Shock Data Logger

Shock Data logger PCE-VDL 16I
£ 222.00
Price excl. VAT &. delivery
2 year Warranty
The shock data logger PCE-VDL 16I from PCE Instruments measures and stores the relevant measured variables: temperature, relative humidity, air pressure, light as well as acceleration in three axes by means of a vibration sensor. Therefore, this shock data logger is ideal for monitoring vibrations on machines while simultaneously measuring and recording the relevant environmental conditions of the system.

- 3-Axis acceleration up to 800 Hz
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Temperature, Humidity, Air pressure, Vibration, and Light

Shock Data Logger PCE-VDL 24I 3-Axis
£ 267.00
Price excl. VAT &. delivery
2 year Warranty
For this shock data logger PCE-VDL 24I the acceleration sensor is delivered with a sampling rate of 1600 Hz. The sensor measures the acceleration, which is currently acting on it (3 axes), for example shock / vibration. The measurements take place at predetermined (selectable) time intervals.

- 3-Axis acceleration up to 1600 Hz and ±16 g
- 32 GB SD memory card
- Evaluation software
- Small design: 86.8 x 44.1 x 22.2 mm / 3.4 x 1.7 x 0.87 in
Shock Data Logger PCE-VDR 10-ICA incl. ISO Calibration Certificate
£ 851.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

PCE-VDR 10-ICA is a single-axis accelerometer or shock data logger with real-time measurement and data logging capabilities. This shock data logger records acceleration (m/s, g, ft/s) as well as velocity (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory. There is also an analog output, which makes this shock data logger compatlble with control systems.

- Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Velocity measuring ranges:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface
- incl. ISO Calibration Certificate

Shock Data Logger PCE-VD 3-ICA incl. ISO Calibration Certificate
£ 293.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

PCE-VD 3-ICA is a shock data logger that measures 3-axis shock/vibration via a built-in accelerometer sensor. This shock data logger records 3-axis acceleration (X, Y, Z) vibration measurement data for Fast Fourier Transform (FFT) waveform analysis. The shock data logger connects to your PC via a USB port for configuration and for quick and easy data transfer.


- Measuring range: ±16 g per axis
- Frequency range: 0 ... 60 Hz
- Recording interval: Adjustable from 1 sec .... 24 hr
- Logs and stores up to 168,042 records
- Includes magnetic bracket with wall-mounting screws
- incl. ISO Calibration Certificate

Shock Data Logger PCE-VD 3
£ 139.00
Price excl. VAT &. delivery
2 year Warranty

The 3-axis Shock Data Logger PCE-VD 3 is a miniaturized universal Data Logger with an included built-in 3-axis acceleration sensor (X, Y, Z axes). The internal sensor of the 3-Axis Shock Data Logger PCE-VD 3 measures acceleration force along the X, Y, and Z axes with a measurement range of ±16 g per axis. These 3-Axis Shock Data Logger PCE-VD 3 are manufacturer calibrated. An ISO calibration certificate is an option.


- 3-axis vibration data logging
- Software included -USB port
- Light weight
- Stand included
- Storage capacity: 8 Mbit (168042 records)
- Magnetic wall mount



Shock Data Logger PCE-VDR 10
£ 676.00
Price excl. VAT &. delivery
2 year Warranty

PCE-VDR 10 is a single-axis accelerometer or shock data logger with real-time measurement and data logging capabilities. This single-axis shock data logger records acceleration (m/s, g, ft/s) as well as velocity (mm/s, cm/s, in/s) measurements and saves the measured data to an included SD card memory. There is also an analog output, which makes this shock data logger compatlble with control systems.


- Single-axis Acceleration measuring range:
  0.5 ... 199.9 m/s, 0.05 ... 20.39 g, 2 ... 656 ft/s
- Velocity measuring ranges:
  0.5 ... 199.9 mm/s, 0.05 ... 19.99 cm/s, 0.02 ... 7.87 in/s
- Frequency range: 10 ... 1000 Hz
- Analog output: 4 ... 20 mA
- RS-232 and USB interface
