Order no.: PCE-TC 28

The Thermal Camera PCE-TC 28 was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the thermal camera can be adjusted, depending on the operation purpose. Besides taking infrared images, the camera can also take normal pictures, as well as a mixture of both, due to the built-in digital camera. This kind of test instruments help electricians and and maintenance workes in condition monitoring.

- Measurement range: -20 ... +300 °C
- Accuracy: ±2 %, ±2 °C
- Frequency image recording: 9 Hz
- Camera: 48608 Pixel

Manufacturer: PCE Instruments
£ 288.00

Price excl. VAT &. delivery

Order no.: PCE-VT 2700

The PCE-VT 2700 is a digital, battery-powered Vibration Meter ideal for measuring the vibration of parts, machinery, or other equipment. Small and lightweight, the Vibration Meter features peak hold functionality and shows acceleration, velocity, and displacement directly on its 4-digit LCD display, making it an especially handy inspection tool for maintenance staff and field personnel. These test instruments are calibrated by the manufacturer and an ISO calibration certificate is delivery included.

- Measurement range acceleration: 399.9 m/s² (Peak) / 1311 ft/s² (Peak)
- Resolution: 0.1 m/s² / 0.1 yd/s²; 0.1 mm/s / 0.003 in/s ; 1 µm / 3.3814e-14 oz ; 1 rpm
- Accuracy: ± 5% of reading + 2 digits
- ISO calibration certificate included

Manufacturer: PCE Instruments
£ 340.00

Price excl. VAT &. delivery

Order no.: PCE-VT 2700S

The PCE-VT 2700S Vibration Meter is ideal for maintenance personnel to quickly test vibrations at machine parts and installations. The Vibration Meter shows acceleration, velocity and vibration displacement measurement data on the display. These test instruments are calibrated by the manufacturer and an ISO calibration certificate is included. The PCE-VT 2700S comes with a special attachment to adapt the probe for handheld use.

- Ideal for measurements on-site
- Peak hold function
- ABS plastic enclosure
- 4-digit LCD, value last measured is displayed
- ISO calibration certificate is included

Manufacturer: PCE Instruments
£ 340.00

Price excl. VAT &. delivery

Order no.: PCE-WL 1

The airflow meter PCE-WL 1 is an ideal tool to measure and store the wind speed over a long period of time. The battery operation enables you to use this kind of airflow test instruments for mobile applications. Since a wind power station is an expensive investment, you usually want to know what profits it will generate in advance. As a test instruments manufacturer, PCE Instruments adjust and calibrate all testing equipment.

- Measuring range: 0.8 ... 40 m/s
- Accuracy: ±0.5 m/s or 5 % of measurement value
- Battery life up to 3 years
- 512 MB microSD card incl.

Manufacturer: PCE Instruments
£ 332.00

Price excl. VAT &. delivery

Order no.: PCE-CSM 3
The color meter PCE-CSM 3 was developed for quality control and offers a very high accuracy reading. When using the color meter, you can choose between different color spaces (CIE L*a*b*C*h, CIE L*a*b*). After a measurement with these color test instruments, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily. As a test instruments manufacturer, PCE Instruments adjust and calibrate all testing equipment.


- CIE L*a*b*C*h, CIE L*a*b*
- white calibration
- determination of reference values and samples
- measuring aperture is 8 mm

Manufacturer: PCE Instruments
£ 882.00

Price excl. VAT &. delivery

Order no.: PCE-CM 4

By using the electrical tester PCE-CM 4, you are able to perform AC measurements on electrical conductors without having to disconnect them. Just put the flexible clamp of these electrical test instruments around the conductor to be measured and start the measurement. The flexible design of the clamp allows measurements even on hard to reach conductors. All test instruments are sent out manufacturer calibrated and can additionally be equipped with an ISO calibration certificate.

