PCE Instruments

Tachometer

Order no.: PCE-T 260
The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope function, the tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 50
The revolver PCE-DT 50 in the form of a pistol is ideal for quick control of speeds. This PCE-DT 50 tachometer measures the rotational speed of moving objects, such as shafts, drives, pinions etc., without contact.

- Measuring range: 2.5 ... 99,999 rpm (RPM)
- Measurement accuracy: ± 0.02% + 1 digit
- Resolution: 2.5 ... 999 rpm: 0.1 rpm
- MIN / MAX / AVG mode
- Data hold function
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-N15O
The Industrial Tachometer Display is a simple gauge to display pulses from speed sensors. This industrial tachometer display is able to display the pulses per revolution.

- Display range: 0 ... 9999
- Input range: 0.1 Hz ... 1 kHz
- Display range revolutions: 6 ... 60000 RPM
- 4-digit LED display
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 66

PCE-DT 66 is a portable, digital, handheld tachometer, or rotation meter, that can take measurements of rotational speed. This handheld tachometer features mechanical attachments and is ideal for measuring rotational speeds of machines, motors, conveyor belts and other moving parts.


- For taking measurements in contact with moving parts
- Measuring range: 50 ... 19999 RPM
- Accuracy: ± 0.03% / ± 2 digits



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 65

PCE-DT 65 is a digital tachometer, or rotation meter, that can take both contact and non-contact measurements of rotation speed and linear speed. This handheld tachometer features an integrated laser and includes a mechanical attachment with contact probes, making it the ideal measuring instrument for machines, motors, conveyor belts and other moving parts.


- Speed (rpm)
- Surface speed (m / min)
- Number of revolutions (counter)
- Frequency (Hz)
- Length measurement (m, In, FT, Yd)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-N16O
The Industrial Tachometer Display is an adjustable gauge to visualize pulses from speed sensors. This industrial tachometer display is able to display the pulses per revolution.

- Display range: 0 ... 999999
- Input range: 0.1 Hz ... 1 kHz
- Display range revolutions 6 ... 60000 RPM
- 6-digit LED display
- Display of the pulses per revolution
- Adjustable divider via buttons
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T237

The tachometer can be used contactless or with mechanical contact. The PCE-T237 digital tachometer is particularly suitable for recording rotational speeds and speeds on rotating machines and systems (on conveyor belts, motors, belt drives, etc.).


- Contact measurement of rpm via cone adapter
- Contact measurement of m / min via surface wheel
- Robust ABS plastic housing
- Meter count: 0.1 ... 199,999 m



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 66-ICA

PCE-DT 66 is a portable, digital, handheld tachometer, or rotation meter, that can take measurements of rotational speed. This handheld tachometer features mechanical attachments and is ideal for measuring rotational speeds of machines, motors, conveyor belts and other moving parts.


- For taking measurements in contact with moving parts
- Measuring range: 50 ... 19999 RPM
- Accuracy: ± 0.03% / ± 2 digits
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T 238
The tachometer PCE-T 238 is a battery-powered hand-held device that allows mobile use. The handheld tachometer can perform a contact measurement as well as a non-contact measurement. It is also possible to perform a measurement of the surface velocity. The handheld tachometer allows a measurement of up to 99,999 revolutions per minute. This measuring range is possible with contactless measurements with the optical tachometer.

- Continuous data output
- Contactless measurement range: 5 ... 99,999 RPM
- Contact measurement range: 0.5 ... 19,999 RPM
- Surface measurement range: 0.05 ... 1,999.9 m/min
- Measuring distance without contact: 5 ... 150 cm / 1.9" ... 4.9 ft
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DT 65-ICA

PCE-DT 65 is a digital tachometer, or rotation meter, that can take both contact and non-contact measurements of rotation speed and linear speed. This handheld tachometer features an integrated laser and includes a mechanical attachment with contact probes, making it the ideal measuring instrument for machines, motors, conveyor belts and other moving parts.


- Speed (rpm)
- Surface speed (m / min)
- Number of revolutions (counter)
- Frequency (Hz)
- Length measurement (m, In, FT, Yd)
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T237-ICA

The tachometer can be used contactless or with mechanical contact. The PCE-T237 digital tachometer is particularly suitable for recording rotational speeds and speeds on rotating machines and systems (on conveyor belts, motors, belt drives, etc.).


