Pipe Locator

Order no.: PCE-160 CB
The PCE-160 CT pipe locator is a line locator for hard-to-reach cables and is used, for example, in the automotive sector. In addition to the line location, there is also the continuity test with the pipe locator.

- Sensitivity adjustment
- Headphone jack
- Different beeps
- Cable tracking in walls and cable channels
- For mobile use
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-LT 20
The PCE-LT 20 pipe locator is used to determine the correct assignment of wire pairs in network cables. Furthermore, the pipe locator can be used to locate lines and determine the connection between cables.

- Automatic / manual test of lancets
- Main and remote unit
- Testing of coaxial cables, single cores ...
- Cable location up to 50 cm depth
- For testing of analog telephone systems
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CL 10

PCE-CL 10 is a pipe locator that uses the conductive method to detect metal pipes or pipe tracer wires. With PCE-CL 10, you also can locate power cables, lines, circuits, short circuits and ground points, as well as test protective tubing and coaxial cables. To perform these functions, it is not necessary to disconnect the power. Location can be identified in floors, ceilings, walls and the ground, even behind concrete and brick.


- Operating temperature / humidity: 0 ... +40 ºC or +32 ... +104 ºF / max. 80% rh
- Storing temperature / humidity: -20 ... +60 ºC or -4 ... +140 ºF/ max. 80% rh
- Max. Voltage: 400 VAC (0 - 60 Hz) / 400 V DC



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CL 20

PCE-CL 20 is a cable or pipe locator used to detect live and voltage-free electrical wires. This cable detector also can be used to locate metallic and non-metallic gas or water pipes, identify short circuits, and follow lines inside walls or under flooring.


- Output signal: 125 kHz
- Compatible with one- or two-pole circuits
- Automatic, manual and UAC measuring modes



Manufacturer: PCE Instruments
Test Instruments manufacturer
