Vibration Analyzer / Vibration Analyser

Order no.: PCE-HAV 100
The vibration analyzer is a versatile hand-arm vibration meter. The main feature of the vibration analyzer is the human vibration exposure assessment according to the ISO standards ISO 8041: 2005 and ISO 5349: 2001.

Measuring range:
- Low: 0.05 ... 200.0 m/s² / 0.005 ... 20.4 g
- High: 0.50 ... 2000.0 m/s² / 0.05 ... 204.0 g
- Linear operating range: 72 dB
- Frequency weighting: Hand Arm Filter
- Vibration sensor: ACM-PCE-HAV 100, 10 mV/g
- Memory: 992 readings
- Factory certificate

- Upgrade to professional analysis software (optional)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 1100

The vibration analyzer is used as a hand-held measuring device for the individual assessment of vibrations on machines and systems. With the help of this vibration analyzer, the actual state can easily be determined on site. Thus, corresponding changes can be made directly on site after the measurement.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Easy to handle and battery operated
- Standard probe: 10mm

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 1100S

The PCE-VT 1100S vibration analyzer is suitable for relative measurements on various machines. With the 45 mm long needle probe, you can access hard-to-reach places in machines and motors. For this reason, this vibration analyzer is used for rapid measurement of imbalance and for checking bearing and gear conditions.

- Frequency range: 10 Hz ... 1 kHz
- Measures speed, distance, acceleration in metric units
- Holds the reading after each measurement
- Portable and battery operated
- Needle probe: 45mm / 1.77"

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 2700S

PCE-VT 2700S is a factory-calibrated (certificate included) portable digital battery-powered handheld vibration analyzer used to monitor the radial and axial vibration of industrial machines, equipment and parts such as bearings and gearboxes. The PCE-VT 2700S comes with a special attachment to adapt the probe for handheld use.


- Frequency range: 9 Hz ... 1 kHz (in 1 kHz mode) / 9 Hz ... 10 kHz (in 10 kHz
  mode) acceleration; 10 Hz ... 1 kHz velocity / displacement
- Resolution: 0.1 m/s² / 0.1 yd/s²; 0.1 mm/s / 0.003 in/s ; 1 µm / 3.3814e-14 oz ;
  1 rpm
- Accuracy: ± 5% of reading + 2 digits
- ISO calibration certificate included



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 2700

PCE-VT 2700 is a factory-calibrated (certificate included) portable digital battery-powered vibration analyzer used to monitor the radial and axial vibration of industrial machines, equipment and parts such as bearings and gearboxes.


- Frequency range: 9 Hz ... 1 kHz (in 1 kHz mode) / 9 Hz ... 10 kHz (in 10 kHz
  mode) acceleration; 10 Hz ... 1 kHz velocity / displacement
- Resolution: 0.1 m/s² / 0.1 yd/s²; 0.1 mm/s / 0.003 in/s ; 1 µm / 3.3814e-14 oz ;
  1 rpm
- Accuracy: ± 5% of reading + 2 digits
- ISO calibration certificate included



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VDL 16I
The vibration analyzer PCE-VDL 16I from PCE Instruments measures and stores the relevant measured variables: temperature, relative humidity, air pressure, light as well as acceleration in three axes by means of a vibration sensor. Therefore, this vibration analyzer is ideal for monitoring vibrations on machines while simultaneously measuring and recording the relevant environmental conditions of the system.

- 3-Axis acceleration up to 800 Hz
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Temperature, Humidity, Air pressure, Vibration, and Light
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VDL 24I
For this vibration analyzer PCE-VDL 24I the acceleration sensor is delivered with a sampling rate of 1600 Hz. The sensor measures the acceleration, which is currently acting on it (3 axes), for example shock / vibration. The measurements take place at predetermined (selectable) time intervals.

- 3-Axis acceleration up to 1600 Hz and ±16 g
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VD 3

The PCE-VD 3 Vibration analyzer is a miniaturized universal Vibration analyzer with an included built-in three-axes acceleration sensor (X, Y, Z axis). The internal sensor of the PCE-VD 3 Vibration analyzer measures acceleration force along the X, Y, and Z axes with a measurement range of ±18 g per axis.


- 3-axis vibration data logging
- Software included -USB port
- Light weight
- Stand included
- Storage capacity: 4 Mbit (85764 records)
- Magnetic wall mount



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VS10

PCE-VS10 is a vibration meter, analyzer or sensor condition monitoring switch used to measure RMS and peak value of vibration velocity or acceleration piezoelectrically. This IP67-rated vibration monitoring switch features a red and green visual warning or alarm with programmable high pass and low pass filters.


- Frequency range (max.): 0.1 Hz ...10 kHz
- Measuring range: Acceleration = 0.1 ... 1000 m/s², Speed = Frequency-dependent
- Connections: Screw terminals for power supply (5 ... 30V DC) and Micro USB (internal)
- Mounting: M8 stud bolt

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VS11

PCE-VS11 is a vibration meter, analyzer or sensor condition monitoring switch used to measure RMS value, peak value and frequency domain (FFT) of vibration velocity or acceleration piezoelectrically. This IP67-rated vibration monitoring switch features a red and green visual warning or alarm with programmable high pass and low pass filters.


