| Direct voltage DC | |
| Measuring range | 0 ... 400 mV |
| Resolution | 0,1 mV |
| Accuracy | ±(1.5 % of reading +10 digits) |
| Direct voltage DC | |
| Measuring range | 400 mV ... 4 V |
| Resolution | 0,1 mV |
| Accuracy | ±(1.5 % of reading +10 digits) |
| Direct voltage DC | |
| Measuring range | 4 ... 40 V |
| Resolution | 0,1 mV |
| Accuracy | ±(1.5 % of reading +10 digits) |
| Direct voltage DC | |
| Measuring range | 40 ... 400 V |
| Resolution | 0,1 mV |
| Accuracy | ±(1.5 % of reading +10 digits) |
| Direct voltage DC | |
| Measuring range | 400 ... 600 V |
| Resolution | 0,1 mV |
| Accuracy | ±(1.5 % of reading +10 digits) |
| Capacity | |
| Measuring range | 0 ... 4 nF |
| Resolution | 1 pF |
| Accuracy | ±(4% of reading +10 digits) |
| Capacity | |
| Measuring range | 4 ... 40 nF |
| Resolution | 1 pF |
| Accuracy | ±(4% of reading +10 digits) |
| Capacity | |
| Measuring range | 40 ... 400 nF |
| Resolution | 1 pF |
| Accuracy | ±(4% of reading +10 digits) |
| Capacity | |
| Measuring range | 400 nF ... 4 µF |
| Resolution | 1 pF |
| Accuracy | ±(4% of reading +10 digits) |
| Capacity | |
| Measuring range | 4 ... 400 µF |
| Resolution | 1 pF |
| Accuracy | ±(4% of reading +10 digits) |
| Capacity | |
| Measuring range | 400 µF ... 4 mF |
| Resolution | 1 pF |
| Accuracy | ±(10% of reading +15 digits) |
| AC voltage | |
| Measuring range | 0 ... 4 V |
| Resolution | 1 mV |
| Accuracy | ±(2% v.Mw. +10 Digits) |
| Frequency range | 50 ... 2000 Hz |
| AC voltage | |
| Measuring range | 4 ... 40 V |
| Resolution | 1 mV |
| Accuracy | ±(2% v.Mw. +10 Digits) |
| Frequency range | 50 ... 2000 Hz |
| AC voltage | |
| Measuring range | 40 ... 400 V |
| Resolution | 1 mV |
| Accuracy | ±(2% v.Mw. +10 Digits) |
| Frequency range | 50 ... 2000 Hz |
| AC voltage | |
| Measuring range | 400 ... 600 V |
| Resolution | 1 mV |
| Accuracy | ±(2% v.Mw. +10 Digits) |
| Frequency range | 50 ... 2000 Hz |
| Alternating current AC | |
| Measuring range | 0 ... 40 A |
| Resolution | 10 mA |
| Accuracy | ±(2.5% of reading +10 digits) |
| Alternating current AC | |
| Measuring range | 40 ... 400 A |
| Resolution | 0,1 A |
| Accuracy | ±(2.5% of reading +10 digits) |
| Resistance | |
| Measuring range | 0 ... 400 Ω |
| Resolution | 0,1 Ω |
| Accuracy | ±(1 % of Rd +5 digits) |
| Resistance | |
| Measuring range | 400 Ω ... 4 kΩ |
| Resolution | 0,1 Ω |
| Accuracy | ±(1 % of Rd +5 digits) |
| Resistance | |
| Measuring range | 4 ... 40 kΩ |
| Resolution | 0,1 Ω |
| Accuracy | ±(1 % of Rd +5 digits) |
| Resistance | |
| Measuring range | 40 ... 400 kΩ |
| Resolution | 0,1 Ω |
| Accuracy | ±(1 % of Rd +5 digits) |
| Resistance | |
| Measuring range | 400 kΩ ... 4 M Ω |
| Resolution | 0,1 Ω |
| Accuracy | ±(1 % of Rd +5 digits) |
| Resistance | |
| Measuring range | 4 ... 40 M Ω |
| Resolution | 0,1 Ω |
| Accuracy | ±(3 % of Rd +5 digits) |
| Frequency | |
| Measuring range | 10 Hz ... 30 kHz |
| Resolution | 0,1 Hz |
| Accuracy | ±(2.5% of reading +10 digits) at 4 … 600 V |
| Temperature | |
| Measuring range | -20 ... +250 °C |
| Resolution | 1 °C |
| Accuracy | ±(2% +3°C) |
| Oscilloscope specifications | |
| Bandwidth | 2 kHz |
| Sampling rate | 2 kSa/s |
| General technical data | |
| Display type | LCD |
| Storage medium | Internal memory |
| Memory capacity (additional information) | Multimeter mode: 100 records, oscilloscope mode: 10 waveforms |
| Dimensions | Clamp opening: 35 x 49 mm |
| Menu language | English, English (GB) |
| Protection class (device) | IP20 |
| Power supply | batteries |
| (Rechargeable) battery | 3 x 1,5 V AAA battery , Alkali-manganese |
| Capacity | 1270 mAh |
| Operating conditions | 0 ... 40 °C , 0 ... 75 (non-condensing)% RH |
| Storage conditions | -10 ... 60 °C , 0 ... 90 (non-condensing)% RH |
| Dimensions ( L x W x H ) | 212 x 74 x 35 mm |
| Weight | 264 g |
