PCE Instruments

Stroboscope / Stroboscope Light

Order no.: PCE-T 260
The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope function, the tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared
Manufacturer: PCE Instruments
£ 303.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 260-ICA
The combination PCE-T 260 is a measuring instrument for use in maintenance, and production. In addition to the stroboscope light function, the tachometer-stroboscope also has the option of removing the rotational contacts and measuring temperatures.

- Optical tachometer
- Measuring range: 5 ... 99999 rpm
- Contact tachometer
- Stroboscope LED
- Temperature measurement: Type K, PT 1000, Infrared
- LED Flash frequency: 100 ... 99990 FPM
- Temperature measurement: Type K, PT 1000
- Infrared
- Incl. ISO calibration certificate (only for the tachometer function)
Manufacturer: PCE Instruments
£ 420.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-LES 100

The PCE-LES 100 Stroboscope light combines LED technology with compact and accurate electronics, which controls the sequence and timing of flash over the entire measuring range. Thanks to LED technology, the stroboscope light does not need periodic changing of bulbs. The stroboscope light is sent to you calibrated (by the manufacturer PCE Instruments).


- Range: 60 ... 99,990 r.p.m / 1 ... 1,666 Hz
- 2 bright LEDs (1400 lux @ 50 cm)
- Display: 5 digits LCD
- Impulses/Flash: Possibility of duplication and division/fine tuning
- Offset: Yes, 360º

Manufacturer: PCE Instruments
£ 418.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 240
The stroboscope light has a contact speed measurement. The measuring range of the contact speed measurement with the stroboscope light is 0.5 ... 99,999 RPM. In addition to the contact measurement, the speed can also be measured optically with the stroboscope.

- Measuring range contacting: 0.5 ... 99,999 RPM
- Measuring range optical: 5 … 99,990 RPM
- Temperature measurement: Type K, PT1000
- Strobe for speed determination
- Temperature measurement in °C and °F
Manufacturer: PCE Instruments
£ 222.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-OM 15

PCE-OM 15 is a handheld stroboscope light or strobe tachometer with trigger functionality. This easy-to-use portable digital stroboscope light gun features high / low range selection and push-button rate control to scale the flash rate slower (x½) and faster (x2). In addition, two knobs allow coarse and fine adjustment of the flash rate.


- Measuring range: 50 ... 30000 rpm
- Bright 6500K xenon light bulb
- 10 mm / 0.4 in 5-digit LCD



Manufacturer: PCE Instruments
£ 303.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-T 240-ICA
The stroboscope has a contact speed measurement. The measuring range of the contact speed measurement with the stroboscope is 0.5 ... 99,999 RPM. In addition to the contact measurement, the speed can also be measured optically with the stroboscope.

- Measuring range contacting: 0.5 ... 99,999 RPM
- Measuring range optical: 5 … 99,990 RPM
- Temperature measurement: Type K, PT1000
- Strobe for speed determination
- Temperature measurement in °C and °F
- incl. ISO Calibration Certificate
Manufacturer: PCE Instruments
£ 334.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DSX 20
The stroboscope PCE-DSX 20 is mostly used for speed or vibration measurement or for motion observations. This stroboscope has a small design and has a low weight. Thus, the stroboscope can be conveniently used even in measurements in hard to reach places.

Function
- Speed: 50 ... 35000 RPM / FPM
- Flash frequency
- phase shift
- Lamp type: Xenon flash
- Flash response time: 10 ... 30 μs
- With trigger input
Manufacturer: PCE Instruments
£ 343.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-OM 15-ICA

PCE-OM 15-ICA is a stroboscope with trigger functionality. This easy-to-use portable digital stroboscope gun features high / low range selection and push-button rate control to scale the flash rate slower (x½) and faster (x2). In addition, two knobs allow coarse and fine adjustment of the flash rate.


- Measuring range: 50 ... 30000 rpm
- Bright 6500K xenon light bulb
- 10 mm / 0.4 in 5-digit LCD
- Incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
£ 415.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-DSX 20-ICA
The stroboscope light PCE-DSX 20-ICA is mostly used for speed or vibration measurement or for motion observations. This stroboscope light has a small design and has a low weight. Thus, the stroboscope light can be conveniently used even in measurements in hard to reach places.

Function
- Speed: 50 ... 35000 RPM / FPM
- Flash frequency
- phase shift
- Lamp type: Xenon flash
- Flash response time: 10 ... 30 μs
- With trigger input
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
£ 450.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-LES 100-ICA

The PCE-LES 100-ICA Stroboscope combines LED technology with compact and accurate electronics, which controls the sequence and timing of flash over the entire measuring range. Thanks to LED technology, the stroboscope does not need periodic changing of bulbs. The stroboscope is sent to you calibrated (by the manufacturer PCE Instruments).


- Range: 60 ... 99,990 r.p.m / 1 ... 1,666 Hz
- 2 bright LEDs (1400 lux @ 50 cm)
- Display: 5 digits LCD
- Impulses/Flash: Possibility of duplication and division/fine tuning
- Offset: Yes, 360º

Manufacturer: PCE Instruments
£ 507.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: RT STROBE 3000 LED

Stationary stroboscope with intelligent LED-technology.


- Wear-resistant LED flash production
- 0 to 120,000 FPM
- 6000 LUX at 30 cm
- Illumination area of 20 by 30 cm
- Widths > 300 mm
- Strobes can be connected in parallel



Manufacturer: PCE Instruments
£ 1,127.00

Price excl. VAT &. delivery
2 year Warranty

Order no.: PCE-HSC 1660
The stroboscope PCE-HSC 1660 is suitable for simple slow motion recordings in industry and research. With the stroboscope, film recordings can be made at a frame rate of 2420 frames per second. This stroboscope is distinguished by its compact design and ease of use.

- CMOS: 1.3 megapixels
- Max. resolution: 1280 x 1024
- 2420 frames per second
- USB 3.0
- Can be controlled directly via PC
- Battery life approx. 150 minutes
- Slow motion function
Manufacturer: PCE Instruments
£ 3,960.00

Price excl. VAT &. delivery
2 year Warranty