- Measurement range: 4 A / 40 A / 400 A AC
- Resolution: 0.001 A / 0.01 A / 0.1 A AC
- Accuracy: ± 3 %
- easy to use

Manufacturer: PCE Instruments
£ 117.00

Price excl. VAT &. delivery

Order no.: PCE-EM 882

PCE-EM 882 is a portable, handheld, multifunctional digital device capable of measuring four different physical parameters. An ideal tool for use in industrial hygiene, HVAC performance assessment and environmental condition monitoring applications, this easy-to-use measuring instrument includes sensors for measuring sound, light, temperature and relative humidity.

- Sound: Low and high A- and C-weighted noise measurements from 35 ... 130 dB
- Light: 20, 200, 2000, 20000 lux ranges
- Temperature: Range from -20 ... +750 ºC / -4 ... +1400 ºF
- Relative humidity (RH): Range from 25 ...95% RH

Manufacturer: PCE Instruments
£ 64.00

Price excl. VAT &. delivery

Order no.: PCE-ATP 1

PCE-ATP 1 is a food / hygiene test instrument, lumitester or luminometer used in the food, pharmaceutical, hygiene, healthcare, hospitality and janitorial industry. This lumitester allows for quick and easy first-generation adenosine triphosphate (ATP) surface testing and monitoring to ensure proper cleanliness, sterilization and sanitization.

- measurement range: of 0 ... 999999
- data records to internal memory
- allows very fast testing (you get precise results in seconds)

Manufacturer: PCE Instruments
£ 683.00

Price excl. VAT &. delivery

Order no.: PCE-DFG 500

The PCE-DFG 500 digital Force Test Instrument or Gauge is used to conduct tensile and compressive force tests up to 500 N. The Force Gauge can take precise measurements with a resolution of 0.05 N. The PCE-DFG 500 digital Force Test Instrument is the ideal device for performing quality control inspections during the manufacturing production assembly line process, for inspecting incoming and outgoing shipments and goods, and for researching, developing, and testing new products and materials.



- Measuring range: 0 ... 500 N
- Resolution: 0.05 N
- Accuracy: ±0.1 % F.S.
- Sampling rate: 2000 Hz
- Interface: RS-232 and USB ports
- Measuring units: mN, N, gf, kgf, ozf, kg, lbf (selectable)
- Factory calibration certificate included

Manufacturer: PCE Instruments
£ 452.00

Price excl. VAT &. delivery

Order no.: PCE-LFG 10

The PCE-LFG 10 Force Test Instrument brings force measurement technology to the user on site. The digital Force Test Instrument is made for tensile and compressive force measurements and has a measuring range of 10 N. The Force Test Instrument is suitable for precise measurements with its high resolution of 0.001 N. All these test instruments are sent out manufacturer calibrated including an ISO calibration certificate.

- Measuring range: 0 ... 10 N
- Resolution: 0.001 N
- Accuracy: ±0.1 % F.S.
- Memory size: 1,000 values
- RS-232 / USB interface
- Illuminated control panel
- Included ISO calibration certificate

Manufacturer: PCE Instruments
£ 487.00

Price excl. VAT &. delivery

Order no.: PCE-LFG 20

Force measurement technology for the user on site. The digital Force Test Instrument PCE-LFG 20 for tensile and compressive force measurements can be used up to a measuring range of 20 N. The force meter with its high resolution of 0.005 N is suitable for precise measurements. All this type of test instruments is sent out manufacturer calibrated including an ISO calibration certificate.

- Measurement range: 0 ... 20 N
- Resolution: 0.005 N
- Accuracy: ±0.1 % F.S.
- Tensile and compressive force measurement
- Illuminated control panel
- Memory size: 1,000 values
- RS-232 / USB interface
- Incl. an ISO calibration certificate

Manufacturer: PCE Instruments
£ 487.00

Price excl. VAT &. delivery

Order no.: PCE-LFG 5

The PCE-LFG 5 Force Test Instrument brings force measurement technology for the user on site. The digital Force Test Instrument for tensile and compressive force measurements can be used up to a measuring range of 5 N. The Force Test Instrument with its high resolution of 0.0005 N is suitable for precise measurements. As a precision testing tool, this kind of test instruments comes manufacturer calibrated and is also ISO certificated.

