PCE Instruments

Ultrasonic Flow Meter

Order no.: PCE-TDS 100H

PCE-TDS 100H is a portable handheld clamp-on ultrasonic flow meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 57 … 720 mm / approx. 2 ... 28 in.  Software sold separately - see accessories for details.



- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 50 … 700, 57 … 720 mm (approx. 2 … 28")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, Z
- Incl. sensors TDS-M1
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100HS

PCE-TDS 100HS is a portable handheld clamp-on ultrasonic flow meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 20 … 108 mm / approx. 3/4 in ... 4in. Software sold separately - see accessories for details.


- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 15 … 100, 20 … 108 mm (approx. 3/4 … 4")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, (N,W)
- Incl. sensors TDS-S1
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100HSH

PCE-TDS 100HSH is a portable handheld clamp-on ultrasonic flow meter used for non-invasive, unobstructed and highly accurate measurements of the flow velocity of liquids in metal, plastic and rubber pipes and tubes with a diameter of 20 … 108 mm / approx. 3/4 in ... 4in. Software sold separately - see accessories for details.


- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 15 … 700, 20 … 720 mm (approx. 3/4 … 28")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, (N,W)
- Incl. sensors TDS-M1 and TDS-S1
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100H-TG50
The ultrasonic flow meter can be used to measure on metallic pipes, plastic pipes or rubber pipes. This set consists of an ultrasonic flow meter and an ultrasonic material thickness meter for metals, glass and homogeneous plastics.

Ultrasonic flow meter
- Measuring range: -32 ... +32 m/s
- Resolution: 0.0001 m/s
- Pipe size: DN 50 … 700, 57 … 720 mm
- Incl. sensors TDS-M1
- Incl. ISO calibration certificate
Ultrasonic material thickness meter
- Measuring range: 1.2 ... 200.00 mm (steel)
- Accuracy: ±0.5 % ±0.1
- Resolution: 0.1 mm
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100HS-TG50
This set consists of an ultrasonic flow meter and an ultrasonic material thickness meter for metals, glass and homogeneous plastics. The ultrasonic flow meter can be used to measure on metallic pipes, plastic pipes or rubber pipes.

Ultrasonic flow meter
- Measuring range: -32 ... +32 m/s
- Resolution: 0.0001 m/s
- Pipe size: DN 15 … 100, 20 … 108 mm
- Incl. sensors TDS-S1
- Incl. ISO calibration certificate
Ultrasonic thickness meter
- Measuring range: 1.2 ... 200.00 mm (steel)
- Accuracy: ±0.5 % ±0.1
- Resolution: 0.1 mm
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100H+

The ultrasonic flow meter is required as part of a control measurement or to quickly determine the flow in a pipeline and is therefore a portable / easy-to-install measuring system. The ultrasonic flow meter works according to the transit time difference method. The measuring principle of the ultrasonic flow meter is quite simple.



- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 50 … 700, 57 … 720 mm (approx. 2 … 28")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, Z
- Incl. sensors TDS-M1
- Incl. evaluation software
- Incl. temperature datalogger
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100HSH-TG50
The measuring principle of the two devices is quite simple. The ultrasonic flow meter can be used for measuring on metallic pipes, plastic pipes or rubber pipes, while the ultrasonic material thickness meter can be used for metals, glass and homogeneous plastics.

Ultrasonic flow meter
- Measuring range: -32 ... +32 m/s
- Resolution: 0.0001 m/s
- Flow sensors for 20 ... 108 mm (approx. 3/4 … 4") pipe diameter
- Flow sensors for 50 ... 700 mm (approx. 2 … 28") pipe diameter
- Incl. ISO calibration certificates
Ultrasonic thickness meter
- Measuring range: 1.2 ... 200.00 mm (steel)
- Accuracy: ±0.5 % ±0.1
- Resolution: 0.1 mm
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100HS+

The ultrasonic flow meter is required as part of a control measurement or to quickly determine the flow in a pipeline and is therefore a portable / easy-to-install measuring system. The ultrasonic flow meter works according to the transit time difference method. The measuring principle of the ultrasonic flow meter is quite simple.



- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 15 … 100, 20 … 108 mm (approx. 3/4 ... 4")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, (N,W)
- Incl. sensors TDS-S1
- Incl. evaluation software
- Incl. 2-channel temperature datalogger
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TDS 100HSH+

The ultrasonic flow meter is required as part of a control measurement or to quickly determine the flow in a pipeline and is therefore a portable / easy-to-install measuring system. The ultrasonic flow meter works according to the transit time difference method. The measuring principle of the ultrasonic flow meter is quite simple.



- Measuring range: -32 ... 32 m/s, -105 ... 105 ft/s
- Resolution: 0.0001 m/s, 0.00033 ft/s
- Pipe size: DN 15 … 100, 20 … 108 mm (approx. 3/4 ... 4")
- Pipe size: DN 50 … 700, 57 … 720 mm (approx. 2 … 28")
- Sensor temperature range: 0 ... 160°C / 32 ... 320°F
- Sensor installation: V, (N,W)
- Incl. sensors TDS-M1, TDS-S1
- Incl. evaluation software
- Incl. 2-channel temperature datalogger
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
