Noise Dose Meter / Sound Dose Meter

Here you will find a full range with an industrial standard noise meter / sound meter to suit every requirement. With the portable noise meter you can carry out measurements quickly to gain control of a situation or to set the sound meter to take timed measurements. The noise meter is important for all industries, especially by using it as a mobile noise meter which is able to assess office stress levels or street noise levels. Often problems arise from noisy neighbours or if bars and restaurants are in residential areas and produce noise levels after 10 pm in excess of what local laws permit. A noise meter / sound meter will help here.

We can assess which noise meter or sound meter you require in relation to the issue you have and the relating laws (requirements regarding a sound meter and a sound meter’s usage vary depending on the country). We also have noise meter microphone extension cords, tripods, sound meter calibrators and calibration certificates for most noise meter models.

Video with Wolfgang Rudolph

What is a sound level meter and how does it work?

What is a sound level meter and how does it work?
Watch video

If you have any questions about the products on this website, please contact us at or +44 ( 0 ) 161 464902 0.

Noise Dose Meter (Badge Type) PCE-MND 10

£ 1,023.00

Price excl. VAT &. delivery

The noise dose meter (badge type) was specially developed for measuring noise exposure in workplaces and complies with the IEC 61252:2002 standard. With a measuring range of 70 … 140 dB and a frequency weighting of A, B and Z, the sound dosimeter is ideal for this.

Measuring range: 70 … 140 dB
Frequency weighting: A, B and Z
Battery life: >15 hours
LEQ measurement
Memory
USB interface
Battery / power supply
Software download
Standards: IEC 61252:2002, ANSI S1.25-1991

Sound Dose Meter (Badge Type) PCE-MND 10-ICA incl. ISO Calibration Certificate

£ 1,122.00

Price excl. VAT &. delivery

The Sound Dose Meter (badge type) was specially developed for measuring noise exposure in workplaces and complies with the IEC 61252:2002 standard. With a measuring range of 70 … 140 dB and a frequency weighting of A, B and Z, the sound dosimeter is ideal for this.

Measuring range: 70 … 140 dB
Frequency weighting: A, B and Z
Battery life: >15 hours
LEQ measurement
Memory
USB interface
Battery / power supply
Standards: IEC 61252:2002, ANSI S1.25-1991- incl. ISO Calibration Certificate

Noise Dose Meter PCE-NDL 10 with Data-Logging

£ 663.00

Price excl. VAT &. delivery

The data-logging noise dose meter is used to determine volume. The PCE-NDL 10 data-logging noise dose meter is a handy measuring device that meets the highest requirements. In order to evaluate the measured data in the best possible way, it is possible to use the internal measurement data memory on the noise dosimeter. In addition, the data-logging noise dose meter has an SD card slot that enables the use of an SD card as an additional storage medium.

Measuring range: SPL: Auto 30 … 130 dB
Resolution: 0.1 dB
Low sampling rate
Automatic or manual storage
Selectable storage interval
Backlit LC display
Dose measurement or SPL measurement

Sound Dose Meter PCE-NDL 10-ICA incl. ISO Calibration Certificate

£ 798.00

Price excl. VAT &. delivery

The data-logging Sound Dose Meter is used to determine volume. The PCE-NDL 10 data-logging Sound Dose Meter is a handy measuring device that meets the highest requirements. In order to evaluate the measured data in the best possible way, it is possible to use the internal measurement data memory on the noise dosimeter. In addition, the data-logging Sound Dose Meter has an SD card slot that enables the use of an SD card as an additional storage medium.

Measuring range: SPL: Auto 30 … 130 dB
Resolution: 0.1 dB
Low sampling rate
Automatic or manual storage
Selectable storage interval
Backlit LC display
Dose measurement or SPL measurement

Noise Dose Meter PCE-SLD 10

£ 327.00

Price excl. VAT &. delivery

The noise dose meter PCE-SLD 10 is used for permanent monitoring of the sound level. In addition to storing the measured values, the PCE-SLD 10 noise dose meter is able to display the measured values on a display and output them as a 4 … 20-mA analog value.

Measuring range: 30 … 130 dB
Measurement accuracy: Based on class 2 according to IEC61672
Resolution: 0.1 dB
LC display
SD card memory up to 16 GB
external microphone
Analog output with 4 … 20-mA

Sound Dose Meter PCE-SLD 10-ICA Incl. ISO Calibration Certificate

£ 406.00

Price excl. VAT &. delivery

The Sound Dose Meter PCE-SLD 10 is used for permanent monitoring of the sound level. In addition to storing the measured values, the PCE-SLD 10 Sound Dose Meter is able to display the measured values on a display and output them as a 4 … 20-mA analog value.

