Order no.: PCE-TC 38

Thermal Imager PCE-TC 38

US$ 2,574.00
:
4250348735454
PCE-TC 38
ex. VAT, ex. delivery costs
Available in: 1-2 days

Description

Thermal Imager with memory / 5 different colour palettes / 3.5-inch TFT colour display / JPG image format / thermal sensitivity: 0.06 °C

Our Thermal Imager offers reliable temperature measurement within a range from -20 °C to 550 °C (-4 °F to 1022 °F). The infrared images are displayed with a resolution of 384 x 288 pixels on the 3.5-inch colour display. The compact and user-friendly design of the Thermal Imager features an ergonomic handle and an intuitive key control system directly below the screen for easy operation.

The camera offers multiple colour palettes, including rainbow and iron oxide red, as well as various viewing options to accurately capture thermal data. With a thermal sensitivity of 0.06 °C and an adjustable emissivity of 0.01 to 1.0, even subtle temperature differences can be detected. It saves more than 40000 images in the internal 6 GB memory in JPG format. With a frame rate of 25 Hz, a wavelength range of 8 ... 14 μm and selectable automatic power-off times, this Thermal Imager is a versatile tool for professional and private users.

The unique feature of this Thermal Imager is the possibility of a remote connection via a WiFi network, e.g. to a smartphone from which the Thermal Imager can be set remotely or the recorded thermal images can be saved directly to the end device. Once a smartphone is connected to the Thermal Imager via WiFi, the corresponding colour palette, emissivity or even the display of the maximum and minimum value can be set remotely. Thanks to the Thermal Imager, not only heat losses but also leaks in water and heating systems or non-functioning mechanical components of various systems (motors, bearings, belts, heat pumps, etc.) can be easily detected.


Highlights

- infrared image resolution: 384 x 288 pixels
- internal memory for over 40000 images
- image format: JPG
- WiFi image transmission
- 5 different colour palettes
- automatic power-off

Specification

Temperature
Measurement range up to  -20 ... +550 °C
Resolution  0,1 °C
Accuracy  <0 °C: ±3 % | >0 °C: ±2 ℃ or ±2 %

Temperature
Measurement range up to  -4 ... +1022 °F
Resolution  0,1 °F
Accuracy  <32 °F: ±3 % | >32 °F: ±2 °F oder ±2 %

General technical data
Units  °C, °F
Display type  TFT colour display
Display size  3,5 Inch
Display resolution  640 x 480 pixels
Measuring rate  25 Hz
Storage medium  Internal memory
Storage capacity  6 GB
Memory capacity (additional information)  for approx. 40000 images
Interface  Micro-USB, WiFi
Resolution  Infrared image: 384 x 288 pixels
Operating time  4 h
Automatic power-off from...to  5 ... 20 min.
Automatic power-off can be deactivated  Yes
Emissivity from/to  0.01 ... 1
Wavelength range  8 ... 14 µm
Field of vision (FOV)  28.4° x 21.4°/ 13 mm
Colour palette  Rainbow, Iron, Cold colours, white-black (+inverted)
Image / video format  JPG
Thermal sensitivity  0,06 °C
Menu language  German, English, Italian, Chinese
Protection class (device)  IP20
Power supply  100 ... 240 V AC | 50/60 Hz
Connector type  Euro plug
Weight  634 g
Operating conditions  0 ... 45 °C , 0 ... 85 % RH
Storage conditions  -20 ... 60 °C , 0 ... 85 % RH
Capacity  5000 mAh
Dimensions ( L x W x H )  245 x 97 x 110 mm

Delivery Scope

1 x Thermal Imager PCE-TC 38
1 x micro USB cable
1 x mains adaptor 5 V, 2 A
1 x carrying case
1 x user manual
