NDT Test Instruments

Order no.: PCE-TC 28

The NDT tester PCE-TC 28 was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the NDT tester can be adjusted, depending on the operation purpose. Besides taking infrared images, the NDT tester can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


- Measurement range: -20 ... 300°C / -4 ... 572°F
- Accuracy: ± 2%, ± 2°C / 3.6°F
- Frequency image recording: 9 Hz
- Camera: 48608 Pixel



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 26FN-ICA
The PCE-CT 26FN NDT tester can measure non-destructive coatings (paints, plastics ...) on steel / iron and non-ferrous metals. The PCE-CT 26FN NDT tester is ideally suited to immediately detect, for example, accident damage to the vehicle.

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 26FN
The PCE-CT 26FN NDT tester can measure non-destructive coatings (paints, plastics ...) on steel / iron and non-ferrous metals. The PCE-CT 26FN NDT tester is ideally suited to immediately detect, for example, accident damage to the vehicle.

- Measuring range: 0 ... 1250 μm / 0 ...  49.2 mils
- Resolution: 1 μm / 0.039 mils
- Accuracy: ± (3% + 2 μm / 0.079 mils)
- Wear-resistant sensor
- V-groove for measurement on pipes
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-VE 50
The NDT testing borescope PCE-VE 50 is a compact video endoscope for the visual inspection of difficult to access areas. The camera head of the NDT testing borescope PCE-VE 50 on the semi-rigid cable transmits images directly to the LC display.

- Camera diameter: 8 mm
- Cable length: 770 mm
- Image sensor: 1/9 ", CMOS
- Effective pixels: 640 x 480 pixels
- Interface: Video connection via 3.5 mm jack
- Protection class: IP67 (camera hose only)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 60Plus

The PCE-GM 60Plus NDT tester is a portable handheld 60 degree gloss meter. This coating and paint gloss meter measures the gloss units (GU) on a material's surface. The rechargeable gloss meter or gloss tester uses reflected light for gloss measurement per ISO 2813, GB/T 9754, ASTM D523 and ASTM D2457 standards.


- Measuring geometry: 60° degree angle
- Measuring range: 0 ... 200 GU
- 3.5" TFT touchscreen display
- Measuring accuracy ±1.5 GU
- Light source: D65
- Wave length: 400-700 nm

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 75
The NDT tester - gloss meter has a measuring surface of Ø 4.5 mm. Thanks to this small measuring surface, the gloss meter enables measurements on particularly small surfaces. With a maximum inaccuracy of 1%, the gloss meter is a high-precision measuring instrument for fast and easy measurements on surfaces.

- Measuring range up to 1000 GU
- For measurements on small surfaces
- Precise measurements thanks to high accuracy
- Micro-USB interface for the PC connection
- Data memory for later evaluations
- Data memory: 1,245 measured values
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 60Plus-ICA

The PCE-GM 60Plus NDT tester or gloss meter is a portable handheld 60 degree gloss meter. This coating and paint gloss meter measures the gloss units (GU) on a material's surface. The rechargeable gloss meter or gloss tester uses reflected light for gloss measurement per ISO 2813, GB/T 9754, ASTM D523 and ASTM D2457 standards.


- Measuring geometry: 60° degree angle
- Measuring range: 0 ... 200 GU
- Measuring accuracy ±1.5 GU
- 3.5" TFT touchscreen display
- Light source: D65
- Wave length: 400-700 nm
- Incl. ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PGM 60

PCE-PGM 60 is a portable handheld NDT tester or gloss tester used to evaluate the shine on different material surfaces. The gloss tester includes a 3.5" TFT touchscreen display, internal memory and PC-compatible software for detailed analysis.


- Measuring geometry: 60° degree angle
- Measuring range: 0 ... 300 GU
- Standards: ISO 2813 / GB/T 9754 / ASTM D 523 / ASTM D 2457
- Includes PC-compatible software for detailed analysis
- Light source: D65
- Wave length: 400-700 nm

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 75-ICA
The NDT tester - gloss meter has a measuring surface of Ø 4.5 mm. Thanks to this small measuring surface, the gloss meter enables measurements on particularly small surfaces. With a maximum inaccuracy of 1%, the gloss meter is a high-precision measuring instrument for fast and easy measurements on surfaces.

- Measuring range up to 1000 GU
- For measurements on small surfaces
- Precise measurements thanks to high accuracy
- Micro-USB interface for the PC connection
- Data memory for later evaluations
- Data memory: 1,245 measured values
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 50

The PCE-GM 50 is a digital NDT tester or gloss meter with high accuracy (±1.2 gloss points). The PCE-GM 50 gloss meter determines surface color and luster. Areas of application include: building inspection, flooring, production quality control and painted, polished or varnished surface evaluation. This gloss tester comes manufacturer calibrated (ISO certification is optional).


- Optical measurement angle: 60° degree angle
- Measurement range: 0 to 200 gloss units or gloss points
- Calibration standard included in delivery



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-RM 100
The NDT tester - opacity meter PCE-RM 100 is used to measure the reflection properties of surfaces. The NDT tester - opacity meter PCE-RM 100 is used in tinting glass, film quality, opacity of paper, light shading and the hiding power of various paints, inks, and coatings.

