Manometer

Order no.: PCE-DMM 50

The manometer PCE-DMM 50 is suitable for stationary and mobile pressure measurement. The manometer PCE-DMM 50 is used in mechanical and plant engineering, laboratory technology and environmental technology. This manometer is battery powered. The measuring range of the manometer reaches up to 600 bar.


- Max. 600 bar / 8702 psi
- Rotating display
- For hygienic applications
- Media: water, oxygen, fuels and oils
- Print: absolute or relative (user selectable)
- Diaphragm: Ceramics
- Accuracy class: 0.2

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-HVAC 4

The manometer PCE-HVAC 4 is a versatile measuring instrument for the determination of differential pressure, differential temperature and ambient temperature. The measurements of the manometer PCE-HVAC 4 are via measuring terminals, thermocouples and an internally installed NTC sensor.


- Various parameters: psi, kPa, inHg, amHg, bar, °C, °F
- Measuring range: -60 ... 537°C / -70 ... 998°F
- Built-in ambient temperature sensor
- Battery warning indicator
- Overload indicator
Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PDA 01L

The manometer PCE-PDA 01L is a reliable differential pressure gauge for pressure measurement of gases in the range of ± 200 Pa. The manometer PCE-PDA 01L has many different pressure measuring functions.


- Measuring range pressure: ± 200 Pa
- Resolution: 0.01 / 0.1 Pa
- Accuracy: ± 1% of final value
- Min and Max value memory
- Datalogger and leak test
- Temperature measurement, flow measurement

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PDA 10L

The manometer PCE-PDA 10L is a reliable differential pressure gauge for pressure measurement of gases in the range of ±20 kPa. The manometer PCE-PDA 10L has many different pressure measuring functions.


- Measuring range pressure: ± 20 kPa
- Resolution: 1/ 10 Pa
- Accuracy: ± 0.5% of final value
- Min and Max value memory
- Datalogger and leak test
- Temperature measurement, flow measurement

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PDA 100L

The manometer PCE-PDA 100L is a reliable differential pressure gauge for pressure measurement of gases in the range of -100 to +200 kPa. The manometer PCE-PDA 100L has many different pressure measuring functions.


- Measuring range pressure: -100 ... 200 kPa
- Resolution: 1/10 Pa
- Accuracy: ± 0.5% of final value
- Min and Max value memory
- Data logger and leak test
- Temperature measurement, flow measurement

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PDA A100L

The manometer PCE-PDA A100L is suitable for the measurement of atmospheric pressure. This manometer records the pressure from absolute zero to 200 kPa. The manometer can be used for many mobile applications in industry and crafts.


- Measuring range pressure: 0 ... 200 kPa absolute
- Resolution: 0.01 kPa, 0.1 kPa
- Accuracy: < ± 0.5% of the measuring range
- USB interface
- Datalogger
- Different units

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-PDA 1000L

The relative pressure manometer PCE-PDA 1000L measures the relative pressure on machines and systems. The relative pressure is measured by this pressure manometer in the range between -100 ... 2000 kPa. The relative pressure manometer PCE-PDA 1000L has a quick coupling connection with which the air pressure or water pressure can be directly applied to the device.


- Measuring range pressure: -100 ... 2000 kPa relative
- Resolution: 0.01 kPa, 0.1 kPa
- Accuracy: <± 0.5% of the measuring range
- USB interface
- Data logger
- Adjustable measuring units: Pa, hPa, kPa, MPa, mbar, bar, ATM, kg / cm², mmH2O, cmH2O, inH2O, mmHg, inHg, Torr, PSI, PSF

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-HVAC 2

PCE-HVAC 2 is a high-velocity multifunction manometer with a pitot tube. This portable manometer can be used to determine air speed, air pressure, air flow, differential pressure and ambient temperature. The pitot tube allows access through tiny openings to take measurements in small pipe systems and other confined spaces.


- Measures air velocities up to 80 m/s / 262 ft/s
- Zero, minimum, maximum, average, record and hold functions
- Stores to memory up to 99 measurement values per parameter

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-HVAC 2-ICA

The PCE-HVAC 2 is a multifunction manometer with a pitot tube that measures air velocities up to 80 m/s. It is possible to measure air speed, air pressure, air flow, differential pressure and ambient temperature with this mobile manometer. Readings can be taken in narrow pipes and other restricted spaces because the pitot tube can be inserted in very small gaps.


- Measures air velocities up to 80 m/s
- Zero, minimum, maximum, average, record and hold functions
- Stores to memory up to 99 measurement values per parameter
- Includes ISO calibration certificate

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P01

PCE-P01 is a portable handheld digital differential pressure manometer used to measure differential pressure in pneumatic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. The PCE-P01 displays min / max / average values right on the meter's screen for comparison against current measurement values.

- 0.001 to 0.137 bar (0.001 to 2.000 psi) measuring range
- 11 measurement units: bar, mmHg, ozin², kgcm², psi, inH2O, kPa, ftH2O, inHg, cmH2O, mbar
- Features real-time data-logging capabilities using the included PC software and USB cable

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P05

PCE-P05 is a portable handheld digital differential pressure manometer used to measure differential pressure in pneumatic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. The PCE-P05 displays min / max / average values right on the meter's screen for comparison against current measurement values.

