PCE-AQD 10
The CO2 data logger PCE-AQD 10 is used to measure air quality. The CO2 data logger measures carbon dioxide, temperature and humidity. The CO2 sensor from the CO2 data logger is separated from the main unit with a connection cable. The measured values are displayed on the large display of the CO2 data logger. The air quality measurement data is stored on an SD card. The CO2 data logger can set the measured data in adjustable intervals of 1 ... 600 seconds.
The CO2 data logger is used to monitor indoor air quality in lounges, offices, schools, etc. Through the SD memory, the CO2 measurement data can be monitored over a long period of time to initiate further measures to improve the room air quality.
| CO² | |
| Measuring range | 0 ... 1000 ppm |
| Resolution | 1 ppm |
| Accuracy | ±70 ppm |
| CO² | |
| Measuring range | 1000 ... 3000 ppm |
| Resolution | 1 ppm |
| Accuracy | ±5 % of Rd |
| CO² | |
| Measuring range | 3000 ... 4000 ppm |
| Resolution | 1 ppm |
| Accuracy | ±250 ppm |
| Relative humidity | |
| Measuring range | 10 ... 70 % RH |
| Resolution | 0,1 % RH |
| Accuracy | ±4 % RH |
| Relative humidity | |
| Measuring range | 70 ... 90 % RH |
| Resolution | 0,1 % RH |
| Accuracy | ±(4 % of Rd + 1 % RH) |
| Temperature | |
| Measuring range | 0 ... 50 °C |
| Resolution | 0,1 °C |
| Accuracy | ±0.8 °C |
| General technical data | |
| Display type | LCD with backlight |
| Display size | 3,1 Inch |
| Display refresh rate | 1 x per second |
| Adjustable measuring rate | 5 ... 600 s |
| Sampling rate (additional information) | Automatic: if the value changes by ±1 °C, ±1 % RH or ±50 ppm, the data record is automatically written to the memory. |
| Storage medium | SD card |
| Storage capacity | 16 GB |
| Memory capacity (additional information) | 4 GB SD card included in the delivery |
| Menu language | English, English (GB) |
| Protection class (device) | IP20 |
| Power supply | 100 ... 240V AC | 50/60 Hz |
| Connector type | Device-europlug |
| (Rechargeable) battery | 6 x 1,5 V AAA battery , Alkali-manganese |
| Capacity | 1200 mAh |
| Operating conditions | 0 ... 50 °C , 0 ... 90 % RH |
| Storage conditions | 0 ... 50 °C , 0 ... 90 % RH |
| Dimensions ( L x W x H ) | 145 x 80 x 32 mm |
| Other dimensions | CO2 sensor: 132 x 38 x 32 mm |
| Weight | 180 g |