Measuring range: 30 … 130 dB
Measurement accuracy: Based on class 2 according to IEC61672
Resolution: 0.1 dB
LC display
SD card memory up to 16 GB
external microphone
Analog output with 4 … 20-mA
Incl. ISO calibration certificate

Noise Dose Meter PCE-354

£ 113.00

Price excl. VAT &. delivery

The noise dose meter is a small handheld device with many functions such as peak measurement, Leq value calculation and adjustable measuring ranges. In addition, the noise dose meter can freeze the largest measured value with the MAX function so that you can really judge whether a limit has been exceeded.

Measuring range: 30 … 130 dB
Measuring function: Leq, LAp and LCp
Memory function 99 measured values
Frequency range 20 … 12500 Hz
Display with backlight

Noise Dose Meter PCE-354-ICA incl. ISO-Calibration Certificate

£ 224.00

Price excl. VAT &. delivery

Measuring range: 30 … 130 dB
Measuring function: Leq, LAp and LCp
Memory function 99 measured values
Frequency range 20 … 12500 Hz

Display with backlight
incl. ISO-Calibration Certificate

Sound Dose Meter PCE-TSM 3

£ 52.00

Price excl. VAT &. delivery

The Sound Dose Meter is a versatile desktop device that can be used wherever precise monitoring of ambient noise is required, for example in offices, libraries, schools, recording studios or even in private rooms for noise monitoring. Thanks to its compact size and user-friendly operation, the Sound Dose Meter is ideal for stationary use on a desk or at workstations where noise levels play an important role.

Sound level: 30 ... 130 dB
Resolution: 0.1 dB
Accuracy: ±1.5 dB
Temperature: -10 ... 60°C / 14 ... 140°F
Humidity: 20 ... 85%
Frequency range: 50 ... 8500 Hz
USB-C interface
For library, classroom etc.

Noise Dose Meter PCE-EM 750

£ 86.00

Price excl. VAT &. delivery

This multifunctional Noise Dose Meter combines five important functions in a single, compact device. The Noise Dose Meter measures sound level, light intensity, air speed, temperature and humidity - and thus reliably covers the most important environmental parameters.

Sound level: 35 ... 130 dBA
Air velocity: 0.5 ... 30 m/s
Volume flow: 150 ... 9000 CMM
Light intensity: 0 ... 200 klux
Temperature: -20 ... 60°C / -4 ... 140°F
Humidity: 35 ... 80% r. h.
Adjustable alarm for lux measurement
Colored bar display

Noise Dose Meter / Sound Dose Meter PCE-322ALEQ

£ 403.00

Price excl. VAT &. delivery

The Noise Dose Meter / Sound Dose Meter PCE-322ALEQ is particularly suitable for measuring noise in the field of industrial, health, safety, and environmental monitoring. The PCE-322ALEQ Noise Dose Meter / Sound Dose Meter has a logger function, which allows storage of up to 32700 readings.

Automatic range: 30 … 130 dB
Manual range: 30 … 80 / 50 … 100 / 80 … 130 dB
Resolution: 0.1 dB
Accuracy: ±1.4 dB
Memory capacity: 32700 values
incl. software for LEQ calculation Important! The LEQ value is only calculated by the software after the data transfer from the device to the PC or laptop.

Noise Dose Meter / Sound Dose Meter PCE-322ALEQ-ICA incl. ISO-Calibration Certificate

£ 486.00

Price excl. VAT &. delivery

The Noise Dose Meter / Sound Dose Meter PCE-322ALEQ is particularly suitable for measuring noise in the field of industrial, health, safety and environmental monitoring. The PCE-322ALEQ Noise Dose Meter / Sound Dose Meter has a logger function, which allows storage of up to 32700 readings.

