Surface Testing

Order no.: PCE-CT 65

PCE-CT 65 is a surface testing - coating thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range: 0 ... 1350 µm / 0 ... 53.1 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 65-ICA

PCE-CT 65 is a surface testing - coating thickness gauge that uses magnetic induction (ferrous) or eddy current (non-ferrous) to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum. This surface testing - thickness gauge is ideal for painted and powder-coated surface testing, automotive paint inspection, coated material testing, and manufacturing quality control applications.


- Measuring range of 0 ... 1350 µm / 0 ... 53 mils
- Accuracy of ±2.5 % ±2 µm for 0 ... 1000 µm / ±3.5 % for 1000 µm ... 1350 µm / ±2 % ±0.08 mils for 0 ... 39.3 mils / ±3.5 % for 39.3 mils ... 53.1 mils
- Saves up to 1500 measurements to memory
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 100

PCE-CT 100 is a surface-testing coating thickness measuring instrument used to quickly and easily determine coating thicknesses on ferrous (Fe) and non-ferrous (nFe) metals. This compact handheld coating thickness gauge uses magnetic induction (ISO 2178) and eddy current (ISO 2360) coating thickness measurement methods to take non-destructive measurements of coating and dry film thickness (DFT) on metal substrates such as steel and aluminum.


- Measuring range: Depends on choice of sensor probe - sold separately
- Resolution: 0.1 or < 0.2% of measured value
- Saves up to 100,000 measurements to memory
- Interfaces: USB 2.0, Bluetooth 4.0
- Displays measuring units in μm, mm or mils
- Includes factory calibration certificate according to ISO 9001

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000H

PCE-CT 5000H is a surface-testing coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The coating thickness gauge automatically detects the type of metal to be measured.


- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 5000H-ICA

PCE-CT 5000H is a surface testing - coating thickness measuring instrument used for the rapid determination of coating thicknesses on ferrous (Type F) and non-ferrous (Type N) metals. The coating thickness gauge automatically detects the type of metal to be measured.


- Type F measuring range: 0 ... 5000 µm / 0 ... 5 mm / 0 ... 196 mils
- Type N measuring range: 0 ... 3000 µm / 0 ... 3 mm / 0 ... 118 mils
- Displays measuring units in μm, mm or mils
- Saves up to 2000 measurements to internal memory
- Practical V-groove on the measuring head
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 27FN

PCE-CT 27FN is a Surface Testing - Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.


- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ±(2 % + 2 µm) / ±(2 % + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 27FN-ICA

PCE-CT 27FN is a Surface Testing - Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on metal substrates such as steel and aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.


- Measuring range of 0 ... 1250 µm / 0 ... 50 mils
- Accuracy of ±(2 % + 2 µm) / ±(2 % + 0.1 mils)
- Features a resolution of 0.1 µ / 0.1 mils
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 50

PCE-CT 50 is a Surface Testing - Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on only non-ferrous metal substrates such as aluminum, copper,  brass, zinc, stainless steel and anodized aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.


- Measuring range of 5000 microns (µm) / 200 mil
- Accuracy of ±(1 µm / 0.04 mils +2 %) of 0 µm ... 999 µm / 40 mils ±3.5 % of
  1001 µm ... 5000 µm / 40 mils ... 200 mils
- Resolution of 0.1 µm / 0.01 mil / 0.01 mm



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 50-ICA

PCE-CT 50 is a Surface Testing - Coating Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on only non-ferrous metal substrates such as aluminum, copper,  brass, zinc, stainless steel and anodized aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications.


- Measuring range of 5000 microns (µm) / 200 mil
- Accuracy of ±(1 µm / 0.04 mils +2 %) of 0 µm ... 999 µm / 40 mils ±3.5 % of
  1001 µm ... 5000 µm / 40 mils ... 200 mils
- Resolution of 0.1 µm / 0.01 mil / 0.01 mm
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 25

The PCE-CT 25 Surface Tester- Coating Thickness Gauge is used for quickly detecting the thickness of metals, such as steel and iron (F) as well as non-ferrous metals (N) in the automotive sector. The PCE-CT 25 Surface Tester - Coating Thickness Gauge is used to detect damages in cars (the coating thickness of paint can say if the car has suffered any damage) to establish if the car has been in an accident and the resulting value of the car in the used car market.


- Measurement range: 0 µm ... 1000 µm / 40 mils
- Resolution: 0.1 mils / 1 µm
- Display: 3 1/2 digit LCD display
- Operating conditions: 0 ... 50°C / 32 ... 122°F



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-779N

The PCE-779N measures temperatures quickly and without contact. The PCE-779N can be used for almost all surfaces. The emissivity of the Temperature Meter is adjustable over the range of 0.1 ... 1.0. The Temperature Meter has various measurement functions such as max, min and average measurement. Each temperature meter comes manufacturer calibrated and can be certified according to the ISO standards as an option. In general our laboratory adjusts the temperature meter to two (linear) temperature points.


