- Usable up to 80°C / 176°F
- Improves contact between the transducer head and the material to be measured
- Protects material surfaces from the transducer head
- 100 ml size
- See downloads for MSDS
Technical specifications |
Operating frequency range | 1 ... 10 MHz |
Measure time interval range (scan duration) | 6 ... 1000 microseconds (µs) |
Sound velocity range | 1000 ... 9999 m/s |
Deviation of measurement of time intervals | Not exceed ± 0.025 µs |
Max. deviation of amplitude of signals at receiver input in 0 ... 110 dB range | Not exceed ± 0.5 dB |
Testing gain region | 125 dB |
Averaging over the quantity of starts | 1 ... 16 |
Range of time-variable gain (TVG) / Number of control points TVG | 40 dB / 15 |
Duration of excitation pulse to load | 0 ... 0.5 µs |
Amplitude of excitation pulse to 50 Ohm load, not less | 100, 200, 300 |
Operating frequency range of receiver at -3 dB | 1 ... 10 MHz |
Deviation of amplitudes of input signals in 10 ... 100% range of screen height | Not more than 1 dB |
Scanning | 1 ... 1000 µs |
Scanning delay | 0 ... 2000 µs |
Measurement range of time intervals | 0 ... 1000 µs |
Prism of probe delay | 0 ... 15 µs |
Automatic signaling of defects (AFS) | Dual-gate |
Setting range of AFS gates | 0 ... 2000 µs |
Adjusting thresholds of AFS gates | 0 ... 100% |
Detection of signals (receiver) | Positive half-wave, radio mode |
Dimensions of device (approx.) | 80 x 162 x 35 mm / 3.14 x 6.37 x 1.37" |
Dimensions display (approx.) | 48 x 74 mm / 1.88 x 2.91" |
Power supply | 100 ... 250 V AC or 3 x 1.5 V AA batteries |
Weight (approx.) | 250 g / 0.55 lb (without batteries) |
ex. VAT, ex. delivery costs
ex. VAT, ex. delivery costs
Calibration block PCE-USC-V1 for PCE-USC 20, PCE-USC 30, and PCE-FD 20. Distance, beam index, refracted angle, and sensitivity calibration. In accordance with ASTM E164 specifications. Dimensions are 1" thickness.
Calibration block for training and test
ex. VAT, ex. delivery costs
Calibration block PCE-USC-V2 for PCE-USC 20, PCE-USC 30, and PCE-FD 20. Distance, beam index, refracted angle, and sensitivity calibration. Contains a 1.0" radius opposite a 2.0" radius, a 5/64" diameter x 0.750" deep flat-bottom hole. In accordance with ASTM E164 specifications. Dimensions are 1" thickness.
Calibration block for training and test
