Milliohmmeter

Here you will find a milliohmmeter to measure impedance quantities in different fields of both electro technical and electronics; others can also be used as a multimeter. Our milliohmmeter comes with a wide and easy to read display as well as a very easy to use control panel. A milliohmmeter is mainly used in vocational training, in school, in industry and also in the workshop. Besides, the milliohmmeter is used for professionals for their high measuring accuracy capabilities.

Here you will find a milliohmmeter for high, medium and low potential measurements. We offer you a milliohmmeter where range can be automatically selected or by hand. RS 232 interfaces are also available for our milliohmmeter for data to be transferred onto a computer for further analysis.

Batteries and testing cables are included in the delivery so the milliohmmeter can be used out of the box. ISO Calibration certificates can also be done when the milliohmmeter is ordered or as an annual validation.

If you have any questions about the products on this website, please contact us at or +44 ( 0 ) 161 464902 0.

Milliohmmeter PCE-IRM 10

£ 70.00

Price excl. VAT &. delivery

The Milliohmmeter is a compact and easy-to-use device for testing the battery quality of various battery types such as lithium, alkaline and lead-acid batteries. The Milliohmmeter can automatically check the internal resistance and voltage at the same time, with the measurement results clearly shown on the 2.4-inch colour display.

DC voltage: 0 ... 100 V
resolution: 0.0001 V
accuracy: ±0.5 %
resistance: 0 mΩ ... 200 Ω
resolution: 0.01 mΩ
accuracy: ±0.5 %
connections: Kelvin clamps
adjustable limit values
internal memory

Milliohmmeter PCE-MO 2001

£ 352.00

Price excl. VAT &. delivery

This Milliohmmeter comes with a large 3½ positions LCD display that shows the measurement values. Used for measuring binding energy in mines, planes, boats and also for both industrial and home installations.

Measuring ranges: 100 μΩ … 2000 Ω
Resolution: 0.1 / 1/10 mΩ; 0.1 / 1 Ω
Accuracy: ± 0.1%
Measuring rate: approx. 0.4 s
Security: IEC-1010-1; CAT II 20 V

Milliohmmeter PCE-MO 2001-ICA incl. ISO-Calibration Certificate

£ 459.00

Price excl. VAT &. delivery

Measuring ranges: 100 μΩ … 2000 Ω
Resolution: 0.1 / 1/10 mΩ; 0.1 / 1 Ω
Accuracy: ± 0.1%
Measuring rate: approx. 0.4 s
incl. ISO-Calibration Certificate
Security: IEC-1010-1; CAT II 20 V

Milliohmmeter PCE-MO 2006

£ 610.00

Price excl. VAT &. delivery

The milliohmmeter is a compact and precise measuring device with 5 selectable scale ranges for measuring resistances. By using the 4-wire measuring method for mΩ measurements, the milliohmmeter guarantees accurate and reliable results, even with the smallest resistances.

Measuring range: 0 mΩ … 2,000 Ω
Accuracy: ± 0.8 % of Mw.
Resolution: 0.1 mΩ
5 selectable measuring ranges
Test current: 1 mA, 10 mA, 100 mA
Internal memory

Milliohm Meter PCE-MO 2002

£ 717.00

Price excl. VAT &. delivery

Milliohm Meter with ruggedized and waterproof carrying case. Includes 4 test leads with clips.

Measuring ranges / resolution: 5 ranges, 0 … 200 mΩ / 0 … 2000 Ω
Accuracy: ± 0.5% of reading

Max. Output voltage: (C1-C2) 20 V
Power source 12V DC

Milliohmmeter PCE-MO 2006-ICA incl. ISO calibration certificate

£ 771.00

Price excl. VAT &. delivery

Measuring range: 0 mΩ … 2,000 Ω
Accuracy: ± 0.8 % of Mw.
Resolution: 0.1 mΩ
5 selectable measuring ranges
Test current: 1 mA, 10 mA, 100 mA

Internal memory
incl. ISO calibration certificate

Milliohmmeter PCE-MO 2002-ICA incl. ISO-Calibration certificate

£ 789.00

Price excl. VAT &. delivery

This Milliohm Meter comes with a housing protected against water intrusion. With the Milliohm Meter PCE-MO 2002 Series you can measure from 100 μΩ up to 2000 Ω. With this Milliohm Meter measurement values are displayed by means of a LCD display with 3.5 digits and a good readability.

Measuring ranges / resolution: 5 ranges, 0 … 200 mΩ / 0 … 2000 Ω
Accuracy: ± 0.5% of reading
Max. Output voltage: (C1-C2) 20 V
Power source 12V DC
incl. ISO-Calibration certificate

Milliohmmeter PCE-MO 2005

£ 783.00

Price excl. VAT &. delivery

The Milliohmmeter with a measurement range from 0 µΩ to 6000 Ω precisely measures the smallest resistances and is used to check critical connections in electronics and electrical engineering. The Milliohmmeter offers 6 selectable measurement ranges, uses the 4-wire measuring method and can measure both resistance and inductance.

measurement range: 0 µΩ to 6000 Ω
resolution: 1 µΩ
accuracy: ± 0.25 % of Rd + 25 digits
test current: 10 A, 1 A, 100 mA, 10 mA, 1 mA
pass/fail display
calculation of the cable length

Milliohmmeter PCE-MO 2005-ICA incl. ISO-Calibration Certificate

£ 939.00

Price excl. VAT &. delivery

measurement range: 0 µΩ to 6000 Ω
resolution: 1 µΩ
accuracy: ± 0.25 % of Rd + 25 digits
test current: 10 A, 1 A, 100 mA, 10 mA, 1 mA
pass/fail display
calculation of the cable length
incl. ISO-Calibration Certificate