- 0.001 to 0.344 bar (0.001 to 5.000 psi) measuring range
- 11 measurement units: bar, mmHg, ozin², kgcm², psi, inH2O, kPa, ftH2O, inHg, cmH2O, mbar
- Features real-time data-logging capabilities using the included PC software and USB cable

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P15

PCE-P15 is a differential pressure manometer used to measure gauge pressure and true differential pressure in pneumatic, hydraulic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. 11 pressure units are selectable for Imperial and Metric measurement, including bar, mmHg, ozin², kgcm², psi, inH2, kPa, ftH2O|, inHg, cmH2O and mbar.

- Pressure measuring range: 0 to 1.034 bar / 0 to 15 psi
- Resolution: 0.001 bar / 0.01 psi
- Accuracy: ± 0.3% of full scale at 25°C / 77°F

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P30

PCE-P30 is a digital differential pressure manometer used to measure gauge pressure and true differential pressure in pneumatic, hydraulic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. 11 pressure units are selectable for Imperial and Metric measurement, including bar, mmHg, ozin², kgcm², psi, inH2, kPa, ftH2O|, inHg, cmH2Oand mbar.


- Pressure measuring range: 0 to 2.068 bar / 0 to 30 psi
- Resolution: 0.001 bar / 0.02 psi
- Accuracy: ± 0.3% of full scale at 25°C / 77°F



Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 10

The compact manometer PCE-DMM 10 is characterized by its rotatable housing and the display and the battery supply. Thus, the manometer PCE-DMM 10 is ideal for mobile applications, such as test beds.


- Max. 250 bar / 3626 psi
- Rotatable 4.5 digit display
- Battery operation
- Media: gases, fuels and oils
- Pressure: relative
- Diaphragm: Ceramic
- Accuracy class: 0.5

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-P50

PCE-P50 is a differential pressure manometer used to measure gauge pressure and true differential pressure in pneumatic, hydraulic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. 11 pressure units are selectable for Imperial and Metric measurement, including bar, mmHg, ozin², kgcm², psi, inH2, kPa, ftH2O|, inHg, cmH2O and mbar.

- Pressure measuring range: 0 to 6.894 bar / 0 to 100 psi
- Resolution: 0.001 bar / 0.1 psi
- Accuracy: ± 0.3% of full scale at 25°C / 77°F

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-932

PCE-932 is an easy-to-use, digital, handheld device for high pressure measurement in hydraulic and compressor systems, pumps, tanks and silos in chemical, manufacturing, plastics and HVAC industries. This portable pressure measuring device can be connected to pressure sensors with ranges up to 400 bar (each with a 1.2 m / 3.9 ft connecting cable). Please note: Pressure sensors are sold separately.


- Measuring range: 0 to 400 bar / 0 to 5801 psi, depending on sensor
- Measures system pressure in all media (e.g., gasses, liquids, etc.)
- Offers min, max and hold functionality

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-910

PCE-910 is a portable handheld digital differential pressure manometer used to measure differential pressure in pneumatic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. The PCE-910 features a dust-proof, splash-resistant housing, allowing the meter to be used under adverse conditions.

- ± 1 to 2000 mbar (± 0.01 to 29.00 psi) measuring range
- 10 measurement units: psi, mbar, inH2O, mH2O, inHg, mmHg, Torr, Pa / kPa, atm, kg/cm²
- Optional PC software with RS-232 cable sold separately as a data transfer accessory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-917

PCE-917 is a portable handheld digital differential pressure manometer used to measure differential pressure in pneumatic, compressor and pump installations, valves, tanks and heating, ventilation and air conditioning (HVAC) systems. The PCE-917 features a dust-proof, splash-resistant housing, allowing the meter to be used under adverse conditions.

- ± 5 to 7000 mbar (± 0.05 / 0.1 to 101.5 psi) measuring range
- 10 measurement units: psi, mbar, inH2O, mH2O, inHg, mmHg, Torr, Pa / kPa, atm, kg/cm²
- Optional PC software with RS-232 cable sold separately as a data transfer accessory

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 11

The manometer PCE-DMM 11 is distinguished by the long battery life of 1800 h. The rotatable housing and display completes the functionality of the manometer. Thus, the manometer PCE-DMM 11 is ideal for mobile applications, such as test beds.


- Up to 600 bar / 8702 psi
- Relative pressure
- Revolving 4.5 digit display
- Max-Min function
- Different units

Manufacturer: PCE Instruments
Test Instruments manufacturer
Order no.: PCE-DMM 51

The manometer PCE-DMM 51 is suitable for flush mounting hygiene. Thus, the manometer can be installed both in the food industry as well as in medical technology. The manometer shows on its rotatable display pressures up to 400 bar, relative or absolute. The operating fluid of the manometer has a food safe FDA approval.


- Max. 400 bar / 5801 psi
- Rotating display
- For hygienic applications
- Media: water, paints and coatings, gases, viscous and paste media
- Pressure: relative
- Diaphragm: stainless steel flush
- Accuracy class: 0.2

Manufacturer: PCE Instruments
Test Instruments manufacturer
