Ultrasonic Tester / Ultrasonic Testing


Order no.: PCE-TG 75
Ultrasonic Thickness Tester PCE-TG 75
The ultrasonic thickness tester can measure material thicknesses up to 225 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.00 ... 225.0 mm  / 0.04 ... 8.85"
- Resolution: 0.01 mm at ≤99.99 mm
                       0.1 mm at ≥100.0 mm
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 500 measured values
- Calibration reference on housing
£ 351.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-ULM 10
Ultrasonic Level Indicator PCE-ULM 10
The ultrasonic level indicator is the ideal measuring device to determine the fill level of a silo. Thanks to the 4 … 20-mA output signal, the ultrasonic level indicator can also be connected to the operational process control.

- Measuring range: 0 ... 10 m / 0 ... 32.8 ft
- Accuracy: 0.5%
- Resolution: 0.001 m
- With display for setting and reading
- Stable M60 connection thread
£ 441.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 75-ICA
Ultrasonic Thickness Tester PCE-TG 75-ICA incl. ISO Calibration Certificate ISO Calibration
The ultrasonic thickness tester can measure material thicknesses up to 225 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.00 ... 225.0 mm  / 0.04 ... 8.85"
- Resolution: 0.01 mm at ≤99.99 mm
                       0.1 mm at ≥100.0 mm
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 500 measured values
- Calibration reference on housing
- incl. ISO Calibration Certificate
£ 459.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-ULM-10-N24S
Ultrasonic Level Indicator PCE-ULM-10-N24S
The ultrasonic level indicator is the ideal measuring device to determine the filling level of a silo. Thanks to the 4 ... 20 mA output signal, the ultrasonic level indicator can also be connected to the operational process control.

- Measuring range: 0 ... 10 m / 0 ... 32.8 ft
- Accuracy: 0.5%
- Resolution: 0.001 m
- With display for setting and reading
- Stable M60 connection thread
- incl. external digital display PCE-N24S:
- Voltage supply: selectable
- Input signal: selectable
- Display: 4 digits, red
- Digit height: 20 mm / 0.78"
£ 467.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 150
Ultrasonic Thickness Tester PCE-TG 150
The ultrasonic thickness tester can measure material thicknesses up to 300 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.00 ... 300.0 mm  / 0.04 ... 11.81"
- Resolution: 0.01 mm at ≤99.99 mm
                       0.1 mm at ≥100.0 mm
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 1500 measured values
- Calibration reference on housing
£ 467.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 150-ICA
Ultrasonic Thickness Tester PCE-TG 150-ICA incl. ISO Calibration Certificate ISO Calibration
The ultrasonic thickness tester can measure material thicknesses up to 300 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.00 ... 300.0 mm  / 0.04 ... 11.81"
- Resolution: 0.01 mm at ≤99.99 mm
                       0.1 mm at ≥100.0 mm
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 1500 measured values
- Calibration reference on housing
- incl. ISO Calibration Certificate
£ 467.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 150 F2.5
Ultrasonic Thickness Tester PCE-TG 150 F2.5
The ultrasonic thickness tester can measure material thicknesses up to 300 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.20 ... 300.0 mm  / 0.04 ... 11.81"
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 1500 measured values
- Calibration reference on housing
- Probe temperature range: -10 ... 60 °C / 14 ... 140 °F
£ 530.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 150 F2.5-ICA
Ultrasonic Thickness Tester PCE-TG 150 F2.5-ICA incl. ISO Calibration Certificat ISO Calibration
The ultrasonic thickness tester can measure material thicknesses up to 300 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.20 ... 300.0 mm  / 0.04 ... 11.81"
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 1500 measured values
- Calibration reference on housing
- Probe temperature range: -10 ... 60 °C / 14 ... 140 °F
- incl. ISO Calibration Certificate
£ 530.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-UFM 10
Ultrasonic Flow Tester PCE-UFM 10
With our ultrasonic flow tester, you have the capability to measure flow rates from ±0.1 m/s to ±5 m/s. The ultrasonic flow tester is suitable for small pipes with a diameter of DN10 / 3/8" and various pipe materials such as steel, copper, aluminum, and plastics.

- Measurement Range: 0.1 ... 5 m/s
- Resolution: 0.001 m/s
- Accuracy: 2%
- Pipe Size: DN10 / 3/8"
- Display Type: OLED
- Analog Output: 4 ... 20mA
£ 823.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-UFM 15
Ultrasonic Flow Tester PCE-UFM 15
With our ultrasonic flow tester, you have the capability to measure flow rates from ±0.1 m/s to ±5 m/s. The ultrasonic flow tester is suitable for small pipes with a diameter of DN15 / 1/2" and various pipe materials such as steel, copper, aluminum, and plastics.

- Measurement Range: 0.1 ... 5 m/s
- Resolution: 0.001 m/s
- Accuracy: 2%
- Pipe Size: DN15 / 1/2"
- Display Type: OLED
- Analog Output: 4 ... 20mA
£ 823.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-UFM 20
Ultrasonic Flow Tester PCE-UFM 20
With our ultrasonic flow tester, you have the capability to measure flow rates from ±0.1 m/s to ±5 m/s. The ultrasonic flow tester is suitable for small pipes with a diameter of DN20 / 3/4" and various pipe materials such as steel, copper, aluminum, and plastics.

- Measurement Range: 0.1 ... 5 m/s
- Resolution: 0.001 m/s
- Accuracy: 2%
- Pipe Size: DN20 / 3/4"
- Display Type: OLED
- Analog Output: 4 ... 20mA
£ 823.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-UFM 25
Ultrasonic Flow Tester PCE-UFM 25
With our ultrasonic flow tester, you have the capability to measure flow rates from ±0.1 m/s to ±5 m/s. The ultrasonic flow tester is suitable for small pipes with a diameter of DN25 / 1" and various pipe materials such as steel, copper, aluminum, and plastics.