- Measurement range: 0 ... 5 N
- Resolution: 0.0005 N
- Tensile and compressive force measurement
- High measuring accuracy
- Illuminated control panel
- Incl. calibration certificate

Manufacturer: PCE Instruments
£ 487.00

Price excl. VAT &. delivery

Order no.: PCE-WMM 50
The gas detector PCE-WMM 50 is an inexpensive alarm instrument to detect carbon dioxide (CO2). The gas detector protects against the health hazards of the colourless and odourless gas that is used in the food industry, the metal industry and in chemical processes in waste management. The gas detector PCE-WMM 50 is divided into two parts: The detector is placed in the danger area, the reporting unit outside that area. This kind of test instruments helps to save lives.

- Detection of carbon dioxide (CO2)
- 2 adjustable alarm thresholds
- 4-digit display
- Easy mounting on wall
Manufacturer: PCE Instruments
£ 327.00

Price excl. VAT &. delivery

Order no.: PCE-SGM 60
The PCE-SGM 60 gloss meter with small measuring area is used on many types of surfaces to quantify their gloss units. This gloss-measuring device operates on the reflection principle by sending light from a calibrated light source onto the surface to be tested and then calculates the gloss level of the surface according to the reflection of light particles. These gloss test instruments allow you to measure very high gloss surfaces above 70 gloss units (GU).


- Measurement geometry: 60 °
- Measurement up to 1000 gloss units
- Internal reading memory up to 5000 readings
- 3.5" TFT display

Manufacturer: PCE Instruments
£ 679.00

Price excl. VAT &. delivery

Order no.: PCE-900

PCE-900 is a digital, handheld hardness testing device or portable Leeb rebound hardness meter used to measure metal surface hardness. This type of test instruments come manufacturer adjusted incl. ISO calibration certificate. Precise and versatile, this Leeb hardness tester:

- Displays measurements in: Leeb, Rockwell C, Rockwell B, Brinell, Vickers or Shore hardness units
- Offers an accuracy of ±0.8 % @ HLD = 900
- Includes external sensor with type D impact body
- Connects to PC via RS232 serial port
- Supplied with factory ISO calibration certificate

Manufacturer: PCE Instruments
£ 564.00

Price excl. VAT &. delivery

Order no.: PCE-A

Mechanical shore durometer for measuring the hardness of soft rubber and plastic. The PCE-A Durometer is a standard model for measuring the hardness of rubber (Shore A). The Durometer is composed of a device with a pressure pin and a 360° anti-glare dial with an accuracy to within 0.5 hardness units. Meets standards DIN 53505, ISO 868, ISO 7619 and ASTM D2240. This type of test instruments comes manufacturer adjusted. An ISO calibration certificate can be ordered as option.

- Testing force: 12.5 N
- Penetrating body: 35°
- Diameter of dial: 57 mm
- Total length: 123 mm
- Follows ASTM D2240

Manufacturer: PCE Instruments
£ 426.00

Price excl. VAT &. delivery

Order no.: PCE-DSD-A

PCE-DSD-A is a digital hardness tester or durometer used to measure the surface hardness of rubber, plastic and other nonmetals. Designed with high-quality components to provide years of accurate measurements, this handheld durometer works by measuring soft to semi-soft materials' resistance to indentation. The included protective carrying case allows for ease of portability. This type of test instruments come manufacturer adjusted. An ISO calibration certificate can be ordered as an option.

- High end digital Shore A durometer
- Measures in accordance to:
  ISO 7619, ISO 868 and ASTM D 2240 standards
- Features a measuring range of 0.5 ... 100 hardness units
- RS232 interface
- Supplied with a factory calibration certificate

Manufacturer: PCE Instruments
£ 1,205.00

Price excl. VAT &. delivery

Order no.: PCE-HT-225A

PCE-HT-225A is a hardness test instrument or concrete test hammer, also called a concrete rebound hammer, Schmidt hammer or Swiss hammer, used for non-destructive measurements of surface hardness and compression strength. Suitable for use with concrete, rock and building materials, this manufacturer-calibrated manual rebound hammer is economical, practical and easy to use.


