PCE Instruments

Viscometer / Viscosity Meter

Order no.: PCE-RVI 1

PCE-RVI 1 is an analogue viscometer or dial reading viscometer used in industrial and research applications to measure the viscosity of fluids such as paints, lacquers, inks, pastes, adhesives, plastics, greases and liquid food products. Under identical conditions, test results from an analogue viscometer are as accurate and reproducible as results from a digital viscometer. Thus, the PCE-RVI 1 analogue viscometer offers an affordable solution for viscosity measurement during product and material testing, development, production and quality control.


- Rotational speed: 6, 12, 30, and 60 rpm
- Viscosity range: 10 ... 100,000 mPa.s / cP
- Accuracy: ±5 % full scale (FS) in Newtonian fluids

Manufacturer: PCE Instruments
£ 614.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 2
The viscometer has a measuring range of 1 ... 100,000 cP. With an accuracy of <±2% of the range, the viscometer is a precise measuring device to determine the viscosity of a sample liquid.

- Measuring range: 1 ... 100,000 cP
- Measurement accuracy: <±2% of measuring range
- Resolution: 0.01 cP
- Spindle set consisting of L1, L2, L3, L4
- Temperature measurement
Manufacturer: PCE Instruments
£ 796.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 10
The rotary viscometer uses the mechanical resistance of any liquid to measure viscosity using rotational movement of a spindle. This results in a torque that is recognized by the rotary viscometer and converted into a viscosity value. With an accuracy of ± 1.0%, the rotary viscometer is a very precise measuring device despite the high measuring range of 10 … 2,000,000 cP (mPa*s).

- Viscosity measuring range: 10 ... 2,000,000 cP
- Accuracy: ± 1% of full scale (with Newtonian liquid)
- Rotation speeds: 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm
- Various viscosity units can be displayed (mPa*s, Pa*s, dPa*s, cP, P, cPs)
- Includes 4 spindles in the kit, an optional spindle (L0) measures down to 1 cP
Manufacturer: PCE Instruments
£ 2,024.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 2 V1R

PCE-RVI 2 V1R is a rotational viscometer used in industrial and research applications to measure viscosity according to BS, ISO and ASTM standards. Featuring a plug-and-play sensor for temperature control to help ensure accurate test results, this digital viscometer is delivered with spindles R2, R3, R4, R5, R6 and R7 and displays measurements in millipascal-second (mPa.s) or centipoise (cP), depending on the rotational speed and the type of spindle used.


- Rotational speed: 0.3, 0.5, 0.6, 1, 1.5, 2, 2.5, 3, 4, 5, 6, 10, 12, 20, 30, 50, 60,
  100, 200 rpm

- Viscosity range: 20  ... 13,000,000 mPa.s / cP
- Accuracy: ±1 % full scale (FS)



Manufacturer: PCE Instruments
£ 2,128.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 2 V1L

PCE-RVI 2 V1L is a rotational viscometer used in industrial and research applications to measure viscosity according to BS, ISO and ASTM standards. Featuring a plug-and-play sensor for temperature control to help ensure accurate test results, this digital viscometer is delivered with spindles L1, L2, L3 and L4 and displays measurements in millipascal-second (mPa.s) or centipoise (cP), depending on the rotational speed and the type of spindle used.


- Rotational speed: 0.3, 0.5, 0.6, 1, 1.5, 2, 2.5, 3, 4, 5, 6, 10, 12, 20, 30, 50, 60,
  100, 200 rpm

- Viscosity range: 3  ... 2,000,000 mPa.s / cP
- Accuracy: ±1 % full scale (FS)



Manufacturer: PCE Instruments
£ 2,128.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 3 VP20

PCE-RVI 3 VP20 is a portable rotational viscometer used in industrial and research applications to measure viscosity according to the Brookfield method. Featuring an ergonomic design and up to 30 hours of battery life during continuous operation, this handheld viscometer is delivered with spindles R2, R3, R4, R5, R6 and R7 and displays measurements in millipascal-second (mPa.s).


- Rotational speed: 20 rpm
- Viscosity range: 200  ... 200,000 mPa.s / cP
- Accuracy: ±2 % reading (RD)



Manufacturer: PCE Instruments
£ 1,420.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 4 VP 20

PCE-RVI 4 VP20 is a rotational viscometer used in industrial and research applications to measure viscosity according to the Brookfield method. Featuring a simple, lightweight construction for ease of portability, this digital viscometer can be used in the laboratory or in the field. This viscometer is delivered with spindles R2, R3, R4, R5, R6 and R7 and displays measurements in millipascal-second (mPa.s).