Automatic range: 30 … 130 dB
Manual range: 30 … 80 / 50 … 100 / 80 … 130 dB
Resolution: 0.1 dB
Accuracy: ±1.4 dB
Memory capacity: 32700 values
incl. software for LEQ calculation Important! The LEQ value is only calculated by the software after the data transfer from the device to the PC or laptop.
incl. ISO-Calibration Certificate

Noise Dose Meter / Sound Dose Meter PCE-428

£ 1,113.00

Price excl. VAT &. delivery

PCE-428 is a Noise Dose Meter / Sound Dose Meter that meets IEC 60651:1979, IEC 60804:2000, IEC 61672-1:2013, ANSI S1.4-1983 and ANSI S1.43-1997 requirements. This portable high-accuracy sound level meter has a large easy-to-read illuminated LCD screen that displays the sound pressure level (SPL) numerically and graphically in real time. The sound level meter calculates the equivalent continuous sound level Leq (LXeq).

Measuring range: 25 … 136 dB(A)
LXY (SPL), Leq (LXeq), LXYSD, LXSEL, LXE, LXYmax, LXYmin, LXPeak, LXN
Frequency weighting: A, B, C and Z
Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
adjustable data-recording interval from 1 s … 24 h
1/1 octave band filter (optional 1/3 octave band filter upgrade)

Noise Dose Meter / Sound Dose Meter PCE-428-ICA incl. ISO-Calibration Certificate

£ 1,157.00

Price excl. VAT &. delivery

Measuring range: 25 … 136 db(A)
LXY (SPL), Leq (LXeq), LXYSD, LXSEL, LXE, LXYmax, LXYmin, LXPeak, LXN
Frequency weighting: A, B, C and Z
Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
adjustable data-recording interval from 1 s … 24 h
1/1 octave band filter (optional 1/3 octave band filter upgrade)
incl. ISO-Calibration Certificate

Noise Dose Meter / Sound Dose Meter PCE-430-ICA incl. ISO-Calibration Certificate

£ 2,136.00

Price excl. VAT &. delivery

The Noise Dose Meter / Sound Dose Meter meets all requirements for noise measurement and frequency analysis. This integrating precision pulse sound level meter complies with all applicable standards and guidelines.

Accuracy class 1
A, B, C & Z frequency weighting
Fast, Slow, Impulse and Peak time weighting
Statistics function
1/1 octave band included
1/3 octave band optional
incl. ISO-Calibration Certificate

Noise Dose Meter / Sound Dose Meter PCE-432

£ 2,181.00

Price excl. VAT &. delivery

PCE-432 is a class 1 data logging sound level meter that meets IEC 60651:1979, IEC 60804:2000, IEC 61672-1:2013, ANSI S1.4-1983 and ANSI S1.43-1997 requirements. This portable high-accuracy sound level meter is equipped with GPS functionality, allowing measured values to be assigned to a precise geographic location. The sound level meter calculates the equivalent continuous sound level Leq (LXeq).

Measuring range: 22 … 136 dB(A)
LXY (SPL), Leq (LXeq), LXYSD, LXSEL, LXE, LXYmax, LXYmin, LXPeak, LXN
Frequency weighting: A, B, C and Z
Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
GPS receiver for location determination
Adjustable data-recording interval from 1 s … 24 h
1/1 octave band filter (optional 1/3 octave band filter upgrade)

Noise Dose Meter / Sound Dose Meter PCE-SLM 50

£ 2,221.00

Price excl. VAT &. delivery

The Noise Dose Meter / Sound Dose Meter is certified in accordance with IEC 61672-1:2013, Class 1 and is ideally suited for professional use in noise monitoring. With a wide frequency range from 10 Hz to 20 kHz and extensive filter options, the device enables precise measurements in almost all areas of application. The Noise Dose Meter / Sound Dose Meter also impresses with its comprehensive connectivity: Ethernet, WiFi and USB Type-C enable flexible and uncomplicated data transfer.

Measuring range: 21 ... 143 dBA
Resolution: 0.1 dB
Class 1 accuracy IEC61672-1:2013
Frequency range: 10 Hz ... 20 kHz
Frequency weighting: A, C, Z
Time weighting: S, F, I
Ethernet, WiFi, USB Type-C
Internal memory: 8 GB
External SD card support: 32 GB / 64 GB
Measurement parameters: Lp, Lmax, Lmin, Leq, Lpeak
4-inch TFT touch display
PC software

Noise Dose Meter / Sound Dose Meter PCE-432-ICA incl. ISO-Calibration Certificate

£ 2,225.00

Price excl. VAT &. delivery

Measuring range: 22 … 136 dB(A)
LXY (SPL), Leq (LXeq), LXYSD, LXSEL, LXE, LXYmax, LXYmin, LXPeak, LXN
Frequency weighting: A, B, C and Z
Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
GPS receiver for location determination
Adjustable data-recording interval from 1 s … 24 h
1/1 octave band filter (optional 1/3 octave band filter upgrade)
incl. ISO-Calibration Certificate

