PCE Instruments

Force Gauge / Digital Force Gauge

Order no.: PCE-FM1000

PCE-FM1000 is a push-pull force gauge for tension and compression force measurements. This digital force measuring device features a large, easy-to-read 5-digit LCD with 180° screen rotation and backlight. PCE-FM1000 is ideal for handheld use as well as for universal test stand applications.

- Maximum capacity: 100 kg / 220 lb / 980 N
- Minimum capacity: 0.15 kg / 0.35 lb / 1.4 N
- Resolution: 0.05 kg / 0.05 lb / 0.2 N
- Accuracy: ± (0.5 % +0.1 kg)
- Units of measurement: kilograms (kg) / pounds (lbs) / Newtons (N)

Manufacturer: PCE Instruments
Order no.: PCE-FM50

PCE-FM50 is a push-pull force gauge for tension and compression force measurements. This digital force gauge features a large, easy-to-read 5-digit LCD with 180° screen rotation and backlight. PCE-FM50 is a force measuring device ideal for handheld use as well as for universal test stand applications.

- Maximum capacity: 5000 g / 176.40 oz / 49.03 N
- Minimum capacity: 3 g / 0.10 oz / 0.03 N
- Resolution: 1 g / 0.05 oz / 0.01 N
- Accuracy: ± (0.4 % +1 digit)
- Units of measurement: grams (g) / ounces (oz) / Newtons (N)

Manufacturer: PCE Instruments
Order no.: PCE-PTR 200

PCE-PTR 200 is a high-acccuracy multi-purpose force gauge (penetrometer) commonly used to test the ripeness or maturity of fruit based on firmness. PCE-PTR 200 eliminates the need to purchase multiple devices, as PCE-PTR 200 comes with three different penetrating sensors and can be used to measure compression as well as tension or traction.


- Maximum measurement load: 20 kg / 196.10 N / 44.10 lbs
- Resolution: 0.01 kg / 0.05 N / 0.01 lb
- Accuracy: ± 0.5 % of reading + 2 digits
- Units of measurement: kg / N / lb
- Maximum overload: 30 kg / 294.19 N / 66.13 lbs



Manufacturer: PCE Instruments
Order no.: PCE-FM 200
The force gauge PCE-FM 200 is a handheld device that measures up to 200 N. The force gauge PCE-FM 200 can determine the units N, kg and lb. The PCE-FM 200 force gauge is supplied with various adapters that have different shapes. The force gauge PCE-FM 200 can measure both tensile and compressive forces.


- Measuring range: 0 ... 200 N
- Measurement accuracy: ±0.5 %
- Units: N, KG, lb
- Integrated load cell with M6 connection
- Evaluation via USB interface
- Including evaluation software
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-FM 200-ICA
The force gauge PCE-FM 200 is a handheld device that measures up to 200 N. The force gauge PCE-FM 200 can determine the units N, kg and lb. The PCE-FM 200 force gauge is supplied with various adapters that have different shapes. The force gauge PCE-FM 200 can measure both tensile and compressive forces. This force gauge comes with an ISO calibration certificate (PCE-FM 200-ICA).


- Measuring range: 0 ... 200 N
- Measurement accuracy: ±0.5 %
- Units: N, KG, lb
- Integrated load cell with M6 connection
- Evaluation via USB interface
- Including evaluation software
- Incl. ISO Calibration Certificate

Calibration certificates are issued specifically for the customer and are excluded from the right of return.
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-FG 20SD

The force gauge PCE-FG 20SD measures tensile and compressive forces to 196.12 N (20 kg). Thanks to the different measuring tips supplied the force gauge is versatile and by the enclosed extension, it is also suitable for hard to reach places. The integrated microprocessor measurements can be performed quickly and accurately with the pressure force gauge.