- Rotational speed: 20 rpm
- Viscosity range: 200 ... 200,000 mPa.s / cP
- Accuracy: ±2% full scale (FS)



Manufacturer: PCE Instruments
£ 1,420.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-RVI 8
The viscometer / viscosity meter has a measuring range of 27…. 5250 cp and an accuracy of +1% of the measuring range. The viscometer is used, for example, in quality control of production processes. In addition, the viscometer is particularly used in laboratories of all kinds.

- Measuring range: 27 ... 5250 cp
- Rotation speed: 200 RPM
- Volume measuring cup: 600 ml
- Large touch screen for easy operation
- Temperature measuring range: -20 ... 250 °C / -4 ... 482 °F
Manufacturer: PCE Instruments
£ 1,326.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: Viscolite d15

Viscolite d15 is a portable resonant or vibrational viscometer used in industrial and research applications to measure viscosity in very small to large samples 10 ml / 10cc / 0.39 oz and up. Featuring a built-in thermometer and a nearly maintenance-free design with no openly rotating parts, this handheld viscometer is delivered with one 316L stainless steel measuring probe and displays measurements in centipoise (cP). The energy loss measurement during vibration yields very high accuracy in very small vessels.


- Uses resonant vibration to measure fluid viscosity
- Viscosity range: 0 ... 5,000 cP (mPa.S)
- Reproducibility is better than 1%
- Small sample of only 10 cc required
- No moving parts to damage, easy cleanup, and virtually maintenance free



Manufacturer: Hydramotion
£ 4,138.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-127/4
DIN flow cup viscometers are viscosity meters to determine the viscosity of liquids. The flow cup viscometers are often used in industry and research laboratories.

- Capacity: 100 ml
- Ø nozzle: 4 mm (± 0.02 mm)
- Material: anodized aluminum
- Standard: DIN 53211
Manufacturer: PCE Instruments
£ 125.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-128/3
ISO flow cup viscometers are suitable for determining the flow time of Newtonian / near-Newtonian liquids and are often used in laboratories and industrial production.

- Measuring range: 7 ... 42 cSt
- Ø nozzle: 3 mm
- Material: anodized aluminum and stainless steel
- Standard: ISO 2431, DIN 53224, EN 535, ASTM D5125
Manufacturer: PCE Instruments
£ 129.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-125/2
Ford flow cup viscometers are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 25 ... 120 mm²/s
- Ø nozzle: 2 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-125/3
Ford flow cup viscometers are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 49 ... 220 mm²/s
- Ø nozzle: 3 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-125/4
Ford flow cup viscometers are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 70 ... 370 mm²/s
- Ø nozzle: 4 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-125/5
Ford flow cup viscometers are used to measure liquids quickly and easily in order to determine their viscosity. However, it must be taken into account that this is only possible with less viscous liquids.

- Measuring range: 214 ... 1413 mm²/s
- Ø nozzle: 5 mm
- Material: anodized aluminum and stainless steel
- Standard: International Standard ASTM D1200, D333 and D365
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-128/4
ISO flow cup viscometers are suitable for determining the flow time of Newtonian / near-Newtonian liquids and are often used in laboratories and industrial production.

- Measuring range: 34 ... 135 cSt
- Ø nozzle: 4 mm
- Material: anodized aluminum and stainless steel
- Standard: ISO 2431, DIN 53224, EN 535, ASTM D5125
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-128/5
ISO flow cup viscometers are suitable for determining the flow time of Newtonian / near-Newtonian liquids and are often used in laboratories and industrial production.

- Measuring range: 91 ... 326 cSt
- Ø nozzle: 5 mm
- Material: anodized aluminum and stainless steel
- Standard: ISO 2431, DIN 53224, EN 535, ASTM D5125
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-128/6
ISO flow cup viscometers are suitable for determining the flow time of Newtonian / near-Newtonian liquids and are often used in laboratories and industrial production.

- Measuring range: 188 ... 684 cSt
- Ø nozzle: 6 mm
- Material: anodized aluminum and stainless steel
- Standard: ISO 2431, DIN 53224, EN 535, ASTM D5125
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-128/8
ISO flow cup viscometers are suitable for determining the flow time of Newtonian / near-Newtonian liquids and are often used in laboratories and industrial production.

- Measuring range: 600 ... 2000 cSt
- Ø nozzle: 8 mm
- Material: anodized aluminum and stainless steel
- Standard: ISO 2431, DIN 53224, EN 535, ASTM D5125
Manufacturer: PCE Instruments
£ 133.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-127/4P
DIN immersion flow cup viscometers are viscosity meters to determine the viscosity of liquids. The immersion flow cup viscometers are often used in industry and research laboratories.

- Capacity: 100 ml
- Ø nozzle: 4 mm (± 0.02 mm)
- Material: anodized aluminum
- Standard: DIN 53211
Manufacturer: PCE Instruments
£ 151.00

Price excl. VAT &. delivery
2 year Warranty
