PCE-PEL 20 Pellet Moisture Analyzer
1000 mm / 39.37"long acid-proof steel measuring probe
PCE-PEL 20 is a portable handheld digital moisture analyzer used to measure the moisture or water content of pellets and biomass such as sawdust, wood chips, straw, hay, sunflower shells, buckwheat, corn and soy. Designed in collaboration with biomass power plant operators, this pellet moisture analyzer features automatic temperature compensation.
The PCE-PEL 20 pellet moisture meter uses the resistance measuring method to determine a material's moisture or water content. Therefore, it is of great importance to select the appropriate characteristic curve and temperature when taking measurements with the pellet moisture meter. Simply plunge the measuring sensor probe into a pile of pellets and, once the value is stabilized, the moisture or water content percentage can be read. The pellet moisture tester only measures at the tip of its sensor probe. Thus, it is advised to perform several measurements at different points to achieve an adequate overview of the moisture or water content of a pile.
| Humidity | |
| Material | Pellet |
| Measuring range | 10 ... 20 % |
| Resolution | 0,1 % |
| General technical data | |
| Temperature compensation | manual, 0 ... 50°C / 32 ... 122°F |
| Display type | LCD |
| Operating time additional information | approx. 10,000 measurements |
| Automatic power-off | 10 min |
| Measurement time | 3 s |
| Dimensions | Electrode: Ø 10 mm x 1000 mm |
| Readability | 0,1 % |
| Menu language | English, English (GB) |
| Protection class (device) | IP41 |
| Power supply | batteries |
| (Rechargeable) battery | 1 x 12 V 23A , Alkali-manganese |
| Capacity | 50 mAh |
| Operating conditions | 0 ... 50 °C , 20 ... 85 % RH |
| Storage conditions | 0 ... 50 °C , 20 ... 85 % RH |
| Dimensions ( L x W x H ) | 60 x 50 x 1000 mm |
| Weight | 900 g |
