Noise Dose Meter

Order no.: PCE-MSL 1
The Noise Dose Meter PCE-MSL 1 is a simple sound measuring device. The PCE-MSL 1 noise dose meter is used to quickly determine the ambient noise level. In addition to the volume measurement, the PCE-MSL 1 noise dose meter also has the option of determining the ambient temperature. The measurement of background noise is important in almost every situation today.

- Measuring range: 35...135 dB
- Frequency range: 31.5 Hz ... 8 kHz
- Accuracy: ±2 dB
- Frequency rating: A
- Class II
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-353

PCE-353 is a sound level meter, sound pressure level (SPL) meter, decibel (dB) meter, noise meter or noise dose meter used for acoustic measurements. With this meter, you are able to measure sound exposure level (SEL) as well as equivalent continuous sound level (Leq).


- Measuring range: 30 ... 130 dB
- Measurement parameters: Lp, Lmax, Leq, LN
- Resolution: 0.1 dB
- Accuracy: ±1 dB
- Frequency: 20 Hz ... 12.5 kHz
- Frequency weighting: A, C, F (Flat)
- Memory: Stores up to 30 groups with measuring conditions



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-353-ICA

PCE-353 is a class 2 sound level meter, sound pressure level (SPL) meter, decibel (dB) meter, noise meter or noise dose meter used for acoustic measurements. With this meter, you are able to measure sound exposure level (SEL) as well as equivalent continuous sound level (Leq). Having Leq measurement in such instruments is an important feature.


- Class 2
- Measuring range: 30 ... 130 dB
- Measurement parameters: Lp, Lmax, Leq, LN
- Resolution: 0.1 dB
- Accuracy: ±1 dB
- Frequency: 20 Hz ... 12.5 kHz
- Frequency weighting: A, C, F (Flat)
- Memory: Stores up to 30 groups with measuring conditions
- incl. ISO Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-322ALEQ
The noise dose meter PCE-322ALEQ is particularly suitable for measuring noise in the field of industrial, health, safety and environmental monitoring. The PCE-322ALEQ noise dose meter has a logger function, which allows storage of up to 32700 readings.


- Automatic range: 30 ... 130 dB
- Manual range: 30 ... 80 / 50 ... 100 / 80 ... 130 dB
- Resolution: 0.1 dB
- Accuracy: ±1.4 dB
- Memory capacity: 32700 values
- incl. software for LEQ calculation


Important! The LEQ value is only calculated by the software after the data transfer from the device to the PC or laptop.

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-322ALEQ-ICA
The noise dose meter PCE-322A is particularly suitable for measuring noise in the field of industrial, health, safety and environmental monitoring. The PCE-322A noise dose meter has a logger function, which allows storage of up to 32700 readings.


- Automatic range: 30 ... 130 dB
- Manual range: 30 ... 80 / 50 ... 100 / 80 ... 130 dB
- Resolution: 0.1 dB
- Accuracy: ±1.4 dB
- Memory capacity: 32700 values
- incl. software for LEQ calculation
- incl. ISO calibration certificate

Important! The LEQ value is only calculated by the software after the data transfer from the device to the PC or laptop.

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MSM 4

The noise dose meter PCE-MSM 4 has features that you will only find in other more expensive devices. The noise dose meter in a slim design is ideal for mobile measurements of sound.


- Automatic range: 30 ... 130 dB
- Manual range: 30 ... 80 / 50 ... 100 / 80 ... 130 dB
- Resolution: 0.1 dB
- Accuracy: ± 1.4 dB
- Frequency range: 31.5 Hz ... 8 kHz

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-MSM 4-ICA

The noise dose meter PCE-MSM 4 has features that you will only find in other more expensive devices. The class 2 noise dose meter in a slim design is ideal for mobile measurements of sound. It is not easy to find an instrument of this level for such a low price.


- Class 2

- Automatic range: 30 ... 130 dB
- Manual range: 30 ... 80 / 50 ... 100 / 80 ... 130 dB
- Resolution: 0.1 dB
- Accuracy: ±1.4 dB
- Frequency range: 31.5 Hz ... 8 kHz
- Time weighting: Fast, Slow
- Frequency weighting: A, C
- incl. ISO-Calibration Certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-428

PCE-428 is a class 2 data-logging noise dose meter that meets IEC 60651:1979, IEC 60804:2000, IEC 61672-1:2013, ANSI S1.4-1983 and ANSI S1.43-1997 requirements. This portable high-accuracy sound level meter has a large easy-to-read illuminated LCD screen that displays the sound pressure level (SPL) numerically and graphically in real time.

- Measuring range: 25 ... 136 db(A)
- A, B, C and Z frequency weightings
- Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
- Adjustable data-recording interval from 1 s ... 24 h
- 1/1 octave band filter (optional 1/3 octave band filter upgrade)
- Includes factory calibration certificate according to ISO 9001

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-430

PCE-430 is a class 1 data-logging noise dose meter that meets IEC 60651:1979, IEC 60804:2000, IEC 61672-1:2013, ANSI S1.4-1983 and ANSI S1.43-1997 requirements. This portable high-accuracy sound level meter has a large easy-to-read illuminated LCD screen that displays the sound pressure level (SPL) numerically and graphically in real time.