- Contact measurement of rpm via cone adapter
- Contact measurement of m / min via surface wheel
- Robust ABS plastic housing
- Meter count: 0.1 ... 199,999 m
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-OM 15

PCE-OM 15 is a handheld strobe tachometer with trigger functionality. This easy-to-use portable digital stroboscope gun features high / low range selection and push-button rate control to scale the flash rate slower (x½) and faster (x2). In addition, two knobs allow coarse and fine adjustment of the flash rate.


- Measuring range: 50 ... 30000 rpm
- Bright 6500K xenon light bulb
- 10 mm / 0.4 5-digit LCD

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T 238-ICA
The tachometer PCE-T 238 is a battery-powered hand-held device that allows mobile use. The handheld tachometer can perform a contact measurement as well as a non-contact measurement. It is also possible to perform a measurement of the surface velocity. The handheld tachometer allows a measurement of up to 99,999 revolutions per minute. This measuring range is possible with contactless measurements with the optical tachometer.

- Continuous data output
- Contactless measurement range: 5 ... 99,999 RPM
- Contact measurement range: 0.5 ... 19,999 RPM
- Surface measurement range: 0.05 ... 1,999.9 m/min
- Measuring distance without contact: 5 ... 150 cm / 1.9" ... 4.9 ft
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DSX 20
The tachometer PCE-DSX 20 is mostly used for speed or vibration measurement or for motion observations. This tachometer has a small design and has a low weight. Thus, the tachometer can be conveniently used even in measurements in hard to reach places.

Function
- Speed: 50 ... 35000 RPM / FPM
- Flash frequency
- phase shift
- Lamp type: Xenon flash
- Flash response time: 10 ... 30 μs
- With trigger input
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-OM 15-ICA

PCE-OM 15-ICA is a strobe tachometer with trigger functionality. This easy-to-use portable digital stroboscope gun features high / low range selection and push-button rate control to scale the flash rate slower (x½) and faster (x2). In addition, two knobs allow coarse and fine adjustment of the flash rate.


- Measuring range: 50 ... 30000 rpm
- Bright 6500K xenon light bulb
- 10 mm / 0.4 in 5-digit LCD
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DSX 20-ICA
The tachometer PCE-DSX 20-ICA is mostly used for speed or vibration measurement or for motion observations. This tachometer has a small design and has a low weight. Thus, the tachometer can be conveniently used even in measurements in hard to reach places.

Function
- Speed: 50 ... 35000 RPM / FPM
- Flash frequency
- phase shift
- Lamp type: Xenon flash
- Flash response time: 10 ... 30 μs
- With trigger input
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T 260-ICA
The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope function, the tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared
- LED Flash frequency: 100 ... 99990 FPM
- Temperature measurement: Type K, PT 1000
- Infrared
- Incl. ISO calibration certificate (only for the tachometer function)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-LES 100

The PCE-LES 100 Tachometer combines LED technology with compact and accurate electronics, which controls the sequence and timing of flash over the entire measuring range. Thanks to LED technology, the Tachometer does not need periodic changing of bulbs. The tachometer is sent to you calibrated (by the manufacturer PCE Instruments).


- Range: 60 ... 99,990 r.p.m / 1 ... 1,666 Hz
- 2 bright LEDs (1400 lux @ 50 cm)
- Display: 5 digits LCD
- Impulses/Flash: Possibility of duplication and division/fine tuning
- Offset: Yes, 360º

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-LES 100-ICA

The PCE-LES 100-ICA tachometer combines LED technology with compact and accurate electronics, which controls the sequence and timing of flash over the entire measuring range. Thanks to LED technology, the tachometer does not need periodic changing of bulbs. The tachometer is sent to you calibrated (by the manufacturer PCE Instruments).


- Range: 60 ... 99,990 r.p.m / 1 ... 1,666 Hz
- 2 bright LEDs (1400 lux @ 50 cm)
- Display: 5 digits LCD
- Impulses/Flash: Possibility of duplication and division/fine tuning
- Offset: Yes, 360º

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VT 204

PCE-VT 204 is a multifunction handheld tachometer with the ability to accurately measure both rotation and vibration. An ideal tool for the testing and inspection of machine parts and components such as motors, transmissions, gears, gear boxes and wheels, this multi-purpose device measures revolutions per minute (RPMs) as well as three-axis vibration, i.e., speed or velocity, displacement and acceleration.


- Vibration measurement: velocity or speed, acceleration and displacement
- RPM measurement: contact / mechanical and noncontact / optical
- Internal memory for up to 1000 readings
- Min / max and data hold functions
- RS-232 port



Manufacturer: PCE Instruments
Test Instruments manufacturer
