level meter will best meet the needs of your application, please don't hesitate to contact us at info@industrial-needs.com or +44 (0) 2380 987 035 for PCE Instruments UK , or info@pce-americas.com or +1 (561) 320-9162 for PCE Americas Inc.

Application notes / Brochures

Sound Level Meter Catalog

Catalog
View a PDF from our print catalog to learn more about our sound level meter
products...Sound Level Meter catalog

How to Use a Sound Level Meter

How to Use
Learn more about how to use a sound
level meter...Sound Level Meter How-To

Sound Level Meter for Environmental Noise

Environment
Environmental noise is a combination of different sources and a sound level
meter...Sound Level Meter for Environmental Noise

Sound Level Meter Application

Application
Excessive noise in a work environment can have
dangerous results...Sound Level Meter in the Workplace



Sound Level Meter in Construction

Construction Noise
Almost all of us are familiar with noise coming from the near-by
sites ...Sound Level Meter for Construction Noise

Sound Level Meter for Entertainment Noise

Entertainment Noise
To monitor noise levels in entertainment venues, sound level meters
are ...Sound Level Meter Entertainment Venue Use

Sound Level Meter for Traffic Noise

Traffic Noise - General
Noise caused by traffic can be a serious problem.
Especially in big cities where...Sound Level Meter for Traffic Noise Measurement

Sound Level Meter Catalog

Traffic Noise - Germany
Nowadays, road traffic is the strongest source of noise pollution in industrialized
countries such as the...Sound Level Meter catalog





Multifunction Sound Level Meter PCE-EM 886
Order no.: PCE-EM 886
PCE-EM 886 is a portable handheld multifunctional digital device used to measure sound, light, humidity, temperature, AC / DC current, electrical resistance, capacitance and frequency.

- Sound: 35 ...100 dB
- Light: 4,000 ... 40,000 lux
- Humidity: 33 ... 99% RH
- Temperature: 0 ... 50 °C Indoor / -20 ... 1300 ºC Type K
- Auto-ranging electrical multimeter
Manufacturer: PCE Instruments
£ 60.00
Price excl. VAT &. delivery

Multifunction Sound Level Meter PCE-EM 882
Order no.: PCE-EM 882

PCE-EM 882 is a portable, handheld, multifunctional digital device capable of measuring four different physical parameters. An ideal tool for use in industrial hygiene, HVAC performance assessment and environmental condition monitoring applications, this easy-to-use measuring instrument includes sensors for measuring sound, light, temperature and relative humidity.

- Sound: Low and high A- and C-weighted noise measurements from 35 ... 130 dB
- Light: 20, 200, 2000, 20000 lux ranges
- Temperature: Range from -20 ... +750 ºC / -4 ... +1400 ºF
- Relative humidity (RH): Range from 25 ...95% RH

Manufacturer: PCE Instruments
£ 64.00
Price excl. VAT &. delivery

Sound Level Meter PCE-SDL 1
Order no.: PCE-SDL 1
PCE-SDL 1 is a class II (type 2) data-logging sound level meter, sound pressure level (SPL) meter, noise meter or decibel (dB) meter used for long-term acoustic measurements.

- Measuring range: 30 ... 130 dB
- Accuracy: ± 1.4 dB
- Frequency: 31.5 Hz ... 8 kHz
- Frequency weighting: A and C
- Memory: Stores up to 129,920 data sets
- Includes USB interface and Windows-compatible software for data transfer to PC
Manufacturer: PCE Instruments
£ 85.00
Price excl. VAT &. delivery

Sound Level Meter PCE-353
Order no.: PCE-353
PCE-353 is a sound level meter, sound pressure level (SPL) meter, decibel (dB) meter, noise meter or noise dose meter used for acoustic measurements. With this meter, you are able to measure sound exposure level (SEL) as well as equivalent continuous sound level (Leq).

- Measuring range: 30 ... 130 dB
- Measurement parameters: Lp, Lmax, Leq, LN
- Resolution: 0.1 dB
- Accuracy: ±1 dB
- Frequency: 20 Hz ... 12.5 kHz
- Frequency weighting: A, C, F (Flat)
- Memory: Stores up to 30 groups with measuring conditions
Manufacturer: PCE Instruments
£ 86.00
Price excl. VAT &. delivery

Sound Level Meter Calibrator PCE-SC 42
Order no.: PCE-SC 42
PCE-SC 42 is an acoustic or sound calibrator used to calibrate sound level meters, microphones and noise measuring devices and equipment. Suitable for use with type 2 or class II SPL meters, this portable decibel (db) meter calibrator is easy to use in the field or the laboratory.

- Frequency: 1 kHz / ± 0.1 %
- Sound pressure levels: 94 dB and 114 dB
- Accuracy: ± 0.3 dB (at 20 °C / 68 °F and 760 mm Hg / 101325 Pa)
Manufacturer: PCE Instruments
£ 117.00
Price excl. VAT &. delivery

Sound Level Meter PCE-322A
Order no.: PCE-322A
PCE-322A is a professional class II sound level meter for the measurement of noise pollution levels in industrial, commercial, and educational environments. The recorded decibel readings helps users determine if and what protective measures need to be taken to ensure overall health, safety and productivity in various occupational settings.