- Measuring range: 0 ... 196.12 N
- Resolution: 0.02 N
- Accuracy: ± 0.5% + 2 digits, with 23 ± 5 °C
- Measuring units: kg, lb, N
- Memory size: 16 GB max. SD card
- RS232 / USB interface



Manufacturer: PCE Instruments
Order no.: PCE-DDM 3WI

The PCE-DDM 3WI Force Gauge is the ideal tool for measuring strong tensile forces. The PCE-DDM 3WI Force Gauge is delivered in a protective carrying case and includes two shackles made of heavy-duty aluminum. The instrument is manufacturer calibrated, but can be certified to ISO standards for an additional fee.


- Measurement range: 3000 kg / 30 kN
- Resolution: 1 kg / 10 N
- Units of measurement: kg / t / lbs / N / kN
- Supplied without remote control / indicator



Manufacturer: PCE Instruments
Order no.: PCE-DFG N 10
Digital force gauge PCE-DFG N 10 for tensile force measurement and force measurement up to 10 N. The PCE-DFG N 10 is a digital dynamometer for precise measurements with a resolution of 0.005 N. The Force gauge PCE-DFG N 10 can be purchased here in our shop.

- Measuring range: 0 ... 10 N, 0 ... 2.25 lbs
- Accuracy: ± 0.1% of the measuring range
- Pull and pressure force measurement
- 1600 Hz sampling rate
- Interface: USB
- 6 different measuring tips
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DFG N 2
Digital force transducer PCE-DFG N 2 for tensile force measurement and force measurement up to 2 N. The PCE-DFG N 2 is a digital force transducer for precise measurements with a resolution of 0.001 N. You can buy the dynamometer PCE-DFG N 2 here in our shop.

- Measuring range: 0 ... 2 N, 0 ... 0.45 lbs
- Accuracy: ± 0.1% of the measuring range
- Pull and pressure force measurement
- 1600 Hz sampling rate
- 6 different measuring tips
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DFG N 20
Digital force gauge PCE-DFG N 20 for tensile force measurement and force measurement up to 20 N. The PCE-DFG N 20 is a digital dynamometer for precise measurements with a resolution of 0.01 N. The force gauge PCE-DFG N 20 can be found here in our shop to buy.

- Measuring range: 0 ... 20 N, 0 ... 4.5 lbs
- Accuracy: ± 0.1% of the measuring range
- Pull and pressure force measurement
- 1600 Hz sampling rate
- Interface: USB
- 6 different measuring tips
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DFG N 200
Digital force gauge PCE-DFG N 200 for tensile force measurement and pressure force measurement up to 200 N. The PCE-DFG N 200 is a digital dynamometer for precise measurements with a resolution of 0.1 N. The Force gauge PCE-DFG N 200 can be found here in our shop to buy.

- Measuring range: 0 ... 200 N, 0 ... 44.96 lbs
- Accuracy: ± 0.1% of the measuring range
- Pull and pressure force measurement
- 1600 Hz sampling rate
- Interface: USB
- 6 different measuring tips
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DFG N 5
Force Gauge PCE-DFG N 5 for tensile force measurement and force measurement up to 5 N. The PCE-DFG N 5 is a digital dynamometer for precise measurements with a resolution of 0.001 N. The Force Gauge PCE-DFG N 5 can be purchased here in our shop.

- Measuring range: 0 ... 5 N, 0 ... 1.12 lbs
- Accuracy: ± 0.1% of the measuring range
- Pull and pressure force measurement
- 1600 Hz sampling rate
- Interface: USB
- 6 different measuring tips
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DDM 5WI

The PCE-DDM 5WI Force Gauge is the ideal tool for weighing big loads and for measuring strong tensile forces. The PCE-DDM 5WI Force Gauge is delivered in a protective carrying case and includes two shackles made of heavy-duty aluminum. The instrument is manufacturer calibrated, but can be certified to ISO standards for an additional fee.


- Measurement range: 5000 kg / 50 kN
- Resolution: 2 kg / 20 N
- Units of measurement: kg / t / lbs / N / kN
- Supplied without remote control indicator

Manufacturer: PCE Instruments
Order no.: PCE-LFG 10

The PCE-LFG 10 Force Gauge brings force measurement technology to the user on site. The digital Force Gauge is made for tensile and compressive force measurements and has a measuring range of 10 N. The Force Gauge is suitable for precise measurements with its high resolution of 0.001 N.


