Spectrophotometer

Order no.: PCE-XXM 20
The spectrophotometer PCE-XXM 20 is used to quickly measure the color of surfaces. The spectrophotometer has a highly sensitive RGB photodiode as a color sensor. The measurement of the color with the spectrophotometer PCE-XXM 20 takes place in the LAB color space.

- Color spaces: CIE LAB, CIE XYZ, RGB, CMYK, Pantone
- Wavelength colour sensor: 400 ... 720 nm
- Interface: Micro-USB / Bluetooth
- Sensor: RGB Photodiode
- "Meterbox Lab" App (Playstore) (Android)
- "Meterbox Lab" App (App Store) (IOS)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CRM 40

PCE-CRM 40 is a portable handheld LED spectrophotometer used to accurately measure the correlated color temperature (CCT - in Kelvin), illuminance, chromaticity, excitation purity (Pe), luminous flux (in lumens - lm), RGB and dominant wavelength of light sources such as LED, organic LED (OLED) and other forms of organic electroluminescence (EL).


- Measuring range: 0.1 ... 150,000 lux / 0.01 ... 15,000 foot-candle
- Spectral wavelength range: 360 ... 780 nm
- Display: 3.2" colour LCD
- Chromaticity: Ev xy, Ev u'v'

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 8

The spectrophotometer PCE-CSM 8 was developed for quality control, offers a high accuracy and comes with a 3.5" touch screen display. When using the spectrophotometer, you can choose between different color spaces (CIE LAB, XYZ, Yxy, LCh, and LUV) and 13 illuminants. The reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily to determine delta pass/fail.  58 mm sphere with wavelength from 400 to 700 nm in 10 nm increments.


CIE LAB, XYZ, Yxy, LCh, and LUV
- 13 illuminants to choose, white and black calibration
- 1000 alphanumeric reference values and up to 10,000 sample values memory
- WI, YI, TI, Mt, Color Stain, Color Fastness, SCI and SCE option (specular included and excluded)
- Measuring aperture of 8 mm and 45°/0° illumination/viewing angle

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 20
PCE-CSM 20 is a handheld spectrophotometer used for high-quality color measurement. Featuring a single 8 mm aperture and including SCI and SCE specular modes for industrial color measuring applications, the PCE-CSM 20 offers a long battery life, a 4-color lamp with long life and an easy-to-use portable design. The PCE-CSM 20 covers the full spectrum from 400 to 700 nm in 10 nm increments. Camera/illumination locating for small samples.

- Measuring geometry: 8° / d
- Includes Yellowness, Whiteness, Opacity, Staining and other color indexes
- USB cable and software for data transfer
- 2000 reference standard memory, 20,000 sample memory
- Light source: D65, A, C, D50
- Color ranges: CIE L*a*b, XYZ, Yxy, LCh, CIE LUV, Hunter L*A*B
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 21
PCE-CSM 21 is a handheld spectrophotometer used for high-quality color measurement. Featuring a custom 4 mm aperture and including SCI and SCE specular modes for industrial color measuring applications, the PCE-CSM 21 offers a long battery life, a 9-color lamp and an easy-to-use portable design. The PCE-CSM 21 covers the full spectrum from 400 to 700 nm in 10 nm increments. Camera/illumination locating for small samples.

- Measuring geometry: 8° / d
- Includes Yellowness, Whiteness, Opacity, Staining and other color indexes
- Bluetooth 4.0 and USB cable for data transfer
- 2000 reference standard memory, 20,000 sample memory
- Light sources: D65, A, C, D50, D55, D75, F2, F7, F11
- Color ranges: CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 10

The spectrophotometer PCE-CSM 10 was developed for quality control, offers a high accuracy and comes with a 3.5" touch screen display. You can choose between different color spaces like CIE L*A*B, XYZ, Yxy, LCh, LUV, LCH, LAB &WI &YI, Color Fastness, and Staining Fastness. 400 to 700 nm photodiode array for 10 nm wavelength increments with Reflectance Curve graph.


CIE L*A*B/LCh, CIE XYZ/Yxy, CIE LUV/LCH, LAB &WI &YI, Color Fastness, and Color Staining
- Measuring geometry 10° or 2°/d
- Black and white calibration
- Opacity, 18 light source options, metameric index, CIE 1976/1994/2000
- 1000 Standards, 15,000 sample memory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 30
This very accurate tabletop spectrophotometer is intended for laboratory use to perform measurements on liquids, paper, textiles or other reference samples. This spectrophotometer uses both transmission and reflectance to accurately measure liquids, solids, and pastes.

Chromaticity for spectral reflection:  Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.02
Chromaticity for spectral transmittance:  Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.02

- Color touchscreen
- 256 Pixel CMOS sphere-type Image Sensor
- Data storage: 2000 Standards, 20,000 Samples
- Menu languages: English, Chinese
- Single and average measurements
- Data interface: USB
- Device software included
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CSM 31
The spectrophotometer, like any other spectrometer, is responsible for colorimetry. This very accurate table spectrophotometer is intended for laboratory use to perform measurements on paper, textiles or, for example, reference samples.

Chromaticity for spectral reflection:
Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.01
Chromaticity for spectral transmittance:
Φ 25.4 mm / SCI, standard deviation ΔE*ab 0.03

- Touchscreen
- 256 Pixel CMOS Image Sensor
- Data storage: 5000 Standards, 40000 Samples
- Menu languages: English, Chinese
- Single and average measurements
- Data interface: USB, Bluetooth
- Device software
Manufacturer: PCE Instruments
