Regulator / Process Controller

The 2-point process controller / temperature controller is a compact temperature controller for use in a wide range of tasks. This 2-point temperature controller PCE-RE22P processes the process signals 0 … 20mA, 4 … 20 mA, 0 … 5 V and 0 … 10 V as input signals. Different operating modes can be selected to optimally regulate the controlled variable to the reference variable.

• Power supply: 230 V AC, 110 V AC, 24 V AC (selectable)
• Process signals: 0/4 … 20 mA, 0 … 5/10 V
• Output: Relay / SSR (selectable)
• Manual control mode

The 2-point process controller / temperature controller is a compact PID controller for a wide range of tasks. As an input signal, this 2-point temperature controller PCE-RE22 processes resistance sensors and thermocouples. Different operating modes can be selected for optimum control of the control variable. Starting with a simple on / off control with adjustable hysteresis up to the PID control, the 2-point temperature controller offers a wide range of possibilities.

• Signal input: temperature signals (PT100, PT1000, J, T, K, S, R, B, E, N, L)
• Possible control characteristics: P, PD, PI, PID, On / Off control
• Front is protected to IP 65
• 4 LEDs for status display

The process controller / temperature controller is a simple temperature controller for control tasks. The input signal of the thermostat is processed by thermocouples type J in different temperature ranges. Optionally the simple temperature controller can also be equipped with a PID switch.

• Power supply: 85 … 253 V AC / DC
• Sensor Input: Thermocouple type J
• Measuring ranges: up to max. 900 °C (selectable)
• Output: Relay or SSR output (selectable)

The process controller / temperature controller is a simple temperature controller for control tasks. The input signal of the thermostat is processed by thermocouples type K in different temperature ranges. Optionally the simple temperature controller can also be equipped with a PID switch.

• Power supply: 85 … 253 V AC / DC
• Sensor Input: Thermocouple type K
• Measuring ranges: up to max. 1300 °C (selectable)
• Output: Relay or SSR output (selectable)

The process controller / temperature controller is a simple temperature controller for control tasks. The input signal of the thermostat is processed by the Pt100 sensor in different temperature ranges. Optionally the simple temperature controller can also be equipped with a PID switch.

• Power supply: 85 … 253 V AC / DC
• Sensor Input: for Pt100 sensor
• Measuring ranges: up to max. 600 °C (selectable)
• Output: Relay or SSR output (selectable)

The process controller / temperature controller is a simple temperature controller for control tasks. The input signal of the thermostat is processed by thermocouples type S in different temperature ranges. Optionally the simple temperature controller can also be equipped with a PID switch.

• Power supply: 85 … 253 V AC / DC
• Sensor Input: Thermocouple type S
• Measuring ranges: up to max. 1600 °C
• Output: Relay or SSR output (selectable)

The process controller / temperature controller is a compact PID controller which can be used in a wide range of applications. On the input side, this temperature controller processes the widely used process signals 4 … 20 mA and 0 … 10 V as well as resistance sensors and thermocouples. The temperature controller can be used very flexibly, since different operating modes are available. Besides the simple on / off control with adjustable hysteresis, the digital controller also offers various combinations of the PID control. Thanks to the SMART PID control, this temperature controller achieves the setpoint value very quickly and with a slight overshoot.

• Two 4-digit LED displays
• Two output relays
• Front protected to IP65
• Analogue universal input