- Measurement Range: 0.1 ... 5 m/s
- Resolution: 0.001 m/s
- Accuracy: 2%
- Pipe Size: DN25 / 1"
- Display Type: OLED
- Analog Output: 4 ... 20mA
£ 823.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-UFM 4
Ultrasonic Flow Tester PCE-UFM 4
With our ultrasonic flow tester, you have the capability to measure flow rates from ±0.1 m/s to ±5 m/s. The ultrasonic flow tester is suitable for small pipes with a diameter of DN4 / 1/8" and various pipe materials such as steel, copper, aluminum, and plastics.

- Measurement Range: 0.1 ... 5 m/s
- Resolution: 0.001 m/s
- Accuracy: 2%
- Pipe Size: DN4 / 1/8"
- Display Type: OLED
- Analog Output: 4 ... 20mA
£ 823.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-UFM 8
Ultrasonic Flow Tester PCE-UFM 8
With our ultrasonic flow tester, you have the capability to measure flow rates from ±0.1 m/s to ±5 m/s. The ultrasonic flow tester is suitable for small pipes with a diameter of DN8 / 1/4" and various pipe materials such as steel, copper, aluminum, and plastics.

- Measurement Range: 0.1 ... 5 m/s
- Resolution: 0.001 m/s
- Accuracy: 2%
- Pipe Size: DN8 / 1/4"
- Display Type: OLED
- Analog Output: 4 ... 20mA
£ 823.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 150 HT
Ultrasonic Thickness Tester PCE-TG 150 HT
The ultrasonic thickness tester can measure material thicknesses up to 300 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.20 ... 300.0 mm  / 0.04 ... 11.81"
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 1500 measured values
- Calibration reference on housing
- High temperature probe: -10 ... 350 °C / 14 ...  662 °F
£ 845.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TG 150 HT-ICA
Ultrasonic Thickness Tester PCE-TG 150 HT-ICA incl. ISO Calibration Certificate ISO Calibration
The ultrasonic thickness tester can measure material thicknesses up to 300 mm. So that the material thickness of a wide variety of homogeneous materials can be measured, it is possible to store the corresponding sound velocity in the ultrasonic thickness tester.

- Measuring range: 1.20 ... 300.0 mm  / 0.04 ... 11.81"
- Accuracy: ±0.5% of measured value + 0.05 mm
- Memory capacity: 1500 measured values
- Calibration reference on housing
- High temperature probe: -10 ... 350 °C / 14 ...  662 °F
- incl. ISO Calibration Certificate
£ 845.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TDS 100H
Ultrasonic Flow Tester PCE-TDS 100H

PCE-TDS 100H is a portable handheld clamp-on ultrasonic flow tester or meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 57 … 720 mm / approx. 2 ... 28 in.  Software sold separately - see accessories for details.



- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 50 … 700, 57 … 720 mm (approx. 2 … 28")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, Z
- Incl. sensors TDS-M1

£ 1,241.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TDS 100HS
Ultrasonic Flow Tester PCE-TDS 100HS

PCE-TDS 100HS is a portable handheld clamp-on ultrasonic flow tester or meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 20 … 108 mm / approx. 3/4 ... 4in. Software sold separately - see accessories for details.


- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 15 … 100, 20 … 108 mm (approx. 3/4 … 4")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, (N,W)
- Incl. sensors TDS-S1

£ 1,241.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-TDS 75
Ultrasonic Flow Tester PCE-TDS 75
The ultrasonic flow tester is a fixed installation meter. The flow rate of liquids in pipes can be determined with this ultrasonic flow tester. The sensors from the ultrasonic flow tester can be mounted directly on the pipes to be measured without having to cut them open. The flow velocity is calculated using the transit-time principle which requires the solid impurities be less than 5% for accuracy.

- Measuring range: ± 0.03 ... ± 5 m / s
- Measuring accuracy: ± 1% of the measured value
- Pipe diameter: 25 ... 1200 mm (1 ... 48 in)
- Interface: RS232 & RS485
- Relay output
£ 1,254.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer
Order no.: PCE-LDC 8
Ultrasonic Leak Detector PCE-LDC 8
The Ultrasonic Leak Detector is used to locate leaks on compressed air lines. Furthermore, the Ultrasonic Leak Detector can also be used on coolant lines or gas lines for leak detection.

- Measuring principle: ultrasound
- Measuring principle: air, coolant, non-explosive gases
- Working frequency of 40 kHz
- up to 6 h battery operation
- Leak detection via headphones and LCD display
- Localize leaks up to 18m, 59 ft.
£ 1,446.00

Price excl. VAT &. delivery
2 year Warranty

Test Instruments manufacturer

Choosing the Right Ultrasonic Test Equipment for Your Application

A portable ultrasonic tester or ultrasonic gauge is an incredibly versatile measuring device Ultrasonic Tester / Ultrasonic Testingthat comes in handy in myriad applications, especially when detecting leaks or measuring the effects of corrosion on tanks, pipes and structures with limited one-sided access. In addition, an ultrasonic thickness gauge can be used to determine the thickness of coated or painted metals without the need for stripping.

Another kind of ultrasonic testing device is an ultrasonic contact impedance (UCI) durometer or hardness tester. A UCI hardness tester is a portable electronic device that uses the UCI method of hardness testing standardized by ASTM A 1038 and DIN 50159. A UCI hardness tester makes and then measures a diamond indent in the surface of material to determine the material hardness.
