Panel Indicator

The panel indicator is used for the signal processing of 4 .. 20 mA. The panel indicator has a 5-digit LED display to allow the user to read the directly measured current values.

- Power supply: 230 V, 110 V, 24 V, 20 ... 40 V AC/DC, 85 ... 253 V AC/DC (selectable)
- Input signal: 0/4 ... 20 mA, 0 ... 60 mV, ±60 mV DC, 0 ... 10 V, ± 10 V DC (selectable)
- Display: 4 digits, red
- Digit height: 20 mm

- Power supply:
   230V, 110V, 24V, 20 ... 40V AC/DC,
   85 ... 253 V AC/DC (selectable)
- Input signal:
   1 ... 100V, 2.5 ... 250V, 4 ... 400V,
   20 ... 500 Hz, 1 A, 5 A (selectable)
- Display: 4 digits, red
- Digit height: 20 mm / 0.78"

 - Power supply:
   230 V, 110 V, 24 V, 20 ... 40 V AC/DC,
   85 ... 253 V AC/DC (selectable)
- Input signal: ±100 V DC, ±250 V DC,
   ± 400 V DC, 1 A DC, 5 A DC (selectable)
- Display: 4 digits, red
- Digit height: 20 mm / 0.78"

Note: This item must be configured before ordering!

The panel indicator PCE-N24T is used for processing signals coming from temperature sensors. Depending on your specific needs, the digital indicator can be ordered with different inputs for thermocouples (type J, K) or resistance thermometers (Pt100). The input signal of the digital indicator is freely scalable, which increases its application possibilities.



- Power supply: 230 V, 110 V, 24 V, 20 ... 40 V AC/DC, 85 ... 253 V AC/DC (selectable)
- Input signal: PT100, Thermoelement Type J / K (selectable)
- Display: 4 digits, red
- Digit height: 20 mm

The panel indicator is used for processing 4...20 mA and 0...20 mA signals. Many measuring transducers and sensors use this type of output, which makes the panel indicator suitable in a wide application area. The measurement results are shown on the large 5-digit LED-display of the panel indicator.

- Input (selectable): 0...20 mA, 4...20 mA, ± 20 mA
- Accuracy: ± (0.2 % FS + 1 dgt.)
- Two open collector outputs
- 24 V power supply sytem for sensors and transducers

The PCE-N20U is a panel indicator used for signal processing. Designed for quick and easy system integration, the digital panel indicator features a large 5-digit LED display with tricolor coding dependent on the measured values. The panel indicator also can output signals via two open collector outputs when a threshold value is exceeded.

- Input (selectable): 0...10 V / 0...60 mV / ±10 V
- Accuracy: ± (0.2 % FS + 1 digit)
- 24 V power supply system for sensors and transducers

The digital panel indicator is used for processing signals from Pt100 temperature sensors or thermocouples (type J, K). The measurement results are shown on the large 5-digit LED-display of the panel indicator. Depending on the actual values, the temperature can be shown in three different colors, which makes it easier to evaluate them.

- Input: Pt100, thermocouple type J or type K
- Accuracy: ± (0.2 % FS + 1 dgt.)
- two open collector outputs
- 24 V power supply sytem for sensors and transducers
- 5-digit, three-coloured LED display

The panel indicator can be used to measure AC voltages up to 400 V and AC currents. The voltage to be measured is connected directly and can then be read on the 5-digit LED display of the panel indicator.

- Input:
   1A AC, 5A AC, 100V AC, 250V AC,
   400 V AC, 20 ... 500 Hz (selectable)
- Supply voltage:
   85 ... 253V AC/DC / 20 ... 40 V AC/DC (selectable)
- Display: 5 digits, three colors
- Digit height: 14 mm / 0.55"

- Digital panel indicator with function of pulse counter, tachometer and periodimeter
- LED display 6 digits red 14 mm
- Signal ranges: counter up to 250 KHz, tachometer up to 500 KHz, periodimeter up to 500 KHz
- Functions: Push-pull inputs, NPN, PNP, Namur, pick-up, TTL, inductive, mechanical contact, quadrature signals (encoder)

- Digital panel indicator with stopwatch function
- LED display 6 digits red 14 mm color
- Decimal or sexagesimal reading format
- Functions: Start / Stop / Reset inputs, On power-up, Trigger sense, ...

Input:
2-, 3- wire
Thermocouples
Potentiometer
Resistance
Process signals
Frequency
DC voltage
DC power
AC voltage
AC power

The panel indicator can process several different input signals, such as 0...410/4010 Ohm, -10...+63 mV DC, -13...+13 V DC, -24...+24 mA DC or signals from thermocouples and resistance thermometers. This makes the panel indicator applicable in a wide range of applications. The measured values are shown on the large LED display of the panel indicator.

- 21-point scaling
- IP 65 protection on the front
- Three-colored display
- Two alarm outputs

- Interface: RS 485 Modbus RTU Master
- Number of slave devices / registers: 10
- Baud rate individually adjustable
- Further power supply area
