PCE Instruments

Anemometer

Order no.: PCE-A420

Without a doubt, the main advantage of this handheld cup vane Anemometer is that it doesn't need to be held exactly in the direction of the wind. Anemometer with impellers typically have to be held exactly in the direction of the air flow to take accurate measurements. Digital cup vane Anemometer, wind direction will not influence the measurement.


- 0.9 to 35.0 m/s
- 2.5 to 126.0 km/h
- 1.4 to 68.0 knots
- 1.6 to 78.2 miles/h

Manufacturer: PCE Instruments
US$ 179.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VA 11

This vane anemometer is used to measure air speed, air flow, air temperature and infrared (IR) temperature. This multi-functional portable handheld vane anemometer offers a quick response time, allowing for real-time measurement. In addition, the impeller features a thread for mounting in one location for fixed measurement.


- Air speed range: 0.4 ... 30 m/s / 0.9 ... 67 mph
- Air flow range: 0 ... 9999 CFM / CMM
- Air temperature range: -10 ... 60°C / 14 ... 140°F
- IR temperature range: -50 ... 500°C / -58 ... 932°F

Manufacturer: PCE Instruments
US$ 216.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VA 11-ICA

The Vane Anemometer PCE-VA 11 is a useful and versatile device for measuring air speeds, air temperature and infrared temperature. Thanks to the fast response time of the device, real-time measurement is possible without problems. The large display provides an accurate overview of the measured values.


- Air speed range: 0.4 ... 30 m/s / 0.9 ... 67 mph
- Air flow range: 0 ... 9999 CFM / CMM
- Air temperature range: -10 ... 60°C / 14 ... 140°F
- IR temperature range: -50 ... 500°C / -58 ... 932°F
- USB interface
- Incl. ISO Calibration Certificate



Manufacturer: PCE Instruments
US$ 384.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50W 230-ICA

The anemometer PCE-WSAC 50W 230-ICA is useful for measuring the wind speed to help determine the preferred site for a wind turbine installation. The device also monitors the wind load on existing wind farms, as well as on cranes for safey purposes. Due to the integrated 4 ... 20-mA analogue output of the anemometer, the measured data can also be transferred to other controllers for evaluation.


- Measuring range up to 180 km / h
- Input: Pulse, analogue (4 ... 20-mA) or radio transmission
- 4 ... 20-mA analogue output
- Supply voltage: 110 ... 230V AC, 50/60 Hz
- Ambient temperature -20 .. . 70°C / -4 ... 158°F
- Units adjustable: km / h, mph, m / s
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
US$ 1,631.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-THA 10

The multifunction anemometer PCE-THA 10 is easy to operate with one hand thanks to its compact size, the new structure and integrated impeller. In addition to the wind speed, the anemometer measures the temperature, humidity, dew point, the wet bulb temperature and the air volume. Average values can be determined with the anemometer from the 20 preset points. All the test instruments come manufacturer calibrated. ISO certification can be made as an option.


- Temperature measuring range: -15 ... 50°C / 5 ... 122°F
- Humidity range: 5 ... 95% RH
- Air speed: 0.4 ... 35 m / s
- Air flow: 0 ... 9.999 m3 / s



Manufacturer: PCE Instruments
US$ 154.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50-710

PCE-WSAC 50-710 is an anemometer that displays the current wind speed as well as the average wind speed of the last 2 and 5 minutes. This anemometer allows measurement of the slightest of wind movements. The anemometer is used for a variety of wind monitoring applications in industries such as construction, mining, renewable energy and manufacturing.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 230 V AC
-
Signal input: 4...20 mA
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 525.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-THA 10-ICA

The multifunction anemometer PCE-THA 10 is easy to operate with one hand thanks to its compact size, the new structure and integrated impeller. In addition to the wind speed, the anemometer measures the temperature, humidity, dew point, the wet bulb temperature and the air volume. Average wind speed values can be determined with the anemometer from the 20 preset points.


- Temperature measuring range: -15 ... 50°C / 5 ... 122°F
- Humidity range: 5 ... 95% RH
- Air speed: 0.4 ... 35 m / s
- Air flow: 0 ... 9.999 m3 / s
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
US$ 315.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50-721

The prevailing wind speed and the mean wind speed (across two and five minutes) can be displayed by the PCE-WSAC 50-721 anemometer. The smallest of wind movement is detected by this convenient anemometer. The anemometer is used for a variety of wind monitoring applications in both outdoor industry and outdoor sports.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 230 V AC
- Signal input: 0...10 V
- Interface: RS-485 modbus
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 612.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VA 20

PCE-VA 20 is a multifunction anemometer for assessing wind, weather, indoor / outdoor environmental climate conditions as well as for testing heating, ventilation and air conditioning or cooling (HVAC) systems. This combination anemometer-hygrometer-thermometer features a 10 cm / 3.9" Ø fan impeller, easy-to-read backlit LCD, and functions such as display hold, average value, maximum value, minimum value, battery-saving automatic power off, low-battery indicator, and metric or imperial unit selection.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±(3% of
  measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1



Manufacturer: PCE Instruments
US$ 334.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-VA 20-ICA

The PCE-VA 20 is a versatile multifunction anemometer for determining environmental conditions such as wind, temperature and humidity. It is additionally used to test heating, ventilation and air conditioning / cooling (HVAC) systems. This triple thermometer-hygrometer-anemometer device has a 10 cm / 3.9" Ø fan impeller and a clear backlit LCD. Available functions include display hold, average / maximum / minimum value, auto shutdown, low-battery warning, and metric / imperial choice.


