Universal Testing Machine

A universal testing machine is used to assess the strength of materials. A universal testing machine offers enhanced control and stability during a materials testing process. A universal testing machine also helps ensure accuracy and repeatability. The strength or mechanics of materials is an area of materials science focused on calculating material stresses and strains. A number of tensile strength and compressive strength materials tests exist, including but not limited to tear, elongation, elasticity, plasticity, 3-point bend, deflection, deformation, fatigue, fracture and failure tests. The range of tests is so wide that it allows for testing a wide range of materials under very different conditions (e.g., different speeds, loading rates, forces, etc.).

Materials testing conducted with the help of a universal testing machine should be carried out in compliance with standards established by entities such as DIN, ISO and ASTM. In addition, proper safety precautions should be taken to prevent accident and injury. For example, commonly referenced standards for the testing of plastic and rubber materials using a universal testing machine include DIN 51233, ISO 527 and ISO 37. As PCE Instruments (PCE) is committed to worker safety and protection, each PCE-branded universal testing machine is manufactured in compliance with the machinery directive 2006/42/EG.

Product introduction video:

Universal Testing Machine PCE-MTS500

Universal Testing Machine PCE-MTS500
Watch video

If you have any questions about the products on this website, please contact us at or +44 ( 0 ) 161 464902 0.

Universal Testing Machine PCE-TWT 10N

£ 74.00

Price excl. VAT &. delivery

The Universal Testing Machine is a compact, portable precision tool for applications where exact torque values are crucial. It has an easy-to-read display with backlighting that provides clear values even in poor lighting conditions. Our Universal Testing Machines are primarily used in vehicle construction, mechanical engineering, bicycle assembly and in the electrical and electronics industry.

Torque: 0.001 ... 10 Nm
Resolution: 0.001 Nm
Accuracy: ±2% FS / ±2.5% FS
Units: Nm, kgf cm, lbf ft, lbf in
Internal memory: 999 values
Adjustable alarm

Universal Testing Machine PCE-TWT 30N

£ 76.00

Price excl. VAT &. delivery

Torque: 0.001 ... 30 Nm
Resolution: 0.001 Nm
Accuracy: ±2% FS / ±2.5% FS
Units: Nm, kgf cm, lbf ft, lbf in
Internal memory: 999 values
Adjustable alarm

Universal Testing Machine PCE-TWT 60N

£ 85.00

Price excl. VAT &. delivery

Torque: 0.01 ... 60 Nm
Resolution: 0.01 Nm
Accuracy: ±2% FS / ±2.5% FS
Units: Nm, kgf cm, lbf ft, lbf in
Internal memory: 999 values
Adjustable alarm

Universal Testing Machine PCE-TWT 100N

£ 89.00

Price excl. VAT &. delivery

Torque: 0.01 ... 100 Nm
Resolution: 0.01 Nm
Accuracy: ±2% FS / ±2.5% FS
Units: Nm, kgf cm, lbf ft, lbf in
Internal memory: 999 values
Adjustable alarm

Universal Testing Machine PCE-HTS 50

£ 1,487.00

Price excl. VAT &. delivery

The motorized tension-compression Universal Testing Machine is a motorized test station with a force range of up to 500 N. With the help of the horizontal Universal Testing Machine, it is possible to to carry out tension-compression tests.

Force range: 500 N / 50 kg / 110 lb
Distance display resolution: 0.02 mm
Resolution: 1 mm/min
Tensile and compression testing
Travel: 270 mm / 10.6"

Test Stand PCE-VTS 50

£ 1,635.00

Price excl. VAT &. delivery

This vertical force test stand is a motorized test station with a force range of up to 500 N. In addition to setting the speed, the vertical force test stand also offers the option of switching between automatic and manual mode.

Force range: 500 N / 50 kg / 110 lb
Distance display resolution: 0.02 mm
Resolution: 1 mm/min
Tensile and compression testing
Travel: 270 mm / 10.6"
220V AC ONLY

Universal Testing Machine PCE-MOV 60

£ 1,767.00

Price excl. VAT &. delivery

This compact Universal Testing Machine is ideal for precise applications in the laboratory and in materials testing. With a maximum temperature of 1000°C / 1832°F and a continuous working temperature of up to 900°C / 1652°C, the Universal Testing Machine is ideal for sintering processes, annealing tests or material analyses.

For temperatures up to 1000°C / 1832°F
Heating chamber made of polycrystalline alumina ceramic
PID control with ±1°C / 1.8°F accuracy
Programmable with up to 30 heating sections
Chamber size: 100 x 100 x 100 mm / 3.9 x 3.9 x 3.9 in

PCE-VTS 50-PFG 500-KIT incl. Force Test Stand and Force Gauge

£ 1,813.00

Price excl. VAT &. delivery

The force gauge incl. test stand is a handy, digital measuring device for measuring tensile and compressive forces. The force gauge offers a sampling rate of 500 Hz and various measurement options such as real-time measurement (RT), maximum value measurement (PEAK), configurable average value acquisition (Average) and automatic measurement storage of up to 100 measurements. This kit contains a vertical materials test stand which is a motorized test station with a force range of up to 500 N.

Measuring range: 0 … 500 N
Resolution: 0.1 N
Accuracy: ± 0.3% of the measuring range
Memory for 100 measurements
USB interface
Graphic displayMotorised Force Test Stand PCE-VTS 50
Force range: 500 N / 50 kg / 110 lb
Distance display resolution: 0.02 mm
Resolution: 1 mm/min
Tensile and compression testing
Travel: 270 mm / 10.6"
220V AC ONLY

Universal Testing Machine PCE-MTS500

£ 1,937.00

Price excl. VAT &. delivery

Our universal testing machine PCE-MTS500 can be coupled and operated in a wide variety of versions with our force gauges, the PCE series. The universal testing machine lets you carry out almost all of your compression and tensile force applications with repeatability. The use of the universal testing machine offers the operator the most precise equality of test bench and sample.

Measuring range: max. 5000 N / 500 kg
Feed speed: 30 mm/min … 230 mm/min
All PCE devices adaptable
Robust steel design
** N.B. The mounting plate ADP-UNI accessory must be ordered for internal load cell force gauges ***

More Information

on Universal Testing Machines

Materials used in manufacturing and production are not necessarily solid, unchangeable substances. Universal Testing Machine Under stresses and strains involving pressure, compression, tension, bending and twisting, materials reveal characteristics related to strength and deformation. Depending on the type of material (e.g., metal, rubber, plastic, alloy) and level of stress or strain, the degree of material deformation will vary greatly.

A universal testing machine is a pivotal technology regularly used in the materials testing world to carry out controlled, static tests to determine material characteristics. A universal testing machine extends the opportunities for materials testing, as most machines feature motors capable of exerting enough power to test materials to their limits under extreme conditions. To ensure accurate, reliable test results, the platform dimensions and shape of a universal testing machine will differ according to the kind of test (e.g., bending, compression, etc.) to be performed. The size and anticipated strength of the material to be tested also will affect the design of the universal testing machine. Therefore, universal testing machines can come in tabletop or floor models to accommodate different test and material requirements.

In addition, an electronic universal testing machine will have built-in programming, features and functionality that allow the user to control certain test conditions and adjust key parameters like the test speed and cycle time.