- Automatic range: 30 to 130 dB
- Resolution: 0.1 dB
- Accuracy: ±1.4 dB
- Memory: 32,700 readings
- Sampling rate: 2 per sec.
- ISO calibration available as an option
Manufacturer: PCE Instruments
£ 120.00
Price excl. VAT &. delivery

Sound Level Meter PCE-318
Order no.: PCE-318
PCE-318 is a portable handheld class II (type 2) noise, sound level or sound pressure level (SPL) meter used for measuring sound in decibels (dB).

- Acoustic measuring range: 30 ... 130 dB
- 6 level ranges in 10 dB steps: 20 ... 80 dB, 30 ... 90 dB, 40 ... 100 dB, 50 ... 110 dB, 60 ... 120 dB, and 70 ... 130 dB
- Resolution: 0.1 dB
- Accuracy: ± 1.0 dB (ref. 94 dB at 1 kHz)
- Frequency range: 31.5 Hz ... 8 kHz
- Frequency weighting: A and C
- Memory: Stores up to 99 readings
Manufacturer: PCE Instruments
£ 194.00
Price excl. VAT &. delivery

Sound Level Meter with Calibrator PCE-322-SC42
Order no.: PCE-322-SC42
PCE-322 A is a professional class II sound level meter for the measurement of noise pollution levels in industrial, commercial and educational environments. The recorded decibel readings helps users determine if and what protective measures need to be taken to ensure overall health, safety and productivity in various occupational settings. This meter comes with an acoustic calibrator.

- Supplied with acoustic calibrator
- Automatic range: 30 to 130 dB
- Resolution: 0.1 dB
- Accuracy: ±1.4 dB
- Memory: 32,700 readings
- ISO lab calibration available as an option
- Sound meter class: 2
Manufacturer: PCE Instruments
£ 213.00
Price excl. VAT &. delivery

Sound Level Meter PCE-NDL 10
Order no.: PCE-NDL 10
PCE-NDL 10 is a high-quality sound level meter with data logging capabilities. This noise dosimeter records sound pressure level (SPL) measurements as well as dosimetry (dose) measurements in decibels (dB) and saves the measurement data to the internal memory or an SD card (SD card included).

- Measuring range: 30 ... 130 dB (SPL) / 70 ... 130 dB (dose)
- Accuracy: ± 3.5 dB (31.5 Hz) ... ± 5.6 dB (8000 Hz)
- Data logging: Manual or adjustable automatic
- Sampling rate: Approx. 1 second
- Frequency weighting: A and C
Manufacturer: PCE Instruments
£ 340.00
Price excl. VAT &. delivery

Sound Level Meter Kit PCE-EV-KIT 3
Order no.: PCE-EV-KIT 3
This sound level meter kit includes gauges for demanding applications with advanced functionality. The sound level meter kit has been specially formulated to meet all requirements with regard to the assessment of the environment. With these devices, the recorded values are saved and can then be evaluated on a PC or laptop.

The sound level meter meter kit consists of the following devices:

- P1 / PCE-322A
- P2 / PCE-890U
- P3 / PCE-174
- P4 / PCE-330
Manufacturer: PCE Instruments
£ 482.00
Price excl. VAT &. delivery

Sound Level Meter PCE-MSV 10
Order no.: PCE-MSV 10
In loud environments, it is often difficult to pinpoint the source of a sound. The easy-to-operate PCE-MSV 10 sound level meter visualizes sound in real time, creating a visual road map to a sound’s source. Also referred to as a noise meter, sound pressure meter, portable sound camera or sound level camera, the PCE-MSV 10 sound level meter can be used in various stages of machine and equipment design, manufacture and operation, from engineering research and development (R&D) to preventative maintenance and beyond. Lightweight and compact, the PCE-MSV 10 portable sound level meter features:


- Measurement range of 30 … 130 dBA
- Frequency range of 20 … 20000 Hz
- Real-time image and video recording
Manufacturer: ACB Engineering
£ 4,215.00
Price excl. VAT &. delivery

Sound Level Meter MS 85
Order no.: 5020-0885
The mini sound level meter MS 85 characterizes itself through simple one-handed use. Just turn the mini sound level meter on, point it toward the noise source and read the value on the display. This portable, handheld instrument can be used to measure noise or sound levels in the industrial, commercial or residential settings.

- Measuring range: 40 ... 130 dB
- Frequency range: 31.5 Hz ... 8 kHz
- Frequency weighting: A
- Resolution: 0.1 dB
- Accuracy: ± 3.5 dB at 1 kHz, 94 dB (under reference conditions)
Manufacturer: PCE Instruments
£ 30.00
Price excl. VAT &. delivery

Sound Level Meter SLT-TRM
Order no.: SLT-TRM
SLT-TRM is a class II (type 2) sound level, sound pressure level (SPL), decibel (dB) or noise meter with audible or visual alarm output capability. SLT-TRM is used for long-term, continuous monitoring of occupational noise exposure limits in industrial environments.

