Vibration Analyzer / Vibration Analyser

Order no.: VB-83
Optional Vibration Analyzer VB-83 for vibration meter PCE-VM 5000. (Similar to photo)

- Measuring head with handle: (L) 7.6cm x Ø 3.5 cm
- Cable length: 1.2 m
US$ 389.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: VB-84

Optional Vibration Tester VB-84 for vibration meter PCE-VM 5000. (Similar to photo)

- Measuring head: 7.6 cm x Ø 3.5 cm
- Cable length 1.2 m

US$ 389.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-PVS 30
The Vibration Analyser has been developed for the continuous monitoring of the vibration speed. The Vibration Analyser is available in different versions. Depending on the type of vibration sensor, a distinction is made between design and measuring range.

- Measuring range: ± 12.7 mm / s
- Frequency range: 3 ... 1500 Hz
- Design: horizontal connection
- Power supply: 12 ... 24 V DC in current loop


US$ 645.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1100

The vibration analyzer is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this vibration analyzer, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10mm

US$ 376.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1100S

The vibration analyzer is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this vibration analyzer is used for rapid measurement of imbalance and for checking bearing and gear conditions.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Portable and battery operated
- Needle probe: 45mm / 1.77"

US$ 376.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1100-ICA

The vibration analyzer is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this vibration analyzer, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10mm
- incl. ISO Calibration Certificate

US$ 615.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1100S-ICA

 The vibration analyzer is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this vibration analyzer is used for rapid measurement of imbalance and for checking bearing and gear conditions.




- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Portable and battery operated
- Needle probe: 45mm / 1.77"
- incl. ISO Calibration Certificate

US$ 615.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VDL 16I
The vibration analyzer PCE-VDL 16I from PCE Instruments measures and stores the relevant measured variables: temperature, relative humidity, air pressure, light as well as acceleration in three axes by means of a vibration sensor. Therefore, this vibration analyzer is ideal for monitoring vibrations on machines while simultaneously measuring and recording the relevant environmental conditions of the system.

- 3-Axis acceleration up to 800 Hz
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Temperature, Humidity, Air pressure, Vibration, and Light
US$ 329.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VDL 24I
For this vibration analyzer PCE-VDL 24I the acceleration sensor is delivered with a sampling rate of 1600 Hz. The sensor measures the acceleration, which is currently acting on it (3 axes), for example shock / vibration. The measurements take place at predetermined (selectable) time intervals.

- 3-Axis acceleration up to 1600 Hz and ±16 g
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
US$ 396.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VM 22
The vibration analyzer has a measuring range of 0 ... 200 m/s² for acceleration. In addition to acceleration, the vibration analyzer can also perform speed, displacement, frequency and an ISO 18016-3 measurement.

- Acceleration
- Velocity
- Displacement
- Frequency
- Tachometer
- Infrared temperature measurement
- 4 GB data memory
- FFT analysis and wave view of the vibration
US$ 3,545.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VM 22-ICA
The vibration analyzer has a measuring range of 0 ... 200 m/s² for acceleration. In addition to acceleration, the vibration analyzer can also perform speed, displacement, frequency and an ISO 18016-3 measurement.

- Acceleration
- Velocity
- Displacement
- Frequency
- Tachometer
- Infrared temperature measurement
- 4 GB data memory
- FFT analysis and wave view of the vibration
- incl. ISO Calibration Certificate
US$ 3,758.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VDR 10-ICA

PCE-VDR 10-ICA is a single-axis accelerometer or vibration analyzer with real-time measurement and data logging capabilities. This vibration analyzer records acceleration (m/s, g, ft/s) as well as velocity (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory. There is also an analog output, which makes this vibration analyzer compatible with control systems.

- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Velocity measuring ranges:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface
- incl. ISO Calibration Certificate

US$ 1,140.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VD 3-ICA

PCE-VD 3-ICA is a vibration analyzer that measures 3-axis shock/vibration via a built-in accelerometer sensor. This vibration analyzer records 3-axis acceleration (X, Y, Z) vibration measurement data for Fast Fourier Transform (FFT) waveform analysis. The vibration analyzer connects to your PC via a USB port for configuration and for quick and easy data transfer.


- Measuring range: ±16 g per axis
- Frequency range: 0 ... 60 Hz
- Recording interval: Adjustable from 1 sec .... 24 hr
- Logs and stores up to 168,042 records
- Includes magnetic bracket with wall-mounting screws
- incl. ISO Calibration Certificate

US$ 434.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-S 40

The PCE-S 40 is an automotive-testing acoustic stethoscope which amplifies machine noises. An acoustic stethoscope makes it possible to detect noises in bearings, fan flaps, pumps and similar parts. In mechanical engineering, it is used for preventive maintenance to diagnose potential machine faults before they arise.


- Measuring tip: approx. 16.5 cm
- Earpieces made of soft plastic
- Total length: approx. 1 m
- Tight ear clips

US$ 86.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-S 41

The PCE-S 41 Vibration Analyser is battery powered and easy to use. This Vibration Analyser can be used for detecting noise in machine components, such as gears, valves, vents, and pumps.

- Frequency range: 100 Hz to 10 kHz
- headphones, 70 mm sensor, 290 mm sensor, battery, carrying case
- Weight: 240 g, with battery

US$ 165.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VD 3

The PCE-VD 3 Vibration analyzer is a miniaturized universal Vibration analyzer with an included built-in three-axes acceleration sensor (X, Y, Z axis). The internal sensor of the PCE-VD 3 Vibration analyzer measures acceleration force along the X, Y, and Z axes with a measurement range of ±16 g per axis.


- 3-axis vibration data logging
- Software included -USB port
- Light weight
- Stand included
- Storage capacity: 8 Mbit (168042 records)
- Magnetic wall mount



US$ 206.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VS10

PCE-VS10 is a vibration meter, analyzer or sensor condition monitoring switch used to measure RMS and peak value of vibration velocity or acceleration piezoelectrically. This IP67-rated vibration monitoring switch features a red and green visual warning or alarm with programmable high pass and low pass filters.


- Frequency range (max.): 0.1 Hz ...10 kHz
- Measuring range: Acceleration = 0.1 ... 1000 m/s², Speed = Frequency-dependent
- Connections: Screw terminals for power supply (5 ... 30V DC) and Micro USB (internal)
- Mounting: M8 stud bolt

US$ 392.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1100M

The vibration analyzer is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this vibration analyzer, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units only
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10 mm
- including magnetic sensor

US$ 409.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1300
The vibration analyzer is a measuring device for one-hand operation. This is made possible by the built-in acceleration sensor in the vibration analyzer. Another special feature of the vibration analyzer is the vibration evaluation according to ISO 10816-1.

- Frequency range: 1 ... 15 KHz (HI)
- Measures speed, distance, acceleration
- Piezoelectric ceramic acceleration sensor
- Handy and battery operated
- Standard sensor: 10 mm / 0.4 in  attachment
US$ 439.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VT 1300S
The vibration analyzer is a measuring device for one-hand operation. This is made possible by the built-in acceleration sensor in the vibration analyzer. Another special feature of the vibration analyzer is the vibration evaluation according to ISO 10816-1.

- Frequency range: 1 ... 15 KHz (HI)
- Measures speed, distance, acceleration
- Piezoelectric ceramic acceleration sensor
- Handy and battery operated
- Standard sensor: 45 mm / 1.8" needle tip
US$ 439.00