- Frequency range (max.): 0.1 Hz ...10 kHz
- Measuring range: Acceleration = 0.1 ... 1000 m/s², Speed = Frequency-dependent
- Connections: Screw terminals for power supply (5 ... 30V DC) and Micro USB (internal)
- Mounting: M8 stud bolt

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VS12

PCE-VS12 is a vibration meter, analyzer or sensor condition monitoring switch used to measure RMS value, peak value and frequency domain (FFT) of vibration velocity or acceleration piezoelectrically. This IP67-rated vibration monitoring switch features an external USB port, 8-pin female connector 711 and programmable high pass and low pass filters.


- Frequency range (max.): 0.1 Hz ...10 kHz
- Measuring range: Acceleration = 0.1 ... 1000 m/s², Speed = Frequency-dependent
- Connections: Screw terminals for power supply (5 ... 30V DC) and Micro USB (internal)
- Mounting: M8 stud bolt

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VDR 10

PCE-VDR 10 is a single-axis accelerometer or vibration analyzer with real-time measurement and data logging capabilities. This vibration monitor records acceleration (m/s, g, ft/s) as well as speed (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory.


- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Speed measuring range:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 2800

The PCE-VT 2800 Vibration Analyzer measures acceleration, oscillation speed and shift of vibrating parts, machines and equipment. The device features an integrated data logger to record vibration measurements over time. Measurement data is stored on an SD card memory and can be transferred directly to a PC via USB or RS-232 interface.


- Handheld instrument with vibration data logging function
- Frequency range: 10 Hz ... 1 KHz
- True-RMS (TRMS), max-hold, data-hold and peak-value functionality
- Adjustable sampling rate



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 3D

The PCE-VM 3D Vibration Analyzer provides quick and simple measurements of acceleration and displacement to check the acceleration of machines and construction parts, allowing for defects and larger unbalances to be determined. The PCE-VM 3D Vibration Analyzer is able to record vibration in three dimensions: on the x-, y-, and z- axes. The large display of the PCE-VM 3D Vibration Analyzer allows capturing momentary values as well as recording a whole vibration spectrum.


- Vibration acceleration: 0.1 m/s² ... 400.0 m/s² (Peak); (0 ... 40 g force)
- Vibration velocity: 0.01 ... 400.0 mm/s
- Vibration amplitude: 0.001 mm ... 4.000 mm (Peak-Peak)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 204

PCE-VT 204 is a multifunction handheld vibration analyzer with the ability to accurately measure both rotation and vibration. An ideal tool for the testing and inspection of machine parts and components such as motors, transmissions, gears, gear boxes and wheels, this multi-purpose device measures revolutions per minute (RPMs) as well as three-axis vibration, i.e., speed or velocity, displacement and acceleration.


- Vibration measurement: Velocity or speed, acceleration and displacement
- RPM measurement: Contact / mechanical and noncontact / optical
- Internal memory for up to 1000 readings
- Min / max and data hold functions
- RS-232 port



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VMS 501

The wireless PCE-VMS 501 Vibration Analyzer Sensor detects vibration within an acceleration range of up to 30 g and a frequency range between 5 and 10 KHz. The wireless vibration sensor, which measures vibrations at machines to transfer those wireless vibrations to a receiving unit.


- Acceleration range: up to 300 m/s2
- Wireless communication via ZigBee
- Frequency range between 5 Hz and 10 kHz
- Wireless transferring Piezo sensors
- Transmission rate of 1 minute per sensor



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 25

The PCE-VM 25 Vibration analyzer is designed for engine monitoring to assure a smooth operation of machines. Due to its simple application, the Vibration analyzer can be used for the measurement of a large range of parameters including acceleration, velocity and displacement.


- Vibration velocity range 10 Hz ... 10 kHz, displacement to 60 mm
- True RMS, Max Hold, peak value
- OLED display
- Measurement memory
- VMID measuring point function



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 5000

The 4-channel PCE-VM 5000 Vibration Analyzer performs vibration measurements on up to 4 places at the same time. The vibration velocity, acceleration, and displacement in a frequency range of 10 Hz to 1 kHz can be measured. The cables of the vibration sensors are 1.2 m long, so the vibration measuring device is able to record vibrations at different points of the component to be tested.


- Frequency range: 10 Hz ... 1 kHz
- Measurement of acceleration, velocity and displacement
- Connection of up to 4 sensors simultaneously, 2 included
- Data storage on SD card



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 20
The vibration analyzer PCE-VM 20 is a compact device for direct evaluation of the vibration behavior of a machine. The vibration analyzer can measure and display various vibration parameters, such as vibration acceleration, vibration velocity or vibration displacement.

- Vibration acceleration: 0 ... 200 m / s², RMS and peak-peak
- Vibration speed: 0 ... 200 mm / s, RMS
- Vibration distance: 0 ... 2000 μm, peak-peak
- Real-time FFT analysis
- Direct evaluation according to DIN ISO 10816
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VM 31

The PCE-VM 31 Human Vibration Analyzer is designed for measuring human vibration at the workplace. The Vibration Analyzer can calculate hand-arm vibration measurements according to ISO 5349 and whole-body vibration measurements according to ISO 2631.


- Measuring of human vibration at the workplace
- Velocity, acceleration, displacement
- 3 channel FFT
- TEDS support
- Sensors not included - sold separately (see accessories)



Manufacturer: PCE Instruments
Test Instruments manufacturer