- Test range: 10 ... 60 MPa or 100 ... 600 kg/cm² (1450.38 ... 8702.26 psi)
- Impact energy: 2207 J or N-m (1627.8 ft-lb)
- Impact stroke: 75 mm ± 0.3 mm (2.95" ± 0.012")
- Radius of spherical tip: 25 mm ± 1 mm (0.99" ± 0.04")
- kg/cm² and MPa conversion tables on back of instrument and in user manual

Manufacturer: PCE Instruments
£ 309.00

Price excl. VAT &. delivery

Order no.: PCE-330

The PCE-330 Hygrometer is ideal for rapid measurement of ambient temperature and humidity. The precise Hygrometer also allows the dew point (dew point temperature) to be determined. The Hygrometer is equipped with an easy to read display and has a large memory (16,000 values) for recording the measured values. Especially the humidity sensor has a time drift. So all humidity measurement test instruments should be calibrated regularly. An ISO calibration certificate can be ordered as an option.

- High
precision (±2 % r.H.)
- Fast measurement
- Data Logger 16,000 values
- Interface + Software

Manufacturer: PCE Instruments
£ 194.00

Price excl. VAT &. delivery

Order no.: PCE-HT110

The PCE-HT110 Humidity Test Instrument or Humidity Detector precisely measures air temperature and relative humidity. This accurate and reliable device shows the current measurements on the large LCD display and saves the measurement data directly to an SD card (included). The PCE-HT110 is equipped with two channels, accommodates an SD card memory of up to 16 GB, offers an adjustable measurement rate / sampling interval, and includes a wall mount, making the device ideal for logging data over an extended period of time.

- Measurement ranges: 0 … +50 °C / 32 °F ... 122 °F, 10 ... 90 % RH
- Resolution: 0.1 °C / 0.1 % RH
- Data format: .XLS (compatible with Microsoft Excel)

Manufacturer: PCE Instruments
£ 117.00

Price excl. VAT &. delivery




Custom made test instruments

Besides a wide range of the products in general and testing instruments, in particular, which you may find on our site for sale, there is also a possibility to get an absolutely unique instrument fitting only your personal need and desire.

Are you looking for custom test instruments?
PCE Instruments custom design group provides test instruments and test equipment for customers that is not available off the shelf (1tailor–made). The Engineering team has been providing high-quality services to global customers since 1999. We can deliver testing solutions to customers that meet their requirements for features, cost, and schedule. As a German manufacturer and supplier of high quality products and test instruments solutions, skilled Test instruments (tailor-made and manufactured in Germany)engineers and technical staff make use of their knowledge and experience for the development and design of new test equipment and test instruments. PCE Instruments will put the expertise to work for you to help specify, setup, integrate, and validate the measurement and inspection equipment you need.

PCE Instruments engineers, technicians, and sales agents, work hand-in-hand with the customer experts to clearly define the specifications to be sure that the final test instruments exceed expectations. We have our own High quality test instruments manufacturerand supplierPCE-branded industrial test instruments series but we can also design and manufacture modified test equipment, especially in the field of force, pressure, vibration, humidity, temperature and moisture measurement, based upon ustomers’ special needs.

PCE uses long-term business relationships with high quality suppliers and qualified calibration laboratories (main measurement parameters as force, vibration and moisture inhouse calibrated) to ensure the costumers not only get the equipment they need, but also industrial, professional services and post-sales technical support. Several cross-country co-operations with universities and technical institutions have proven to push huge achievements in development and production / manufacturing process. Let a PCE Instruments sales representative work with you on a cost-effective custom solution, please call us with your test equipment / test instruments requirement.
ISO certified test instruments manufacturer
Industrial test instruments / testers developed and manufactured by PCE (also for custom made products) come with an ISO manufacturer or factory calibration certificate confirming compliance with the highest possible quality standards in measurement. PCE Produktions- und Entwicklungsgesellschaft mbH is certified according to DIN EN ISO 9001 : 2008.