- Measuring range: 0 ... 100 (0 is transparent and 100 is fully opaque)
- Optical measurement angle: 45º degree angle
- Measuring accuracy: ± 1
- Resolution: 0.1
- Battery operation
- Interface and software
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-HT 224E
The NDT Tester is a measuring tool for testing the strength of concrete. The NDT Tester measures strength according to the Schmidt principle. According to this measurement method, the quality of concrete can be measured with the NDT Tester.  The NDT Tester is also suitable for measuring hardness of rolled paper.  The NDT Tester displays measurements Rebound Value and can display force in PSI, MPa, kgF/cm², or N/mm².

- Measuring range: 10 ... 60 N/mm² / 1500 ... 8500 PSI (lbs / in²)
- Impact energy: 2.207 J or N-m / 0.225 kgf.m / 1.6278 ft-lb or Type N
- Digital Display of results
- USB interface for connection to a PC
Data storage
- Rechargeable battery
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-BTM 2000
The belt frequency meter is an optical measuring instrument for determining the belt tension force. This force measuring device consists of a display unit and a sensor on a gooseneck cable. The tension meter measures the tension of the belt in a stationary state.

- Measures the oscillation frequency of the belt
- Measuring range: 10 ... 900 Hz
- Accuracy: ± (1% of rdg. + 4 digits)
- Resolution: <100 Hz: 0.1 Hz
                      >100 Hz: 1 Hz
- Memory for 750 measured values
- Sensor on gooseneck
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 55
The NDT tester PCE-GM 55 is a 3-angle gloss meter. The measuring angles of the gloss meter are 20°, 45° and 75°. This allows the NDT tester to be used for gloss measurements in the high gloss and medium gloss ranges. The special measuring angle of 75° allows, among other things, measurements of the degree of gloss on paper and textiles.

- Range : 0 ... 200 gloss units / highlights
- Accuracy: ± 1 gloss units
- Repeatability: ± 0.5 gloss units
- Optical angle: 20°, 45°, 75°
- For medium and high gloss
- Measurements on textiles and paper possible
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 55-ICA
The NDT tester PCE-GM 55 is a 3-angle glossmeter. The measuring angles of the NDT tester are 20°, 45° and 75°. This allows the NDT tester to be used for gloss measurements in the high gloss and medium gloss ranges. The special measuring angle of 75° allows, among other things, measurements of the degree of gloss on paper and textiles.

- Range : 0 ... 200 gloss units / highlights
- Accuracy: ± 1 gloss units
- Repeatability: ± 0.5 gloss units
- Optical angle: 20°, 45°, 75°
- For medium and high gloss
- Measurements on textiles and paper possible
- Incl. ISO calibration certificate
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-GM 100

The NDT tester - gloss meter is used for measuring on flat surfaces and operates on the principle of a reflectometer. The compact design and the handy size of the gloss meter makes it useful for on-site measurements or during operation of production plant. All test instruments are delivered manufacturer calibrated and can be certified to ISO as an option.


- Measurement angles 20º, 60º and 85º degree angles
- Measurement range: 0.0 to 200 gloss units
- Standards: ISO 2813, GB 9754-88, GB 9966.5



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-IGM 60

The NDT tester or gloss meter PCE-IGM 60 is an optical measuring instrument with a measuring geometry of 60°. The surface is analyzed by the gloss meter and then the result is shown. Every surface has the characteristic to reflect light.


- Measurement geometry: 60° degree angle
- Measuring range: 0 ... 300 GU
- Standards: ISO 2813 / GB/T 9754 / ASTM D 523 / ASTM D 2457
- Light source: D65
- Wave length: 400-700 nm



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PGM 100

The PCE-PGM 100 NDT tester or gloss meter works with measuring geometries of 20°, 60° and 85°, using the reflection principle. This means that the gloss meter emits light which hits the surface to be tested. A part of the light will be absorbed by the surface and another part will be reflected.


- Measurement geometry: 20° / 60° / 85°
- Standards: ISO 2813 / GB/T 9754 / ASTM D 523 / ASTM D 2457
- Range: 20°: 0 ... 1000 GU / 60°: 0 ... 1000 GU / 85°: 0 ... 160 GU



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-TG 300
The PCE-TG 300 is a NDT test instrument with special sensors for various applications. In general, the wall thicknesses of all homogeneous materials can be measured with the NDT test instrument. For damping or scattering materials such as plastic or cast a special sensor is available.

Measuring range:
PE: pulse-echo mode 0.65 ... 600 mm (steel)
EE: echo-echo mode 2.50 ... 60 mm
Accuracy:
± 0.04 mm H [mm] (<10 mm); ± 0.4% H [mm] (> 10 mm)
H refers to the material thickness of the workpiece
Resolution: 0.1 mm / 0.01 mm / 0.001 mm (adjustable)
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-CT 100N
The NDT tester - surface tester works according to the magnetic inductive (ISO 2178) and the eddy current method (ISO 2360). These methods supported by the surface tester are used for the non-destructive testing of materials.

- Measuring range: 0 ... 1250 µm
- Accuracy: ± (1% + 1 µm)
- Resolution: 0.1 µm (<99.9 µm), 1 µm (> 100 µm)
- Measurement data storage for up to 500 data
- Data transfer via wifi and USB
- Two different probes for NFe and Fe (included)
Manufacturer: PCE Instruments
