Pressure Gauge

Pressure Gauge PCE-HVAC 10
£ 219.00
Price excl. VAT &. delivery
The pressure gauge is a robust measuring instrument designed for daily use in refrigeration systems and heat pumps to determine pressure and temperature. Measurement with the pressure gauge is carried out using supplied refrigerant hoses and 2 NTC clamp-on temperature sensors. The 83 preloaded refrigerants can be quickly selected and are visible on the measurement screen.

  • Measurement Range: -1 … +60 bar
  • Resolution: 0.01 bar
  • Accuracy: ±0.5% F.S. (Full Scale)
  • 83 refrigerants stored in the device
  • 2-way valve block with 3 connectors 7/16" – UNF
  • Includes 2 NTC clamp-on temperature sensors
  • Temperature measurement -10 … +200 °C
Pressure Gauge PCE-PDA 10L
£ 627.00
Price excl. VAT &. delivery

The differential pressure gauge PCE-PDA 10L is a reliable differential pressure gauge for pressure measurement of gases in the range of ±20 kPa. The differential pressure gauge PCE-PDA 10L has many different pressure measuring functions.

  • Measuring range: ± 20 kPa /± 2.9 psi / ± 0.2 bar
  • Resolution: 10 Pa / 0.00145 psi / 0.0001 bar
  • Accuracy: ± 0.5% of final value
  • Min and Max value memory
  • Data logger and leak test
  • Temperature measurement, flow measurement
  • Pitot tube not included in delivery / optionally selectable

Pressure Gauge PCE-PDA A100L
£ 697.00
Price excl. VAT &. delivery

The pressure gauge PCE-PDA A100L is suitable for the measurement of atmospheric pressure. This pressure gauge records the pressure from absolute zero to 200 kPa. The pressure gauge can be used for many mobile applications in industry and crafts.


  • Measuring range pressure: 0 … 200 kPa absolute
  • Resolution: 0.01 kPa, 0.1 kPa
  • Accuracy: < ± 0.5% of the measuring range
  • USB interface
  • Datalogger
  • Different units

Pressure Gauge PCE-P01
£ 140.00
Price excl. VAT &. delivery

The pressure gauge is a robust, compact and comprehensive differential pressure measuring device for measuring pressure in 11 adjustable units. The pressure gauge is particularly suitable for the complete documentation of your measuring tasks.

  • Measurement of differential pressure and relative pressure
  • 11 selectable units: mbar, bar, psi, kPa, …
  • Measuring range from -140 to +140 mbar
  • Min / max and average value display directly on the display
  • USB interface

Pressure Gauge PCE-MPM 10
£ 76.00
Price excl. VAT &. delivery

The pressure gauge is a small and handy measuring device for determining the differential air pressure. The pressure gauge has a measuring range of ±5000 Pa. The pressure gauge is connected via two hose connections with a diameter of 8 mm.

  • Measuring range: ±5000 Pa
  • 11 different pressure units:Pa, hPa, mBar, mmH2O, mmHg, inH2O, inHg, psi, ozin², bar, kPa
  • Medium: gaseous
  • Zero point calibration

Pressure Gauge PCE-PME 10
£ 76.00
Price excl. VAT &. delivery
The digital Pressure Gauge is an accurate and compact meter for differential pressure measurement in a wide range of applications, such as measuring filter resistances, pressure in furnaces, orifices, gas-air ratio equalisation, combustion processes, air conditioning systems, ventilation systems, etc. The Pressure Gauge is suitable for measuring non-aggressive and non-explosive gases.

  • measurement range -10 ... +10 kPa (-100 ... +100 mbar)
  • resolution 0.01 kPa
  • accuracy: ±1 % FS
  • MAX, MIN, AVG value, HOLD
  • audible alarm
  • 13 selectable pressure units
  • USB-C with data transfer
  • PC software
Pressure Gauge PCE-PME 40
£ 88.00
Price excl. VAT &. delivery
The digital Pressure Gauge is an accurate and compact meter for differential pressure measurement in a wide range of applications, such as measuring filter resistances, pressure in furnaces, orifices, gas-air ratio equalisation, combustion processes, air conditioning systems, ventilation systems, etc. The Pressure Gauge is suitable for measuring non-aggressive and non-explosive gases.

  • measurement range -40 ... +40 kPa (-400 ... +400 mbar)
  • resolution 0.01 kPa
  • accuracy: ±1 % FS
  • MAX, MIN, AVG value, HOLD
  • audible alarm
  • 13 selectable pressure units
  • USB-C with data transfer
  • PC software
Pressure Gauge PCE-PME 4
£ 105.00
Price excl. VAT &. delivery
The digital Pressure Gauge is an accurate and compact meter for differential pressure measurement in a wide range of applications, such as measuring filter resistances, pressure in furnaces, orifices, gas-air ratio equalisation, combustion processes, air conditioning systems, ventilation systems, etc. The Pressure Gauge is suitable for measuring non-aggressive and non-explosive gases.

  • measurement range -4 ... +4 kPa (-40 ... +40 mbar)
  • resolution 0.01 kPa
  • accuracy: ±1 % FS
  • MAX, MIN, AVG value, HOLD
  • audible alarm
  • 13 selectable pressure units
  • USB-C with data transfer
  • PC software
Pressure Gauge PCE-PME 50
£ 109.00
Price excl. VAT &. delivery
The digital Pressure Gauge is an accurate and compact meter for differential pressure measurement in a wide range of applications, such as measuring filter resistances, pressure in furnaces, orifices, gas-air ratio equalisation, combustion processes, air conditioning systems, ventilation systems, etc. The Pressure Gauge is suitable for measuring non-aggressive and non-explosive gases.

  • measurement range -50 ... +50 kPa (-500 ... +500 mbar)
  • resolution 0.01 kPa
  • accuracy: ±1 % FS
  • MAX, MIN, AVG value, HOLD
  • audible alarm
  • 13 selectable pressure units
  • USB-C with data transfer
  • PC software