- Measuring range: 0 ... 10 N
- Resolution: 0.001 N
- Accuracy: ±0.1 % F.S.
- Memory size: 1,000 values
- RS-232 / USB interface
- Illuminated control panel
- Included calibration certificate



Manufacturer: PCE Instruments
Order no.: PCE-LFG 20

Force measurement technology for the user on site. The digital Force Gauge PCE-LFG 20 for tensile and compressive force measurements can be used up to a measuring range of 20 N. The force meter with its high resolution of 0.005 N is suitable for precise measurements.


- Measuring range: 20 N
- Resolution: 0.005 N
- Accuracy: ±0.1 % F.S.
- Tensile and compressive force measurement
- Illuminated control panel
- Memory size: 1,000 values
- RS-232 / USB interface
- Incl. calibration certificate



Manufacturer: PCE Instruments
Order no.: PCE-LFG 5

The PCE-LFG 5 Force Gauge brings force measurement technology for the user on site. The digital Force Gauge for tensile and compressive force measurements can be used up to a measuring range of 5 N. The Force Gauge with its high resolution of 0.0005 N is suitable for precise measurements. As a precision testing tool, this kind of test instrument comes manufacturer calibrated and is also ISO certificated.


- Measuring range 5 N
- Resolution 0.0005 N
- Tensile and compressive force measurement
- High measuring accuracy
- Illuminated control panel
- Incl. calibration certificate



Manufacturer: PCE Instruments
Order no.: PCE-FB 1K

High accuracy top class force gauge with graphical display, which allows very precise force measurements. A tool for engineers and technicians. This force gauge can be used in a variety of tension and compression force testing applications. It can also be used in combination with our force test stands. The force gauge comes manufacturer calibrated and can optionally be certified to ISO or .


- Measurement range: 0 ... 1,000 N (100 kg)
- Resolution: 0.2 N (20 g)
- Accuracy: ± 0.1 % FS
- External load cell
- Memory: 8 x 800 measurements (internal) + MiniSD slot
- Interfaces: Serial RS-232, 9-pin and USB
- Units: N, g, lb, oz, kg, kgf, lbf, ozf
- Languages: German / English / Spanish



Manufacturer: PCE Instruments
Order no.: PCE-FB 2K

High accuracy top class force gauge with graphical display, which allows very precise force measurements. A tool for engineers and technicians. This force gauge can be used in a variety of tension and compression force testing applications. It can also be used in combination with our force test stands. The force gauge comes manufacturer calibrated and can optionally be certified to ISO or .


- Measurement range: 0 ... 2,000 N (200 kg)
- Resolution: 0.5 N (50 g)
- Accuracy: ±0.1 % FS
- External load cell
- Memory: 8 x 800 measurements (internal) + MiniSD slot
- Interfaces: Serial RS-232, 9-pin and USB
- Languages: german / english / spanish

Manufacturer: PCE Instruments
Order no.: PCE-DDM 3

The PCE-DDM 3 Force Gauge is the ideal tool for measuring strong tensile forces. The PCE-DDM 3 Force Gauge is delivered in a protective carrying case and includes two shackles made of heavy-duty aluminum. The instrument is manufacturer calibrated, but can be certified to ISO standards for an additional fee.


- Measurement range: 3000 kg / 30 kN
- Resolution: 1 kg / 10 N
- Units of measurement: kg / t / lbs / N / kN
- Supplied with remote control indicator

Manufacturer: PCE Instruments
Order no.: PCE-DDM 10WI

The PCE-DDM 10WI Force Gauge is the ideal tool for weighing big loads and for measuring strong tensile forces. The PCE-DDM 10WI Force Gauge is delivered in a protective carrying case and includes two shackles made of heavy-duty aluminum. The instrument is manufacturer calibrated, but can be certified to ISO standards for an additional fee.


- Measurement range: 10000 kg / 100 kN
- Resolution: 5 kg / 50 N
- Units of measurement: kg / t / lbs / N / kN
- Supplied without remote control indicator

Manufacturer: PCE Instruments