- OLED-Display
- Measuring range: -60 ... 760°C / -76 ... 1400°F
- Additional thermocouple measurement -64 ... 1400°C / -83.2 ... 2552°F
- Dual Laser
- Resolution: 0.1°C / 0.18°F at -83.2 ... 999.9°C (-117.8 ... 1831.8°F), otherwise 1°C / 1.8°F



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-T390

The PCE-T390 temperature meter is a digital device with four input channels for type K and type J temperature sensors and two input channels for PT100 temperature sensors. The PCE-T390 temperature meter has a SD card slot (from 1 ... 16 GB) for storing the measured data. The data is stored in xls format on the SD card of the temperature meter so that no additional software is needed for further analysis.


- 4 input channels for type-K, J temperature sensors
- 2 input channels for Pt100 temperature sensors
2 x type-K TF-500 temperature sensors are included in the package
- SD card memory (1 ... 16 GB)



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CRC 10

The Surface Tester PCE-CRC 10 is designed to determine the quality of the adhesion of coatings. The Surface Tester is suitable for thin, thick or tough coatings on all surfaces. Since the adherence of paintings and other coatings is a crucial product and quality characteristic for their protective effect, surface testers are used in a wide range of industries.


- Evaluation of adhesion
- For thin, thick or tough coatings
- Large, non-slip grip
- Various blades selectable



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200

PCE-VE 200 is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.


- 4.5 mm / 0.18" diameter, semi-rigid
- 1 m / 3.28' cable length
- 180° image rotation



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200-KIT2

PCE-VE 200 is a surface testing - automotive tester / borescope or inspection camera, for nondestructive evaluation (NDE) and machine diagnostics. The PCE-VE 200 borescope provides excellent image quality at an affordable price. An ideal camera tool for diagnosing hard-to-reach places, the scope can be rotated 180 ° and offers 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.


Surface Testing - Automotive Tester / Borescope
- 3.5 in LCD display
- 3.28 ft cable length
- 0.18 in camera cable diameter
- 1/8 in camera head / CMOS chip image sensor
- 640 x 480 pixels AVI video resolution
- Micro SD card memory
- Micro USB 2.0 and TV outputs

Clamp Meter
This Clamp Meter has been developed to determine indirectly, the the AC/DC currents with high accuracy. A non-contact clamp meter and a torch to illuminate the area being measured, have been integrated into this device. The small size of this  Clamp Meter, makes it possible to use in small spaces with limited access.

- 4 digit LCD display with backlighting
- save function
- DCA zero rest function
- current tester, non-contact
- integrated light to illuminate measured area
- automatic range selection
- automatic disconnect
- clamp diameter: 18 mm



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 300-H

The Surface Testing - Automotive Tester / Borescope PCE-VE 300-H is the optimum for experts and development engineers. Choose between many different cables for the borescope. This borescope not only gives you an optical insight into the inner workings of machines and systems without first disassembling them, it also allows images and video sequences of the components to be inspected to be stored directly in the device. The optimal tool for inspection of industrial machinery and equipment.


- Various borescope cables selectable
- Interfaces: mini-USB 1.1 and AV out
- Memory: 8 GB SD memory card (incl.)

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 60Plus

PCE-GM 60Plus is a portable handheld 60-degree reflective surface-testing gloss meter or gloss tester used to measure the gloss units (GU) on a material's surface. This rechargeable gloss meter uses reflected light for gloss measurement per ISO 2813, GB/T 9754, ASTM D523 and ASTM D2457 standards.


- Measuring geometry: 60° degree angle
- Measuring range: 0 ... 200 GU
- 3.5" TFT touchscreen display
- Measuring accuracy ±1.5 GU
- Light source: D65
- Wave length: 400-700 nm




Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-HT-225A

PCE-HT-225A is a heavy-duty concrete hardness tester or concrete test hammer, also called a concrete rebound hammer or Swiss hammer, used to measure surface hardness and material compression strength. Suitable for use with concrete, rock and building materials, this rugged, manufacturer-calibrated rebound hammer is both easy to use and built to last.


- Test range: 10 ... 60 MPa or 100 ... 600 kg/cm² or 1450 ... 8702 psi
- Impact energy: 2.207 J or N-m / 0.225 kgf.m / 1.6278 ft-lb
- Impact stroke: 75 ± 0.3 mm / 2.95 ± 0.012 in
- Radius of spherical tip: 25 ± 1 mm / 0.99 ± 0.04 in
- kg/cm², psi, and MPa conversion tables
- Optional test anvil to verify accuracy listed under accessories

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-IR10

The PCE-IR10 temperature meter is made up of a small sensor head and a separate electrical component. The temperature meter sensor is so small that it can fit in almost any space. part from this, the device offers similar specifications as other devices. Each temperature meter comes manufacturer calibrated and can be certified according to the ISO standards as an option. In general our laboratory adjusts the temperature meter to two temperature points.


- Temperature range: -40 ... 600°C / -40 ... 1112°F
- Accuracy: ± 1% or ± 1°C / 1.8°F
- Optical resolution: 15:1
- Storage conditions: -40 ... 85°C / -40 ... 185°F
- Spectral range: 8.0 ... 14 µm
- Emissivity: 0.100 - 1.000 adjustable in digital mode, by units of 0.001
- Outputs: analogue, USB, RS-232, RS-485, relay



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 200-S

PCE-VE 200-S is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.


- 3.7 mm / 0.14" diameter
- 1 m / 3.28' cable length
- 180° image rotation


Manufacturer: PCE Instruments
Test Instruments manufacturer