- Measures air flow velocity, volume flow, relative humidity, air temperature, dew
  point temperature and wet-bulb temperature
- Air flow velocity range: 0.2 ... 30 m/s (39.4 ... 5905.5 fpm)
- Accuracy: ±(1.5% of measured value + 0.3 m/s) when less than 20 m/s, ±
  (3% of measured value + 0.3 m/s) when more than 20 m/s
- Resolution: 0.1
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
US$ 502.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-423

The PCE-423 Hot wire anemometer with thermal sensor is highlighted by its good relation between price and quality. The Hot wire anemometer has a high resolution to be used for different applications. All the test instruments come manufacturer calibrated. ISO certification can be made as an option.


- Kind of sensor: Hot wire
- External
- Memory: No
- Interface: USB
- Measurement range: 0.1 ... 25.0 m/s, 0.2 ...55.8 mph
- Resolution: 0.01 m/s, 0.1 mph



Manufacturer: PCE Instruments
US$ 247.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50-810

The PCE-WSAC 50-810 anemometer allows measurement of wind movements from 0 mph to 110 mph. This convenient anemometer is used to measure the current wind speed and also the average speed over 2 minutes and over 5 minutes. Many outdoor industries, for example farming and acquaculture, are in need of the wind monitoring functions of the anemometer.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 115 V AC
- Signal input: 4...20 mA
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 525.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-423-ICA
The PCE-423 is a high resolution hot-wire anemometer to measure air velocity and temperature in varied situations. The hot-wire anemometer belongs in the basic toolkit for professionals working with ventilation systems, as well as being useful in institutional research and development.


- Measurement range:m/s: 0.1 ... 25.0 m/s, 0.2 ... 55.8 mph
- Measures air velocity and temperature
- Suitable for low velocity air flow
- multiple measurement units available
- Large LCD display
- Data-Hold function
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 475.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50-811

For measurement and display of both the current wind speed and the mean wind speed (over 120 seconds and 300 seconds), the PCE-WSAC 50-811 is an ideal anemometer. Measurement of the slightest of wind motion is achieved by this sensitive instrument. The anemometer can be applied to multiple wind monitoring applications in building and maintenance, agriculture and aviation and many other industries.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 115 V AC
- Signal input: 4...20 mA
- Interface: RS-485 modbus
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 612.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-007

Anemometer with port, memory, software for wind speed, temperature and air flow. All the test instruments come manufacturer calibrated. ISO certification can be made as an option.

- Speed measurement up to 45 m/s or 100 mph
- Wind speed: 0.01 m/s, accuracy ±3% ±0.1
- Air temperature: 0.2°C / 32.4°F, accuracy ±1°C / 33.8°F
- Air flow: 0.001 to 100, accuracy calculated from the wind speed and surface



Manufacturer: PCE Instruments
US$ 304.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-007-ICA

This anemometer is very economical. With this anemometer you can measure wind speed and air temperature.

- Speed measurement up to 45 m/s or 100 mph
- Wind speed: 0.01 m/s, accuracy ±3% ±0.1
- Air temperature: 0.2°C / 32.4°F, accuracy ±1°C / 33.8°F
- Air flow: 0.001 to 100, accuracy calculated from the wind speed and surface
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 509.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-007-ICA

This anemometer is very economical. With this anemometer you can measure wind speed and air temperature.

- Speed measurement up to 45 m/s or 100 mph
- Wind speed: 0.01 m/s, accuracy ±3% ±0.1
- Air temperature: 0.2°C / 32.4°F, accuracy ±1°C / 33.8°F
- Air flow: 0.001 to 100, accuracy calculated from the wind speed and surface
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 509.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50-711

Besides the present wind speed, the Anemometer PCE-WSAC 50-711 shows the average wind speed of the previous 2 minutes and 5 minutes. This anemometer is very sensitive allowing recording of low wind speeds. The anemometer can be utilised in many wind recording applications across all industry sectors, e.g. building, quarrying, green energy and assembly lines.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 230 V AC
- Signal input: 4...20 mA
- Interface: RS-485 modbus
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 612.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-WSAC 50-820

Both the present wind speed and the average wind speed of the preceding two and five minutes are shown on the PCE-WSAC 500-820 anemometer. The large measurement range of the device is 0 to 110 mph. The anemometer is suitable for use across a whole range of industry sectors, including shipbuilding, petroleum and defence.


- Pre-alarm and full alarm with visual and audible warnings
- Measuring range: 0 ... 110 mph
- Power supply: 115 V AC
- Signal input: 0...10 V
- incl. ISO calibration certificate

Manufacturer: PCE Instruments
US$ 525.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
Order no.: PCE-009

This thermal anemometer has a good relation between price and quality and it combines accuracy and versatility with the ability to transfer data directly to a computer. This thermal anemometer forms a part of a professional's basic equipment to regulate and test ventilation systems. All the test instruments come manufacturer calibrated. ISO certification can be made as an option.


- Measurement range: 0.2 ... 20.0 m/s
- Measurement range: 0.0 ... 50.0°C / 32 ... 122°F (sensor)
- Volume of air current:  0 ... 36,000 m3/min
- Internal memory: 16,000 values
- Sampling rate: 1 sec



Manufacturer: PCE Instruments
US$ 735.00

ex. VAT, ex. delivery costs

Test Instruments manufacturer