Noise Dose Meter / Sound Dose Meter PCE-SLM 50-ICA incl. ISO-Calibration Certificate

£ 2,306.00

Price excl. VAT &. delivery

Measuring range: 21 ... 143 dBA
Resolution: 0.1 dB
Class 1 accuracy IEC61672-1:2013
Frequency range: 10 Hz ... 20 kHz
Frequency weighting: A, C, Z
Time weighting: S, F, I
Ethernet, WiFi, USB Type-C
Internal memory: 8 GB
External SD card support: 32 GB / 64 GB
Measurement parameters: Lp, Lmax, Lmin, Leq, Lpeak
4-inch TFT touch display
PC software
incl. ISO-Calibration Certificate

Measuring the Sound Dose

with a Noise Dosimeter

"The dose makes the poison." This summary of Paracelsus' knowledge from the 16th century does not only apply to substances that are absorbed through food, breathing or the skin. It also applies to various types of radiation that affect the body. It has been known for decades that X-rays, radioactive radiation and excessive noise exposure cause permanent damage to health.

The danger of hearing damage does not only exist at very high sound levels. There is also a risk of permanent hearing impairment if noise levels above a certain level are applied for too long. The cause of noise from the environment or at the workplace often cannot be directly influenced by those affected by the noise. However, if the noise cannot be reduced at the source, it is almost always possible to reduce the exposure through appropriate soundproofing measures or with the help of the personal hearing protection. If the level of the noise cannot be reduced, the duration of the noise exposure should be reduced.

Employers are obliged to protect their employees from health hazards at the workplace. Noise can be perceived, but its effect cannot be objectively assessed without auxiliary tools. Therefore, methods and devices for noise measurement and assessment have been developed. Noise dosimeters determine and store the sound exposure over defined periods of time and evaluate the recorded data according to the defined criteria.

For continuous noise levels and peak noise levels, certain limit and threshold values have been defined based on the evaluation of investigations. Before starting the measurements, care must be taken to ensure that the appropriate criteria for the regulation to be applied are set in the noise dosimeter. If the limit values are reached or exceeded, protective measures must be implemented and the employees informed.

Here is a table with important regulations and limit values for noise dose in the workplace:

	EU	UK	USA
Regulation	DIRECTIVE 2003/10/EC transposed into national regulations	The Control of Noise at Work Regulations 2005	The National Institute for Occupational Safety and Health (NIOSH) Occupational Safety and Health Administration (OSHA)
Lower trigger value L_EP,_d/ L_EX,8h/ L_EP,w	L_EP,_d/ L_EX,8h/ L_EP,w = 80 dB(A)	L_EP,_d/ L_EX,8h/ L_EP,w80 dB(A)	OSHA 80 dB (A)
Lower trigger level Peak level LCpeak_Cpeak	L_Cpeak = 135 dB(C)	L_Cpeak135 dB(C)
Upper trigger value L_EP,_d/ L_EX,8h/ L_EP,w	L_EP,_d/ L_EX,8h/ L_EP,w = 85 dB(A)	L_EP,_d/ L_EX,8h/ L_EP,w85 dB(A)	OSHA 85 dB (A)
Upper trigger level Peak level L_Cpeak	L_Cpeak = 137 dB(C)	L_Cpeak137 dB(C)
Limit value L_EP,_d/ L_EX,8h/ L_EP,w	L_EP,_d/ L_EX,8h/ L_EP,w = 87dB(A)	L_EP,_d/ L_EX,8h/ L_EP,w87dB(A)	NIOSH REL 85dB (A) = 100 % OSHA PEL90 dB (A) = 100 %
Limit value L_Cpeak	L_Cpeak = 140 dB(C)	L_Cpeak140 dB(C)	OSHA SPL_peak140 dB(A)

With a noise dosimeter, the noise exposure of an employee in the workplace can be determined without much effort. For this purpose, the dosimeter is usually attached to work clothing or a helmet as close to the ear as possible and worn during the working hours to be assessed. At the end of the shift, the data can be read out and used as a basis for the decisions on hearing protection. Some noise dosimeters display the determined values already during the measurement. This gives the user the possibility to react immediately in case of high exposure.