- Measuring range: 0 ... 130 dB in 3 ranges
- Resolution: 0.1 dB
- Accuracy: ± 1.5 dB
- IP 54 ingress protection rating on transmitter
Manufacturer: PCE Instruments
£ 168.00
Price excl. VAT &. delivery

Sound Level Meter SLT
Order no.: SLT
SLT is a class II (type 2) sound level, sound pressure level (SPL), decibel (dB) or noise meter with audible or visual alarm output capability. SLT is used for long-term, continuous monitoring of occupational noise exposure limits in industrial environments.

- Measuring range: 0 ... 130 dB in 3 ranges
- Resolution: 0.1 dB
- Accuracy: ± 1.5 dB
- IP 54 ingress protection rating on transmitter
- Includes digital indicator with IP 65 rating
Manufacturer: PCE Instruments
£ 254.00
Price excl. VAT &. delivery

Sound Level Meter SP-DL-2
Order no.: SP-DL-2
SP-DL-2 is a portable handheld Class 2 / Class II datalogging sound level meter, decibel meter or sound pressure level (SPL) meter designed for easy monitoring, documentation and analysis of noise exposures.

- Removable SD card memory
- Measuring range: 0 ... 140 dB
- Frequency weighting: A, C, F, Z
- Broadband sound (SLM) measurement
- Measurement parameters: C-A,‎ CNEL,‎ Dose,‎ Exposure,‎ Lavg/Leq,‎ Ldn,‎ Ln,‎ Max,‎ Min,‎ PDOSE,‎ Peak,‎ Sel,‎ SPL,‎ Taktm,‎ TWA
£ 1,652.00
Price excl. VAT &. delivery

Sound Level Meter SP-SE-2
Order no.: SP-SE-2
SP-SE-2 is a portable handheld Class 2 / Class II datalogging sound level meter, decibel meter or sound pressure level (SPL) meter designed for easy monitoring, documentation and analysis of noise exposures. SP-SE-2 features advanced datalogging functionality to store summary data for multiple tests.

- Removable SD card memory
- Measuring range: 0 ... 140 dB
- Frequency weighting: A, C, F, Z
- Broadband sound (SLM) measurement
- Measurement parameters: C-A,‎ CNEL,‎ Dose,‎ Exposure,‎ Lavg/Leq,‎ Ldn,‎ Ln,‎ Max,‎ Min,‎ PDOSE,‎ Peak,‎ Sel,‎ SPL,‎ Taktm,‎ TWA
£ 1,720.00
Price excl. VAT &. delivery

Sound Level Meter CEL-620A/2/K1
Order no.: CEL-620A/2/K1

CEL-620A/2/K1 is a portable handheld sound level meter, decibel meter, sound pressure level (SPL) meter or sound level indicator that uses advanced digital technology to deliver high performance noise exposure evaluation capabilities in a compact yet robust design. The meter features a high-resolution color TFT display and allows for the analysis of octave bands in real time.

- Measuring range: 20 ... 140 dB (143 dB peak)
- Resolution: 0.1 dB
- Sound meter class: 2
- Simultaneous A,C and linear Z frequency weightings
- LXY, LXYmax, LXYmin, LXeq, LXpeak, Lavg, LC-LA, LXIeq, LTM3, LTM5, LAE
- Supplied with calibration certificate and acoustic calibrator

Manufacturer: Casella CEL Ltd.
£ 1,854.00
Price excl. VAT &. delivery

Sound Level Meter SP-DL-2-1/1
Order no.: SP-DL-2-1/1
SP-DL-2-1/1 is a portable handheld Class 2 / Class II datalogging sound level meter, decibel meter or sound pressure level (SPL) meter designed for easy monitoring, documentation and analysis of noise exposures.

- Removable SD card memory
- Measuring range: 0 ... 140 dB
- Frequency weighting: A, C, F, Z
- Broadband sound (SLM) and 1/1 (full) octave real-time analysis (RTA)
- Measurement parameters: C-A,‎ CNEL,‎ Dose,‎ Exposure,‎ Lavg/Leq,‎ Ldn,‎ Ln,‎ Max,‎ Min,‎ PDOSE,‎ Peak,‎ Sel,‎ SPL,‎ Taktm,‎ TWA
£ 2,630.00
Price excl. VAT &. delivery

Sound Level Meter SP-DL-2-1/3
Order no.: SP-DL-2-1/3
SP-DL-2-1/3 is a portable handheld Class 2 / Class II datalogging sound level meter, decibel meter or sound pressure level (SPL) meter designed for easy monitoring, documentation and analysis of noise exposures.

- Removable SD card memory
- Measuring range: 0 ... 140 dB
- Frequency weighting: A, C, F, Z
- Broadband sound (SLM), 1/1 (full) octave and 1/3 (third) octave real-time analysis (RTA)
- Measurement parameters: C-A,‎ CNEL,‎ Dose,‎ Exposure,‎ Lavg/Leq,‎ Ldn,‎ Ln,‎ Max,‎ Min,‎ PDOSE,‎ Peak,‎ Sel,‎ SPL,‎ Taktm,‎ TWA
£ 3,412.00
Price excl. VAT &. delivery