- Measuring range: 22 ... 136 db(A)
- A, B, C and Z frequency weightings
- Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
- Adjustable data-recording interval from 1 s ... 24 h
- 1/1 octave band filter (optional 1/3 octave band filter upgrade)
- Includes factory calibration certificate according to ISO 9001

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-430-EKIT

The Class 1 outdoor noise dose meter PCE-430-EKIT with integrated data logger meets all requirements for noise measurement and frequency analysis. This integrated precision pulse outdoor noise dose meter kit follows all valid standards and guidelines, and is designed for use outdoors in all weather. The typical applications for this instrument are the measurement of workplace noise, compliance, environmental noise detection, selection of hearing protector selection, selection of appropriate noise abatement measures and noise exposure estimation.



- Accuracy class 1
- A, B, C & Z frequency rating
- Fast, Slow, Pulse and Peak time weighting
- Statistics function
- 1/1 octave band included
- 1/3 octave band optional
- Incl. ISO calibration certificate
- Incl. Outdoor Alarm Noise Meter Kit PCE-4xx-EKIT
- Outdoor measurement of sound and noise

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-432

PCE-432 is a class 1 data-logging noise dose meter that meets IEC 60651:1979, IEC 60804:2000, IEC 61672-1:2013, ANSI S1.4-1983 and ANSI S1.43-1997 requirements. This portable high-accuracy sound level meter is equipped with GPS functionality, allowing measured values to be assigned to an exact geographic location.

- Measuring range: 22 ... 136 db(A)
- A, B, C and Z frequency weightings
- Time weighting: Fast (125 ms), slow (1 sec) and impulse (35 ms), decay (1500 ms)
- Adjustable data-recording interval from 1 s ... 24 h
- 1/1 octave band filter (optional 1/3 octave band filter upgrade)
- Includes factory calibration certificate according to ISO 9001

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-432-EKIT

The Class 1 outdoor noise dose meter PCE-432-EKIT can be used, e.g, for sound measurement of street noise, aircraft and train noise, event noise, noise coming from construction sites, ports, factories involving heavy machinery, airport/bus stations, stadiums, horse/motor racing tracks etc. The weather conditions do not matter, and hail, snow, rain and similar are no problem for this system for outdoor noise monitoring. The outdoor noise dose meter is equipped with a GPS receiver which allows the user to assign the measured values to an exact position.



- Accuracy class 1
- GPS function
- A, B, C & Z frequency rating
- Fast, Slow, Pulse and Peak time weighting
- Statistics function
- 1/1 octave band included
- 1/3 octave band optional
- Incl. ISO calibration certificate
- Incl. Outdoor Alarm Noise Meter Kit PCE-4xx-EKIT
- Outdoor measurement of sound and noise

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-NDL 10

PCE-NDL 10 is a high-quality noise dose meter or sound level meter with data logging capabilities. This noise dosimeter records sound pressure level (SPL) measurements as well as dosimetry (dose) measurements in decibels (dB) and saves the measurement data to the internal memory, which can then be transferred to an SD card (SD card included).


- Measuring range: 30 ... 130 dB (SPL) / 70 ... 130 dB (dose)
- Accuracy: ± 3.5 dB (31.5 Hz) ... ± 5.6 dB (8000 Hz)
- Data logging: Manual or adjustable automatic
- Sampling rate: Approx. 1 second
- Frequency weighting: A and C



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-EM 886

PCE-EM 886 is a portable handheld multifunctional digital sound meter used to measure sound, light, humidity, temperature, AC / DC current, electrical resistance, capacitance and frequency.


- Sound: 35 ...100 dB
- Light: 4,000 ... 40,000 lux
- Humidity: 33 ... 99% RH
- Temperature: 0 ... 50°C Indoor, -20 ... 1300ºC Type K
- Auto-ranging electrical multimeter

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-EM 882

PCE-EM 882 is a portable, handheld, multifunctional digital sound meter capable of measuring four different physical parameters. An ideal tool for use in industrial hygiene, HVAC performance assessment and environmental condition monitoring applications, this easy-to-use measuring instrument includes sensors for measuring sound, light, temperature and relative humidity.


- Sound: Low and high A- and C-weighted noise measurements
  from 35 ... 130 dB
- Light: 20, 200, 2000, 20000 lux ranges
- Temperature: Range from -20 ... 750ºC / -4 ... 1400ºF
- Relative humidity (RH): Range from 25 ...95% RH



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-428-EKIT

The outdoor noise dose meter PCE-428-EKIT, from the field of environmental measurement technology, is an optimal noise dose meter for measurements at workplaces, construction sites, in traffic, airports, etc. The outdoor noise dose meter is a class 2 device and is equipped with an octave band frequency filter. Optionally, the outdoor noise dose meter PCE-428-EKIT can be upgraded with a 1/3 octave band filter. The additional kit for outdoor sound measurement makes it possible to measure outdoor noise with a noise dose meter over a long period of time, even in the rain.



- Accuracy class 2
- A, B, C & Z frequency rating
- Fast, Slow, Pulse and Peak time weighting
- Statistics function
- 1/1 octave band included
- 1/3 octave band optional
- incl. ISO calibration certificate
- incl. outdoor noise level meter kit PCE-4xx-EKIT
- Outdoor measurement of sound and noise

Manufacturer: PCE Instruments
Test Instruments manufacturer
