Surface Testing

The surface testing - color meter is designed for fast and precise color measurements of surfaces. The color ranges CIE-LAB, CIE-LCh, HunterLab, CIE-Luv, XYZ, RGB of the color can be determined with the surface testing - color meter.

- Measuring aperture: Ø8 mm / 0.31"
- Wavelength interval: 10 mm / 0.39"
- Wavelength: 400 ... 700 nm
- Battery life for approx. 10,000 measurements
- Bluetooth interface
- Requires free app for Android only in Playstore (PCE-XXM 30) to use all features
- Various adjustable light sources

The surface testing - color meter is designed for fast and precise color measurements of surfaces. The color ranges CIE-LAB, CIE-LCh, HunterLab, CIE-Luv, XYZ, RGB of the color can be determined with the surface testing - color meter.

- Measuring aperture: Ø8 mm / 0.31"
- Wavelength interval: 10 mm / 0.39"
- Wavelength: 400 ... 700 nm
- Battery life for approx. 10,000 measurements
- Bluetooth interface
- Requires free app for Android only in Playstore (PCE-XXM 30) to use all features
- Various adjustable light sources
- incl. ISO Calibration Certificate

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
- Incl. ISO calibration certificate

PCE-CT 65 is a surface testing - coating thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.

- Measuring range: 0 ... 1350 µm / 0 ... 53.1 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory

With the PCE-890U  Surface Testing - Temperature Meter, measurements of surface temperatures can be carried out quickly and easily. Since the temperature meter uses infrared radiation for temperature measurement, no direct contact with the measuring object is required. The temperature meter makes it easy to measure objects from a distance that are difficult to access.

- Measuring range: -50 ... 1150°C / -58 ... 2102°F
- Accuracy: ± 1.5% ± 2°C / 3.6°F (0 ... 500°C / 32 ... 932°F)
- Resolution: 0.1°C / 0.18°F (<1000°C / 1832°F)
- Emission level: 0.1 ... 1

PCE-CT 65 is a surface testing - coating thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This surface testing - thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.

- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory
- Incl. ISO Calibration Certificate

PCE-CT 5000H is a surface-testing coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The coating thickness gauge automatically detects the type of metal to be measured.

- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head

PCE-CT 5000H is a surface testing - coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The coating thickness gauge automatically detects the type of metal to be measured.

- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head
- Incl. ISO Calibration Certificate

PCE-CT 27FN is a Surface Testing - Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.

- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ±(2 % + 2 µm) / ±(2 % + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils



The surface testing PCE-IVE 320 is a borescope, inspection camera, videoscope or industrial endoscope that comes with a rigid telescoping pole that extends up to 2.3 m (7.6 ft) in length (3 m / 9.8 ft long total with camera connection). Plus, the surface testing - inspection camera has a 0.3 megapixel camera with a 23 mm (0.91 in) diameter flexible head with microphone and 12 white LEDs offering adjustable brightness. Includes wheel attachment for under vehicle inspection.

- Telescopic pole extends up to 2.3 m / 7.6 ft
   (3 m /9.8 ft long total with camera connection)
- 12.7 cm / 5" LCD monitor with 800 x 480 pixel resolution
- Video recording capability
- Accommodates SD memory cards from 2 ... 32 GB
- Spare battery to allow all day operation



The surface testing PCE-VE 390N is the ideal inspection camera snake for the analysis of buildings (walls, supports, eaves, gutters, attics, crawl spaces), plumbing (pipes, drains, sewers, wells) and heating, ventilation, air conditioning and refrigeration (HVACR) systems (ducts, furnaces, chimneys, boiler and condenser tubes). The IP68-rated cable of this inspection camera is waterproof and heavy duty, making it well suited for use in tough environments like construction sites and industrial installations.

- Camera head diameter: 28 mm / 1.1"
- Camera cable length: 10 m / 32 ft 9"
- Interface: Mini-USB 1.1 and AV out
- Memory: 8 GB SD memory card (incl.)
- Especially suitable for chimneys, downpipes, ventilation ducts etc.

The surface testing PCE-VE 1000 is an industrial endoscope, borescope, videoscope or inspection camera display featuring an exceptionally large 7" high-resolution LCD screen for impressive on-screen viewing capabilities.

- Stores photos and saves videos with sound to the included 8 GB SD memory
  card (max. compatibility 32 GB) for quick and easy transfer to a computer
- 360° image rotation (in 90° steps)
- Digital zoom

Display only. Camera cables (from diam. 5.5 mm / 0.22 in, 2-way, 4-way articulation) are sold separately. See accessories to customize.



PCE-CT 27FN is a Surface Testing - Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.

- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ±(2 % + 2 µm) / ±(2 % + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils
- incl. ISO Calibration Certificate

- Infrared measuring range: -40 ... 300°C / -40 ... 572°F
- Sensor measuring range: -40 ... 300°C / -40 ... 572°F
- Charging station with micro USB cable
- Bluetooth interface

The Surface Tester PCE-CRC 10 is designed to determine the quality of the adhesion of coatings. The Surface Tester is suitable for thin, thick or tough coatings on all surfaces. Since the adherence of paintings and other coatings is a crucial product and quality characteristic for their protective effect, surface testers are used in a wide range of industries.

- Evaluation of adhesion
- For thin, thick or tough coatings
- Large, non-slip grip
- Various blades selectable



The surface thickness measuring device is used for the quick and precise detection of layer thicknesses on metals. In comparison to many other thickness meters, this surface thickness measuring device does not have to differentiate between ferrous and non-ferrous metal.