More information on Test Instruments

IP Housing Protection Classes
The majority of devices and test instruments have got an inscription IP with the two-digit number following the letters, and though the letters ever remain the same IP (Ingress Protection or Internal/International Protection), the numbers may be different, for example, IP20, IP54, IP65, IP67 and the others.

Any customer would like to have test instruments which have got a longer service life, provide reliable results and are robust to various impacts from outside. That is why the housing can be designed in such a way so that to protect the internal “feeling” of the device from the damage that can be caused by water, solid items of different nature, dust, shocks…

The number after IP … … indicates in fact what the device is protected from, since, both, the first and the second digit, have got a particular explanation. “0” always means that there is no protection, and depending on the position of the “0”, the user may detect, either it is not protected against the impact of solids or water. If instead one of the number there is letter X it means that the level of protection on this criterion has not been precisely determined.

The first digit (can be from 0 to 6 or letter X) always indicates the level of protection from the intrusion of solid items or objects coming from outside, including parts of the human body. The smaller the number, the bigger the size of the object may be. Protection agains waterFor example, test instruments with the IP 20 provide protection against the objects bigger than 12 mm, for example, finger. The digits 4, 5, 6 mean the reduction of the size of the object that may intrude, since they provide protection against the thin wire. If the application of the device involves operation in very dirty dusty environment, the device should have at least 5, better 6 as the first digit, since devices with the IP 5…/6… are dust protected / dustproof correspondingly.

The second digit (0 to 8 or letter X) indicates the level of protection from water penetration (water drops, water flow, water sprinkles, immersing into water). An angle at which the water drop or spray can affect the test instruments also matter, so, for example, IP … 2 gives the protection against the water drops at an angle not more than 15°, IP …3 – at an angle not more than 60° (for example, it can be rain), on condition that test instruments are under normal operating conditions. The highest digits 7 / 8 provide full protection even under the condition of immersing the test instruments under water. The devices retain all its functions and operating abilities.

IP 54 is considered to be the standard. It provides sufficient protection for the equipment, not meant to be applied under extreme conditions. It is protected from dust intrusion that can damage the device and is safe from water sprinkles, not depending on the direction or angle.

IP 67 is a higher protection class. 6 is the highest possible protection from the solid particles, thus, it means absolutely dustproof device. 7 indicates very high level of protection from water, even when the device is plunged into the water completely or partly not deeper than 1 m.

0 NO protection 0 NO protection
1 Protection against solid objects (including body parts: hand, foot…) of the size more than 50 mm 1 Protection against falling vertically down drops
2 Protection against solid objects (including fingers), of the size not less than 12 mm 2 Protection against drops, falling at an angle of no more than 15 ° (equipment in the normal position).
3 Protection against solid objects (wire, instruments) with the DIA not less than 2.5 mm 3 Protection against the drops and water jets, falling from the top at an angle to the vertical of no more than 60 ° (equipment in the normal position).
4 Protection against solid objects (wire, instruments) with the DIA not less than 1 mm 4 Protection against dropping or splashing (any angle).
5 Partial protection against dust (the amount of dust penetrating into the device does not influence its operation). Full protection against accidental penetration 5 Protection against water jets (any angle)
6 Full protection against accidental penetration and dust. 6 Protection against water jets (any angle) under all kinds of pressure. But, it means water resistant nor waterproof!
    7 Protection against water ingress during temporary immersion in water. No damage to equipment only at a certain depth and time of immersion.
    8 Protection against water ingress during constant immersion in water. Water does not cause damage to equipment under specified conditions and unlimited time of immersion.


Addition of the third / sometimes fourth symbol is auxiliary, indicating additional functions. For example, IP 69K means the test instruments are not only fully dustproof, but also waterproof and remain safe under the influence of hot water under pressure.

In spite of water resistance, the difference should be made between sweet and salty water. Very often, test instruments with the sufficient IP protection (dust- and water resistant/proof) may fail under the influence of salty water, because of the properties salt has got and its corrosive influence. That is why test instruments meant for application not only under water, but for immersion in salty water, need to have a special mark made by the producer, confirming that the housing has been designed especially for this application. The same applies for very high / cold temperatures or application in the environment containing particles finer than dust.
